Pix4D PIX4Dfields Educational Classroom Software, 25 Devices, One-Time Charge, Download

- Pix4Dfields -

Advanced agriculture mapping software for aerial crop analysis and digital farming

Capture
Collect images using a drone and any standard RGB or a selected multispectral camera like Parrot Sequoia+ and MicaSense RedEdge. Use our Pix4Dcapture app to easily plan and control your drone flight for optimal mapping.

Process
Process imagery with the instant processing engine and get your maps directly in the field: 6.8 GB, 2948 images, 10 min (with the new radiometry module).

Scout
Generate precise Ortho mosaics, digital surface models, index maps, zones and accurate prescription maps. Trim your fields to a desired field boundary to create more targeted outputs.

Analyze
Visualize and understand your crop growth stages and stress levels. Analyze and compare different layers of information for a full insight of your yield performance and use them to increase crop production and reduce costs.

Share
Share your maps with all project stakeholders for seamless collaboration using Pix4Dfields PDF report tool.

Integrate
Download all outputs, results and insights and import them into the Farming Management Software of your choice in various industry standard formats.

Precision agriculture mapping using images from drones and UAVs
The only digital agriculture software focusing on reducing the processing time while incorporating the highest accuracy standards backed up with years of scientific research.

In-Field Results
Create maps rapidly (no internet connection required) for faster decision making and action, without leaving the field.

Reliable Maps
Always get maps of your fields and crops at any critical stage regardless of satellite availability and cloud cover.

Trusted Results
Eliminate guesswork by analyzing crop health maps and measure issues using calibrated multispectral or full resolution RGB images.

Connected
Connect your data to platforms like the John Deere Operations Center, synchronize and access your data in-office and in-field for streamlined collaboration.

WEBINAR

Bridging the gap between planting and harvesting
In this free webinar, hosted by Pix4D with 4Rivers Equipment and John Deere, you will discover how to bridge the uncertainty gap and improve your agricultural workflows with Pix4Dfields software and a drone.

Inspect, analyze and visualize your crop changes all year round

Fast mapping
Process imagery with the Pix4Dfields instant processing engine and achieve results in minutes in-office and in-field. No internet required.

Generate indices
Use the predefined list of agricultural indices or input your own custom index formula to understand your plant stress better.

Compare
Link different layers of information and compare your crop trends over time in a split or a double screen.

Measure and Annotate
Add annotations to and measure important farm areas.

Export PDF report
Share your maps with all project stakeholders and team for seamless collaboration using Pix4Dfields PDF report tool.

Inputs

MSP images
Import images collected from multispectral sensors like Parrot Sequoia and the MicaSense RedEdge family (import as TIFF or JPG).

RGB images
Import images collected from standard RGB sensors (import as JPG, TIFF or PNG).

Pre-processed maps
Import Ortho mosaics or vegetation index maps already processed in other Pix4D products (import as geoTIFF).

Field boundaries
Import your field boundaries to focus analysis on your areas of interest (import as Shapefile, KML or GeoJSON).

Annotations
Import annotations that have been generated with other apps and overlay them in your project (import as GeoJSON).

Features

Field and Farm project organization
Organize your projects around the industry standard of Field and Farm, and include key information such as crop type and crop variety, etc.

Fast mapping
Generate high-resolution Ortho mosaics and RGB composites, directly after flying. Offline and local.

Rig relative calibration
Optional recalculation of the rig relatives to improve band alignment for supported multispectral cameras.

Field boundary editor
Create your own field boundary, or import an existing one, and trim other layers based on the boundary.

Index generator
Automatically generate predefined indices (BNDVI, GNDVI, LCI, MCARI, NDRE, NDVI, SIPI2, TGI or VARI).

Index calculator
Create your own custom indices by inputting an index formula, save and reuse with Data Sync.

Zonation tool
Create custom zones based on information from vegetation index maps using the normal or high quality level and between 2 and 7 classes.

Prescription tool
Create comprehensive application rate maps for a more targeted input with the prescription tool.

Comparison tool
Compare different maps side-by-side using split or double screen.

Annotations tool
Annotate crop focus areas, add descriptions and attach images for additional context.

Measurement tool
Measurement tools to quickly measure distances and areas for analysis in the field.

Radiometric correction
Create Ortho mosaics / indices acquired during different weather conditions comparable.

Data synchronization
Synchronize your projects between multiple devices, so you can work with them on different computers and / or tablets.

PDF report generator
Share your maps with all project stakeholders for seamless collaboration using the PDF report export tool.

Export tool
Select some or all layers in your project and export them into a predefined folder on your computer.

Share to John Deere Operations Center
Share directly to your John Deere Operations Center outputs from Pix4Dfields including Ortho mosaics, vegetation indices and zonation maps.

Outputs

Ortho mosaic
A visual map of your field for crop scouting and assessment, set the desired output size (megapixel) and quality (GSD) (export as geoTIFF).

Digital surface model
A map for indicating more detail about irrigation variability and pinpointing erosion prone areas (export as geoTIFF).

Vegetation index maps
A map which helps indicate plant stress areas and can assist with crop protection and crop production workflows (export as geoTIFF).

Zonation maps
A map that translates information from the vegetation index maps into a more operational layer (export as Shapefile, KML or GeoJSON).

Prescription maps
A zonation map where each of the zones has a value for the Variable Rate Application (export as Shapefile, KML or GeoJSON).

Field boundaries
Field boundaries help focus analysis to only your areas of interest (export as Shapefile, KML or GeoJSON).

Annotations
Adding annotations to areas of interest helps convey more valuable and actionable information (export as GeoJSON).

PDF report
A report that aggregates all the information in your project for easy sharing (export as PDF).

Language Options
Application features and functionality now available in English, German, Japanese and Spanish.

- Educational Licenses -

Precision agriculture mapping software for high efficiency and productivity
Actionable data and insights from drone imagery for crop analysis and digital farming. Create accurate maps in minutes and identify issues using calibrated multispectral or full resolution RGB images. Share your data via PIX4Dcloud or a PDF report.

The leading photogrammetry software for schools, universities, and research

Elevate education and academic research with photogrammetry

Demonstrate
Use Pix4D's easy-to-understand and intuitive solutions to demonstrate the principles of photogrammetry and 3D modelling.

Teach
Enhance your curriculum or design your courses with the help of our extensive knowledge base, online training materials, and tutorial videos.

Research
Advance your research with Pix4D's cutting-edge solutions in mapping and photogrammetry.
