Pioneer Electronics PLX-500 Direct Drive Turntable, Black

SKU: PIPLX500K

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

GREGORY W : Is this a semi automatic turntable?
Shopper : Why Did You Choose This?Bradley B : Trouble with a belt drive. I have a Pioneer system.

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Pioneer Electronics PLX-500 Specifications

Turntables

Turntables

Jump to...
  • Color

    Black

  • Drive Method

    Servo-type direct drive

  • Platter

    Aluminum, die-casting diameter: 332mm

  • Motor

    3-phase, brushless DC motor

  • Braking System

    Electronic brake

  • Rotation Speed

    33.33, 45, 78 rpm

  • Rotation Adjustment Range

    +/-8 %

  • Wow and Flutter

    < 0.15% WRMS

  • Signal-to-Noise Ratio

    50 dB

  • Starting Torque

    > 1.6 kgf x cm

  • Start Time

    Within 1 sec (at 33.33 rpm)

Tone Arm

Jump to...
  • Arm Type

    Universal type S-shape tone arm
    Gimbal-supported type bearing structure
    Static balance type

  • Overhang

    0.63" (1.6cm)

  • Effective Length

    9.07" (23cm)

  • Tracking Error

    Within 3 Degree

  • Height Adjustment Range

    0.24" (0.6cm)

  • Stylus Pressure Variable Range

    0-4g (1 scale 0.1g)

  • Cartridge Weight Single

    < 0.33 oz (9.5g)

  • Cartridge type

    VM

Terminals

Jump to...
  • USB

    1x USB B port

  • Outputs

    1x PHONO/LINE (RCA)

Physical

Jump to...
  • Dimensions (W x H x D)

    17.72 x 6.26 x 14.49" (45 x 15.9 x 36.8cm)

  • Weight

    23.59 lbs (10.7kg)

  • UPC Code

    841300100423

About Pioneer Electronics PLX-500

Go vinyl
The PLX-500 inherits the layout of the PLX-1000 professional turntable and produces a warm, clear analogue sound. The perfect deck if you want to start playing with vinyl or if you just want to listen to your record collection at home.

Solidly built with excellent vibration damping and precise audio playback, this high-torque deck has a USB out so you can make digital recordings of your vinyl collection in our free rekordbox software. You can also combine the PLX-500 with the rekordbox dvs Plus Pack, a compatible mixer and the RB-VS1-K Control Vinyl to play and scratch with digital files.

Features

Excellent sound design
Just like the PLX-1000, the PLX-500 is built to produce a high-quality vinyl sound. The shortest possible audio routing from the stylus to the outputs reduces distortion, while the phone/line output switch lets you connect directly to your sound system or to powered speakers with no need for an external amplifier.

Easy digital recording
Record your vinyl collection to high-quality digital files by simply connecting the turntable to your PC or Mac via the USB out.

Smooth DJ play
Use the PLX-500 to mix and scratch your vinyl records or combine the turntable with rekordbox dvs, a compatible DJ mixer and the RB-VS1-K Control Vinyl to play and perform with your digital files.

Cover art display
Put your record covers on display while listening to your vinyl thanks to the sleeve stand inside the dust cover.

Pioneer Electronics PLX-500 Features

  • Excellent sound design
  • Easy digital recording
  • Smooth DJ play
  • Cover art display

Key Features

  • Excellent sound design
  • Easy digital recording
  • Smooth DJ play
  • Cover art display

What's in the box:

  • Pioneer Electronics PLX-500 Direct Drive Turntable (Black)
  • Power Cord
  • USB Cable
  • Slip Mat
  • Dust Cover
  • Adapter for EP Records
  • Head Shell with Cartridge
  • Balance and Shell Weights
  • Audio Adapter Cable (Stereo Pin Plug Female to Stereo Mini Plug Male)
  • Operating Instructions
  • Pioneer Electronics 1 Year Limited Warranty
