Panasonic PT-RZ660BU WUXGA Solid Shine 1-Chip DLP Laser Projector, Black
Panasonic PT-RZ660BU: Picture 1 thumbnail
Panasonic PT-RZ660BU: Picture 2 thumbnail
Panasonic PT-RZ660BU: Picture 3 thumbnail
Panasonic PT-RZ660BU: Picture 4 thumbnail
See all Panasonic items
56% Off

Panasonic PT-RZ660BU WUXGA Solid Shine 1-Chip DLP Laser Projector, 1920x1200, 6200 Lumens, Black

SKU: PCPTRZ660BU MFR: PT-RZ660BU
Be the first to review this itemAsk a Question
$7,101.99
$15,999.00
Save: $8897.01 (56%)
OR
$592/mo suggested payments with 12‑month special financing. Learn how.
Earn VIP Reward Points

Key Features

  • Experience vibrant visuals with 6,200 Lumens brightness, ideal for well-lit rooms.
  • Enjoy sharp, detailed images with WUXGA resolution perfect for presentations.
  • Benefit from a long-lasting lamp life of up to 24,000 hours in Eco Mode.
  • Connect effortlessly using HDMI, DVI-D, and DIGITAL LINK connectivity options.
  • Achieve flexible installation with vertical and horizontal lens shift capabilities.
  • Project with confidence using this portable projector, designed for business pros.
See More Product Details
Temporarily On Backorder?Expected Availability: 10/2025Request assistance or get notified
Free Shipping

See Options

1
Add to ListGet Sale Alert

Protect your gear with Adorama Protect.* Learn more

2 Year

$499.99

3 Year

$649.99

5 Year

$949.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Accessories
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Browse our FAQ

See Terms & Conditions

Panasonic PT-RZ660BU Specifications

  • DLP chip: Panel size

    17.0mm (0.67") diagonal (16:10 aspect ratio)

  • DLP chip: Display method

    DLP chip x 1, DLP projection system

  • DLP chip: Pixels

    2,304,000 (1,920 x 1,200) pixels

  • Lens

    Powered zoom (throw ratio 1.7-2.4:1), powered focus F 1.7-1.9, f 25.6-35.7mm

  • Light source

    Laser diodes laser Class 1 (Class 3R for US models), light source life: 20,000 hours (Normal Mode) / 24,000 hours (Eco Mode)
    At this time the brightness will have decreased to approximately half of its original level

  • Screen size (diagonal)

    1.27-15.24m (50-600")
    1.27-5.08m (50-200") with the ET-DLE055
    2.54-8.89m (100-350") with the ET-DLE030
    16:10 aspect ratio

  • Brightness

    6,200 lm (Center)/6,000 lm

  • Center-to-corner uniformity

    90%

  • Contrast

    10,000:1 (Full on/off, with Dynamic Contrast Mode set to "3" )

  • Resolution

    1,920 x 1,200 pixels

  • Scanning frequency: SDI

    SD-SDI: SMPTE ST 259 compliant, [YCBCR 4:2:2 10-bit] 480i(525i), 576i(625i)
    HD-SDI: SMPTE ST 292 compliant, [YPBPR 4:2:2 10-bit] 720(750)/60p, 720(750)/50p, 1080(1125)/60i, 1080(1125)/50i, 1080(1125)/25p, 1080(1125)/24p, 1080(1125)/24sF, 1080(1125)/30p
    3G-SDI: SMPTE ST 424 compliant, [RGB 4:4:4 12-bit/10-bit] 1080(1125)/60i, 1080(1125)/50i, 1080(1125)/25p, 1080(1125)/24p, 1080(1125)/24sF, 1080(1125)/30p, [YPBPR 4:2:2 10-bit] 1080(1125)/60p, 1080(1125)/50p

  • Scanning freq.: HDMI/DVI-D/DIGITAL LINK

    480i (525i), 576i (625i), 480p (525p), 576p (625p), 720 (750)/60p, 720 (750)/50p, 1080 (1125)/60i, 1080 (1125)/50i, 1080 (1125)/25p, 1080 (1125)/24p, 1080 (1125)/24sF, 1080 (1125)/30p, 1080 (1125)/60p, 1080 (1125)/50p, VGA (640 x 480) WUXGA (1920 x 1200) (compatible with non-interlaced signals only)
    Dot clock: 25 162 MHz

  • Scanning frequency: RGB

    fH: 15-100 kHz, fV: 24-120 Hz, dot clock: 20-162 MHz

  • Scanning frequency: YPBPR (YCBCR)

    fH: 15.75 kHz, fV: 60 Hz [480i (525i)]
    fH: 15.63 kHz, fV: 50 Hz [576i (625i)]
    fH: 45.00 kHz, fV: 60 Hz [720 (750)/60p]
    fH: 33.75 kHz, fV: 60 Hz [1035 (1125)/60i]
    fH: 28.13 kHz, fV: 50 Hz [1080 (1125)/50i]
    fH: 27.00 kHz, fV: 24 Hz [1080 (1125)/24p]
    fH: 33.75 kHz, fV: 30 Hz [1080 (1125)/30p]
    fH: 56.25 kHz, fV: 50 Hz [1080 (1125)/50p]

  • Scanning frequency: YPBPR (YCBCR)(cont.)

    fH: 31.50 kHz, fV: 60 Hz [480p (525p)]
    fH: 31.25 kHz, fV: 50 Hz [576p (625p)]
    fH: 37.50 kHz, fV: 50 Hz [720 (750)/50p]
    fH: 33.75 kHz, fV: 60 Hz [1080 (1125)/60i]
    fH: 28.13 kHz, fV: 25 Hz [1080 (1125)/25p]
    fH: 27.00 kHz, fV: 48 Hz [1080 (1125)/24sF]
    fH: 67.50 kHz, fV: 60 Hz [1080 (1125)/60p]

  • Scanning frequency: Video/YC

    fH: 15.75 kHz, fV: 60 Hz [NTSC/NTSC4.43/PAL-M/PAL60]
    fH: 15.63 kHz, fV: 50 Hz [PAL/PAL-N/SECAM]

  • Optical axis shift: Vertical

    +50 %, -16 % (powered)

  • Optical axis shift: Horizontal

    +30 %, -10 % (+28 %, -10 % with ET-DLE085) (powered)

  • Keystone correction range

    Vertical: +/-40 deg. (+/-22 deg. with ET-DLE085/DLE055, +5 deg. with ET-DLE030)
    Horizontal: +/-15 deg. (cannot be operated with ET-DLE030)

    With Optional upgrade kit ET-UK20:
    Vertical: +/-45 deg. (+/-40 deg. with the ET-DLE150/ET-DLE250/ supplied lens, +/-22 deg. with the ET-DLE085/ET-DLE055)
    Horizontal: +/-40 deg. (+/-15 deg. with ET-DLE085/ET-DLE055)
    Up to a total of +/-55 deg. during simultaneous horizontal and vertical correction.

  • Installation

    Ceiling/floor, front /rear, free 360-degree installation

  • Terminals

    SDI IN: 1x BNC (3G/HD/SD-SDI)
    HDMI IN: 1x HDMI 19-pin (Deep Color, compatible with HDCP)
    DVI-D IN: 1x DVI-D 24-pin (DVI 1.0 compliant, compatible with HDCP, compatible with single link only)
    RGB 1 IN: 5x BNC (1x RGB/YPBPR/YCBCR/YC/Video)
    RGB 2 IN: 1x D-Sub HD 15-pin (female) (1x RGB/YPBPR/YCBCR)

  • Terminals (cont.)

    SERIAL/ MULTI PROJECTOR SYNC IN: 1x D-sub 9-pin (female) for external control (RS-232C compliant)
    SERIAL/ MULTI PROJECTOR SYNC OUT: 1x D-sub 9-pin (male) for link control
    REMOTE 1 IN: M3 x 1 for wired remote control
    REMOTE 1 OUT: M3 x 1 for link control (for wired remote control)
    REMOTE 2 IN: 1x D-sub 9-pin (female) for external control (parallel)
    LAN/DIGITAL LINK: 1x RJ-45 (for network, DIGITAL LINK connection, 100Base-TX, compatible with Art-Net, PJLink)

  • Cabinet materials

    Molded plastic

  • Noise level

    35 dB

  • Operating environment

    Operating temperature: 0 to 45 deg. C / 32 to 113 deg. F
    Operating humidity: 10-80 % (no condensation)

  • Power supply

    100-240 V AC, 10.4-5.0 A, 50/60 Hz

  • Power consumption

    700 W,
    (499 W with OPERATING MODE set to NORMAL,
    428 W with OPERATING MODE set to ECO,
    287-402 W with OPERATING MODE set to LONG LIFE 1,
    262-402 W with OPERATING MODE set to LONG LIFE 2,
    238-402 W with OPERATING MODE set to LONG LIFE 3,
    69 W with OPERATING MODE set to SHUTTER)
    (0.2 W with STANDBY MODE set to ECO,
    3 W with STANDBY MODE set to NORMAL,
    85 W with QUICK STARTUP set to ON.)

  • Applicable software

    Logo Transfer Software
    Multi Monitoring & Control Software
    Early Warning Software
    Geometry Manager Pro (ET-UK20 Upgrade Kit and ET-CUK10 Auto Screen Adjustment Kit)

  • Dimensions (W x H x D)

    498 x 200 x 581mm (19.61 x 7.87 x 22.87")

  • Weight

    Approx. 23.1 kg (50.9 lbs)

1 Accessories for Panasonic PT-RZ660BU WUXGA Solid Shine 1-Chip DLP Laser Projector, 1920x1200, 6200 Lumens, Black

  • All Accessories (1)
  • Stands (1)
Flashpoint Laptop Stand and Accessory Tray
Flashpoint Laptop Stand and Accessory Tray
$69.00
Recommended

About Panasonic PT-RZ660BU

With the PT-RZ660BU WUXGA Solid Shine 1-Chip DLP Laser Projector, you can experience high-resolution, bright, and vivid images perfect for education, museums, exhibitions, and digital signage applications. This projector boasts a laser light source that ensures high brightness and excellent image quality, making it an ideal choice for intensive usage.

The PT-RZ660BU is equipped with a dust-resistant optical block and a long-lasting laser engine, providing up to 20,000 hours of maintenance-free operation. Its 360-degree installation and Geometric Manager Pro function offer flexibility in setup and use.

This projector stands out with its next-generation DLP technology and dual laser modules, delivering a brightness of up to 7,200 lm (center). The quartet color harmonizer reduces energy loss from the light source, while the robust and heat-resistant phosphor wheel produces scintillating images with unfailing reliability.

The PT-RZ660BU projector captures a wider color space than comparable laser projectors, thanks to its quartet color harmonizer wheel mechanism. This feature allows for the realistic reproduction of whites on the screen, eliminating the distracting greenish tint often seen with conventional projectors.

The dual solid-state laser modules ensure that the image colors and brightness degrade very gradually, preserving the out-of-the-box picture quality for longer. The projector also features a failsafe redundancy circuit that minimizes brightness and color uniformity loss if a laser diode fails, making it ideal for mission-critical applications.

The PT-RZ660BU projector directly modulates laser power output to achieve high contrast with low power consumption. Its digitally controlled frame-by-frame scene-linking modulation ensures highly precise output adjustment, delivering an accurate 10,000:1 contrast ratio even when bright and dark scenes frequently interchange.

Panasonic's premium system daylight view 3 enhances brightness perception in multi-projector mapping applications by adjusting sharpness, gamma curves, and correcting colors. This results in greater visual impact even in challenging lighting conditions.

The PT-RZ660BU projector is designed with a dust-resistant airtight optical block, ensuring consistent, long-lasting image quality for up to 20,000 hours without maintenance. This design has passed stringent testing to assure utmost reliability in environments with up to 0.15mg of particulate matter per cubic meter.

In Normal Mode, the PT-RZ660BU projector can operate continuously for about 20,000 hours. In Eco Mode, this extends to around 24,000 hours. These modes enhance the projector's suitability for education and signage applications.

The PT-RZ660BU projector is among the world's first to feature contrast and shutter sync functions for multi-screen and mapping applications. Its Geometric Adjustment feature adapts the image for projection onto spherical, cylindrical, and other specially shaped screens. The projector also supports transmission of uncompressed Full HD video and control commands through a single CAT 5e or higher STP cable for distances of up to 150m.

Panasonic PT-RZ660BU Features

  • High-resolution 1-Chip DLP Laser Projector with 1920x1200 WUXGA Solid Shine technology
  • Long-lasting brightness of up to 6200 Lumens, perfect for education, museums, exhibitions, and digital signage applications
  • Maintenance-free operation up to 20,000 hours with dust-resistant optical block and long-lasting laser engine
  • Quartet color harmonizer wheel mechanism for outstanding white balance and color reproduction
  • Dynamic light control for high contrast and low power consumption, with an accurate 10,000:1 contrast ratio
  • Geometric Adjustment feature for projecting onto spherical, cylindrical, and other specially shaped screens
  • Supports transmission of uncompressed Full HD video and control commands through a single CAT 5e or higher STP cable for distances of up to 150m

Warranty Information

This product has a limited warranty of 36 months.

Join VIP PRO

2 Day Delivery on thousands of items!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Experience vibrant visuals with 6,200 Lumens brightness, ideal for well-lit rooms.
  • Enjoy sharp, detailed images with WUXGA resolution perfect for presentations.
  • Benefit from a long-lasting lamp life of up to 24,000 hours in Eco Mode.
  • Connect effortlessly using HDMI, DVI-D, and DIGITAL LINK connectivity options.
  • Achieve flexible installation with vertical and horizontal lens shift capabilities.
  • Project with confidence using this portable projector, designed for business pros.

What's in the box:

  • Panasonic PT-RZ660BU WUXGA Solid Shine 1-Chip DLP Laser Projector
  • Power Cord with Secure Lock
  • Wireless/Wired Remote Control Unit
  • 2x R03/AAA Battery
  • Software CD-ROM (Logo Transfer
  • Multi Monitoring & Control Software)
  • Panasonic Warranty
