Panasonic PT-FZ570U WUXGA LCD Projector, 1920x1200, 4500 Lumens

Endurance is the defining quality of PT-FZ570 Series projector. Engineered to extend picture-perfect performance, it features a new dustproof optical drive, long-life lamp and improved filtering technology to maintain brightness and cut operating costs. Dependable without compromise, students benefit from compelling imaging performance while administrators save money every year: a win-win solution from Panasonic, the world leader in education projection.

• Power-saving Eco Standby Mode draws just 0.5 W
• Direct Power Off enables safe projector shutdown via breaker switch
• Anti-theft measures include security bar, password protection and personalized startup logo
• Supports free Multi Monitoring & Control Software
• 10W speaker
• Closed Captioning (NTSC, 480i YCBCR)
• Schedule Function
• Simplified Installation and System Integration
• User-friendly Wired or Wireless Projection
• Versatile Features for Best Results in Any Space
• Save Big on Parts and Servicing

Compact Design Delivers Up to 4500 lm
PT-FZ570 features 4,500 lm of brightness to produce bright and clear images even with the lights on. Documents with text and graphics are easy to read, while still images and video are reproduced with colorful vibrancy.

Image Optimization for Bright Ambient Light
Panasonic's original Daylight View Basic uses a built-in sensor to measure ambient light and calibrate image projection to suit, optimizing brightness and halftone color and sharpening details for easy-to-see pictures in well-lit rooms.

Dynamic Contrast of 10,000:1 with Iris
High dynamic contrast of 10,000:1 is enabled by an iris mechanism, so that white appears white and black appears black (not dark gray) with minimal loss in detail. The result is clear and comfortable viewing.

DICOM Simulation Mode for Medical Presentations
This imaging mode is similar to the DICOM Part 14 medical imaging standard. It lends a film-like quality to X-ray images, making the PT-FZ570 Series ideal for training presentations related to medicine.

WUXGA Resolution Capability
With up to WUXGA (1920 x 1200) resolution, the PT-FZ570 Series is capable of displaying Full HD video. The extra detail and depth engages viewers for a more compelling presentation.

Long Lamp Replacement Cycle
PT-FZ570 Series projectors extend lamp replacement to 8,000 hours (with lamp power set to Eco) or 6,000 hours (lamp power set to Normal), significantly reducing operating costs, labor and environmental impact.

Dustproof Cabinet with Dual-Layer Eco Filter
If dust gets inside the projector's optical unit, brightness suffers. The PT-FZ570 Series protects against dust intrusion with a one-way airflow path and improved sealing for the lens block, air intake duct and dual-layer Eco Filter. This pleated, dual-layer electrostatic filter captures the tiniest dust particles and requires no maintenance for 16,000 hours. It also can be washed and reused. These dustproof projectors are specifically designed to maintain brightness for longer in high-traffic environments while reducing the cost of servicing.

ECO Management Slashes Power Consumption
A variety of Eco Management functions are accessible via a button on the remote controller. These include brightness optimization for ambient light conditions and lamp power reduction when no input signal is detected.

Easy-Access Lamp and Filter
To reduce hassle, the filter can be replaced via the side and the lamp from the top of the projector. There's no need to remove the unit from its ceiling mount for periodic maintenance.

Quiet Operation in ECO Mode
The quiet design reduces operating noise to just 29 dB, with the sound of the cooling fan hardly noticeable. This helps to keep the audience focused on the presentation.

Easy Setup and System Integration

Wide-Range 1.8x Zoom and Lens Shift
The inclusion of a versatile 1.8x zoom and joystick-operated wide-range lens shift grants flexibility for installation in different rooms and for projection on different screen sizes. To produce a 100-inch-diagonal wide-screen image, projection distance extends from approximately 2.6m (8.5') to approximately 4.9m (16.1').

Screen Adjustment for Specially Shaped Screens
Horizontal, vertical and corner keystone correction adjusts the image shape for clear visibility when projecting off-axis or from an unusual angle. Curved Screen Correction allows for the projection of natural, distortion-free images onto curved or cylindrical surfaces.

Installation Simplified with DIGITAL LINK
DIGITAL LINK supports transmission of Full HD video, audio and control signals through a single CAT 5e or higher STP cable for distances of up to 150m (492'). An optional DIGITAL LINK Switcher or Digital Interface Box allows source devices to be connected and signals routed through a single cable, saving on installation costs and simplifying daily operation.

Lens-Centered Design
A symmetrical lens-centered design reduces installation complexity and makes these projectors easier to adapt to a wider range of installation sites.

Integrates into Existing AV Infrastructure
With support for PJLink Class 1, Crestron Connected, AMX and RS-232C over wired LAN, any legacy unit can be swapped out for a PT-FZ570 Series projector without disrupting existing control and management infrastructure. Emulation via RS-232C allows original settings to be preserved. PT-FZ570 Series supports optional Early Warning Software that notifies the administrator ahead of time when part replacement is required.

Project Wirelessly with Optional Module
The optional ET-WML100 wireless USB module enables projection of a variety of media via Windows PCs, iOS devices or Android devices loaded with an appropriate app. Whether projecting from desk or ceiling, there's no need for cables-and it's also possible to display content from more than one device at a time in Multi-Live Mode.

Presenter Light Ver. 1.0 for Windows PCs
• Stills, video, documents (including PDF and PowerPoint files) and other media displayed on the PC screen can be wirelessly projected
• Images from up to four PCs can be projected simultaneously

VueMagic Pro for iOS/Android Devices
• Selected still images and document formats (including PDF files) are supported
• Features Live Camera Mode and Annotate Mode
• Images from up to four devices can be projected simultaneously
