Pioneer Electronics VSX-824-K 5.2-Channel AV Receiver with Ultra HD Pass-through, Gapless Playback, Dual Subwoofer Preout, Spotify Ready and Roku Ready

SKU: PIVVSX824K

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Pioneer Electronics VSX-824-K Specifications

  • Amplifier Design

    Discrete Direct Energy

  • Channels

    5.2

  • Power Output: 20Hz-20kHz,.08%THD

    80W x 5 (Watts per Channel) at 8Ohms

  • Power Output: 1kHz at 8Ohms

    SC Model Power Rating Only (Watts per Channel)

  • Power Output: 1kHz,1%THD at 6Ohms

    140W x 5 (Watts per Channel)

  • Estimated Power Consumption/Standby

    450 W/0.1 W (with HDMI Control off)

  • AirPlay

    Yes

  • HTC Connect

    Yes

  • Made for iPhone and iPod

    Yes

  • Supported Apple Devices

    iPhone 5s, iPhone 5c, iPhone 5, iPhone 4s, iPhone 4, iPhone 3GS, iPhone 3G, iPhone, iPod touch 5G/4G/3G/2G/1G, iPod nano 7G/6G/5G/4G/3G (Audio Only)

  • iOS/Android Remote Control APP

    iControlAV5

  • DLNA 1.5

    Yes

  • Pandora Internet Radio

    Yes

  • vTuner Internet Radio

    Yes

  • Digital Core DSP Engine

    Texas Instruments Aureus

  • DAC

    192kHz / 24-Bit

  • iPod Digital Audio

    Yes

  • Music File Playback

    MP3, WMA, AAC, Apple Lossless, WAV, FLAC, AIFF via USB and Network

  • Dolby True HD

    Yes

  • Dolby Digital Plus

    Yes

  • DTS-HD Master Audio

    Yes

  • HDMI SACD Transfer

    2 Channel

  • Phase Control

    Yes

  • MCACC

    Auto

  • EQ Bands

    5-Band

  • Symmetric EQ

    Yes

  • MCACC Memory

    1

  • Distance Adjustment

    0.1 Feet

  • Auto Surround

    Yes

  • Stream Direct

    Yes (Direct, Pure Direct)

  • Advanced Surround

    11 + 1

  • Front Stage Surround Advance

    Yes

  • Headphone Surround

    Yes

  • DSD to PCM Converter

    2 Channel

  • Auto Level Control

    2 Channel

  • Advanced Sound Retriever

    2 Channel

  • Sound Retriever AIR

    Yes

  • Midnight Listening

    Yes

  • Loudness

    Yes

  • Tone Control

    2 Channel

  • Sound Delay (Lip Sync)

    Yes (0 to 500 msec)

  • 4K Ultra HD Pass-Through

    Yes

  • 3-D Ready

    Yes

  • Audio Return Channel

    Yes

  • HDMI Standby Through

    Yes with Input Switch / Last Memory

  • HDMI 36-bit Deep Color

    Yes

  • HDMI x.v. Color

    Yes

  • HDMI Input / Output

    6 In (5 Rear / 1 Front) / 1 Out

  • MHL 2.0 Input

    1 (Rear)

  • Bluetooth Adapter Port

    Optional AS-BT200

  • Composite A/V Input / Output

    2 In

  • iPod/ iPhone

    Yes (Audio Only)

  • Front USB Memory Input

    1 (Front)

  • Ethernet Input

    Yes

  • Wireless Adapter Port

    Optional AS-WL300

  • Analog Audio Inputs / Output

    1 in (Assignable)

  • Digital Inputs / Output

    2 In

  • Pre-Amp Output

    .1 ch (SW)

  • Headphone Output

    Yes

  • Front A/V Inputs

    USB & HDMI

  • Power Save for HDMI Stand-by Through

    Yes

  • AM/FM Presets

    30 Preset AM / FM Tuner

  • On-Screen Display

    Network GUI / Set-Up Text - HDMI Only

  • Auto Power Down

    Yes

  • ECO Mode

    Yes

  • FL Dimmer

    Yes

  • Remote

    System Remote Control

  • Sleep Timer

    30, 60, 90 min.

  • Front Panel

    Brushed

  • Speaker Terminals

    5 Large

  • Dimensions (W x H x D)

    17.13 x 6.61 x 13.07" / 43.51 x 16.79 x 33.20cm

  • Weight

    18.68lbs / 8.47kg

  • UPC Code

    884938244039

About Pioneer Electronics VSX-824-K

The Pioneer Electronics VSX-824-K is an advanced, yet affordable receiver that sets the tone for Pioneer's innovative approach to the networked home theater experience. The VSX-824-K is one of the most versatile AV receivers for the Apple or Android platforms, letting you stream your favorite content, while you control the receiver from the palm of your hand. Plus, it readily accommodates leading-edge media, such as high-resolution music files and 4K Ultra HD content.

A Resolution Revolution
Offering 6 HDMI HDMI 2.0 inputs, the VSX-824-K handles 4K2K Ultra HD video at 60 frames per seconds. 4K Ultra HD is the latest high-definition video display format, with four times the resolution of 1080p. Ready to deliver 4K Ultra HD video signals to a compatible display, the Pioneer VSX-824-K supports home theater systems dedicated to producing the highest quality picture available today. HDMI 2.0 is also backwards compatible with earlier versions of HDMI. The VSX-824-K allows 4:4:4 based 4K2K 60P content to be handled offering up to 18GBPS throughput.

Easy Streaming
Roku makes it easy to stream movies, shows, music and games from over 1,000 content providers to your TV whenever you want them. Simply plug your Roku Streaming Stick into the Roku Certified MHL 2.0 port on the back of your receiver to unlock a great selection of entertainment choices. Control the attached Roku stick from the receiver's remote control or free iControlAV5 app for the most convenient access to your favorite entertainment. Roku Streaming Stick sold separately.

Command In Your Hand
From switching inputs and controlling volume, to exploring all of the new features of your AVR, all-new iControlAV5 iOS and Android remote control app offers full control of your VSX-824-K. You can even playback music stored on your phone using Push Player feature. The app is available at no cost from www.AppStore.com or the App Store for iPhone, iPad and iPod touch. The app is also available in Google Play or Android devices.

The Power of Wireless
When equipped with the optional AS-WL300 wireless network adapter, the VSX-824-K is the ultimate control center of your home entertainment system. The AS-WL300 provides wireless compatibility with applications such as iControlAV5, the AVNavigator, Internet Radio and DLNA 1.5 Audio Streaming.

Ready Connectivity
The VSX-824-K gives you instant access to your favorite content and allows you to control it with your smartphone or tablet. It offers the latest Made for iPhone 5s and 5c Certification. And as a networked receiver, it supports Apple's AirPlay music streaming technology, allowing you to enjoy your favorite music with your iPhone, iPod or iTunes anywhere in the house. In addition, Pioneer was the first brand to support HTC Connect, the only unified approach for streaming music wirelessly from select compatible Android smartphones. HTC Connect is built right into your phone's music player, making it easy to wirelessly stream your favorite music to your receiver no separate app required. The VSX-824-K also supports DLNA 1.5 media streaming, which lets you access your favorite music from a DLNA server or computer connected to the same home network. Not only are compressed music files, such as MP3, WMA and AAC supported, but also high-resolution files, such as FLAC, WAV, AIFF and Apple Lossless.

Playback Prowess
The Pioneer VSX-824-K delivers the high-resolution music playback you demand with support for 192 kHz 24-bit AIFF, WAV, FLAC and Apple Lossless up to 96kHz 24-Bit. Compressed formats, such as MP3, WMA and AAC are also supported. Stream these files from your home network, tablet or even the front USB.

The World Wide Web Is Your Oyster
With Internet Radio, the VSX-824-K gives you a wealth of entertainment options. Not only can you enjoy thousands of Internet radio stations around the world with vTuner, you can also access your favorite music from Pandora and Spotify, complete with on-screen album art and music information. Spotify Connect is a premium feature that lets you play and control Spotify with your smart devices.

Customize Your Home Theater to YOUR Room
MCACC creates the optimum acoustic environment for movies and music in any room in the house. Pioneer developed the technology over 10 years ago with the help of professional recording studios. The system, complete with custom microphone, automatically compensates for differences in speaker size, level and distance and equalizes the response. Whether you're watching the latest Hollywood blockbuster or listening to high-resolution music, MCACC will make sure your home theater sounds its best.

On-Screen Overlay
If your home theater system is enclosed in a cabinet, it's often difficult to know the status of certain functions, such as current volume level. With On Screen Display (OSD), your receiver's basic information, such as volume, input and surround mode, will overlay on screen as you make adjustments with the remote, so you don't have to switch to a blank screen background. Of course you can turn it off it you want. Meanwhile, the GUI (Graphical User Interface) lets you easily navigate Internet radio and iPod/iPhone contents. Both the OSD and GUI operate via HDMI.

Bluetooth Ready
The AS-BT200 Bluetooth adapter is a simple solution for adding wireless audio to your home theater system. Using the AS-BT200, simply connect your A2DP profile Bluetooth-enabled device to the port on the back the VSX-824-K and enjoy your music wirelessly from your iPhone, Android, PC, laptop or any other A2DP profile Bluetooth-enabled sources. AS-BT200 is sold separately.

The Ease of Green
All Pioneer AV receivers feature an energy-saving ECO Mode that, when enabled, achieves a standby power consumption of only 0.1 watt. With a host of convenience features, including Network Standby and HDMI CEC support, ECO Mode analyzes your sources in real time, adjusting power consumption accordingly to meet your needs. Or you can manually select the power-saving settings that are right for you.

What's in the box:

  • Pioneer Electronics VSX-824-K 5.2-Channel AV Receiver
  • Pioneer Electronics 1 Year Parts and Labor Limited Warranty
