Pioneer Electronics VSX-LX303 9.2-Channel Network AV Receiver, 100W/Ch (At 8 Ohms)

Designed for optimum Dolby Atmos/DTS:X movie playback in a seamless 7.2.2ch/5.2.4ch surround sound calibrated by MCACC and with support for next-generation video standards, the Elite VSX-LX303 brings multi-dimensional excitement to your home theater. The FlareConnect platform offers wireless multi-room audio with easy control on the Pioneer Remote App for various sources including vinyl records. Enjoy internet radio and network streaming services with Chromecast built-in and DTS Play-Fi via your smartphone.

Works with Sonos
With Sonos Connect, the awesome home theater you've built around your Elite receiver can now be part of your existing Sonos Home Sound System or the start of a new one. Instantly upgrade the music streaming capability of your home theater with Sonos Connect and a free firmware update. After a simple set up, your Elite A/V receiver will seamlessly tie into Sonos, instantly waking, changing inputs and playing at the volume you command through the familiar Sonos app.

Dolby Atmos/Dolby Surround Upmixing
The VSX-LX303 is compatible with 7.2.2ch/5.2.4ch configuration of the latest theater sound platform, Dolby Atmos. You can reproduce object-oriented sound in smooth, curving movements or the realistic three-dimensional movement overhead by the top speakers. Other audio codecs including DTS formats can now be upmixed using Dolby Surround for enjoying 3D surround sound.

DTS:X/DTS Neural:X Upmixing
DTS:X is the next-generation audio codec from DTS that leverages object-based audio to enable new immersive and interactive audio experiences. Enjoy a seamless soundscape with 7.2.2ch/5.2.4ch surround system offering maximum excitement. Other audio codecs including Dolby formats can now be upmixed using DTS Neural:X for enjoying 3D surround sound.

Powered Zone 2 & Zone 3
You can enjoy 2-ch audio in a separate room (ZONE 2/ZONE 3) while performing 5.1-ch playback in the main room. The same source can be played back in the main room and ZONE 2/ZONE 3 simultaneously. Also, different sources can be played back in both rooms.

Next Generation Video
The VSX-LX303 supports pass-through for HDR10, HLG (Hybrid Log-Gamma) and Dolby Vision signals. By connecting a compatible source device, you can enjoy these latest video standards on a compatible display. What's more, all HDMI terminals support 4K (60p/4:4:4/24-bit), Wide Color Gamut (BT.2020) and HDCP 2.2, so you will have no problem when upgrading to new devices and can also enjoy premium content such as 4K videos with digital copy protection.

MCACC Auto Room Tuning
Create the optimum acoustic environment with Pioneer's MCACC (Multi-Channel Acoustic Calibration System), developed with the expertise of professional recording studios. With the custom microphone, the system automatically compensates for differences in speaker size, level and distance and equalizes response.

Synchronized Sound with Phase Control
As an innovative solution for the phase lag between the subwoofer and the main channel speakers caused by the bass management filter, Phase Control compensates the delayed bass to improve sound synchronization.

Reflex Optimizer
When using Dolby Atmos-enabled speakers, high directivity sound from the unit reflects off the ceiling, while low directivity sound directly reaches the ears. The different pathways cause a phase shift, making the sound feel uncomfortable. The Reflex Optimizer which uses the Phase Control technology adjusts this shift and improves the localization of the sound image by aligning the frequencies with those of the floor speakers, creating the ideal reproduction environment.

Multi-room Audio Offers a Variety of Ways to Enjoy Music
FlareConnect shares audio from network and external audio input sources between compatible components. Enjoy effortless multi-room playback of LP records, CDs, network music services and more with supported components and speaker systems. Music selection, speaker grouping and playback management across the home are built into the Pioneer Remote App.

Chromecast built-in
The VSX-LX303 comes with Chromecast built-in, so you can use your mobile device to stream your favorite music, radio or podcasts to your speaker. You can control the audio from anywhere in the house using Chromecast enabled apps running on your personal device-iPhone, iPad, Android phone and tablet, Mac and Windows laptop and Chromebook. The VSX-LX303 also works with Google Assistant, so you can give voice commands via Google Assistant built-in devices such as Google Home to operate the AV receiver without lifting a finger. Discover Chromecast-enabled apps at google.com/cast/apps.

DTS Play-Fi
DTS Play-Fi wirelessly streams any audio content from any compatible mobile device to the VSX-LX303 and DTS Play-Fi compatible audio systems, creating a multi-room system in your home. You can stream different sources to different speakers at the same time from the Pioneer Music Control App.

Amplification
• Channels: 9
• Amplification Type: Direct Energy
• 200 W/ch (6 ohms, 1 kHz, THD 10 %, 1ch Driven)
• 100 W/ch (8 ohms, 20 Hz-20 kHz, THD 0.08 %, 2ch Driven, FTC)

Audio Features
• Dolby Atmos, Dolby Surround Upmixer supports DTS Formats
• DTS:X, DTS Neural:X Upmixer supports Dolby Formats
• Reflex Optimizer
• Dolby TrueHD, Dolby Digital Plus
• DTS-HD Master Audio, DTS-HD High Resolution Audio, DTS 96/24, DTS-ES, DTS Express
• DSD Disc (SACD) Playback via HDMI (5.6, 2.8 MHz/2 ch, 2.8 MHz/5.1 ch)
• Digital Quad-Core 32-bit DSP (Cirrus Logic) + Aureus Floating-Point DSP (TI)
• 384 kHz/32-bit D/A Conversion with AK4458 (AKM) & PCM5101 (TI)
• Audio Return Channel (ARC) on HDMI
• MCACC Auto Room Tuning - Phase Control, Subwoofer EQ, Multi-point Standing Wave Control
• Advanced Sound Retriever (2ch)
• Advanced Surround Modes - Classical, Unplugged, Entertainment Show, Drama, Advanced Game, Action, Rock/Pop, Sports, Extended Stereo, Extended Mono, Front Stage Surround Advance

Video Features
• Ultra HD Pass-through with HDCP 2.2 (4K/60p/4:4:4/24-bit, 4K/24p/4:4:4/36-bit, 4K/60p/4:2:0/36-bit)
• HDR10, HLG and BT.2020 Wide Color Gamut Signal Pass-through
• Dolby Vision Compatible
• Ultra HD Upscaling (1080p to 4K)
• 3D Ready (Blu-ray Disc, Broadcast and Games)
• Deep Color (36-bit), "x.v.Color"

Home Network Features
• FlareConnect for Multi-room Audio
• Chromecast built-in
• Works with the Google Assistant
• DTS Play-Fi with Pioneer Music Control App
• Apple AirPlay Certified
• Amazon Music, Pandora, Spotify, TIDAL and Deezer Music-Streaming Services Ready
• Internet Radio with TuneIn
• Hi-Res Audio File Playback via USB/Network
• Up to 192 kHz/24-bit ALAC, AIFF, FLAC, WAV (RIFF) and 5.6 MHz DSD
• Dolby TrueHD

Convenience Features
• Powered Zone 3/Zone 2
• Dual Band (5 GHz/2.4 GHz) Wi-Fi Built-in
• Bluetooth Wireless Technology (Version: 4.1 + LE, Profile: A2DP 1.2/AVRCP 1.3, Codec: SBC/AAC) Built-in
• Pioneer Remote App
• Ready for Multi-room Entertainment Control and Network Streaming
• User-Friendly GUI with System/Network Setup Menu
• Auto Power Off in HDMI Standby Through
• AM/FM Tuner 40 Presets
• Sleep Timer
• User-Friendly Simple Remote Control
