PHABRIX Dolby E-D-D+ Bitstream Generator Software Option for PHRXM-AG, PHRXM-AGE Module and Rx2000, Rx1000, Rx500 Instrument Chassis

What sets the Dolby E-D-D+ Bitstream Generator Software Option apart is its ability to generate pre-encoded test signals for Dolby-E, Dolby Digital, and Dolby Digital Plus. This advanced software, designed for the PHRXM-AG, PHRXM-AGE Module, and Rx2000, Rx1000, Rx500 Instrument Chassis, ensures that these signals are transferred seamlessly through the broadcast chain, unaffected by routers, switchers, or satellite links.

The Dolby Generator, a system resource, can be utilized to embed a Dolby data stream in the audio channels of any generated SDI video or AES audio. This software option is built on the audio encoding and decoding technologies developed by Dolby Laboratories, a leader in the field.

The Dolby E feature supports up to 8 channels of lossless compressed audio, including mono, stereo, 5.1, or 7.1 for a primary program and optional ancillary programs. This allows for the generation of program metadata types such as Dolby 7.1, which uses eight channels to provide immersive surround sound and is widely used in the industry.

The Dolby Digital (AC3) feature supports up to six channels of lossy compressed audio, including mono, stereo, or 5.1, forming a single 'program'. This feature enables the generation of Dolby 5.1 metadata, which uses all six channels to deliver surround sound and is a daily staple in the audio world.

The Dolby Digital Plus feature supports up to 20 channels of lossless compressed audio, including mono, stereo, 5.1, 7.1, up to 13.1, and optional ancillary programs. This allows for the generation of program metadata types such as Dolby 7.1, which uses eight channels to provide surround sound and is commonly used in the industry.

The generated Dolby stream aligns with the video generator reference source and can be embedded on any SDI audio pair and output as an AES pair. This Dolby E-D-D+ Bitstream Generator Software Option is a powerful tool for any audio professional seeking to enhance their audio production and broadcasting capabilities.
