Portkeys LH5P Specifications

Basic Parameters

Basic Parameters

Jump to...
  • Display Size

    5.5" (13.97cm)

  • Display Resolution

    1920 x 1080

  • Maximum Brightness

    1700 nit

  • Contrast Ratio

    1000:1

  • Display Technology

    WELD

  • Touchscreen

    Yes

  • Bit-Depth

    10 bit (8+2 FRC)

  • HDMI Input

    Yes
    It supports a signal up to DCI 4K (4096 x2160) at 24fps or HD video at up to 60fps.

  • HDMI Output

    Yes: DCI 4K at 24fps or HD video at up to 60fps.

  • Headphone Jack

    Yes: 3.5mm jack

  • 3D LUT Support

    Yes

  • Monitoring Tools

    Yes

  • Powering

    Sony NP-F Battery

  • Other Power Inputs

    Yes: 5-pin aviation power input/output port.

  • Power Output

    Yes: 7.4V 5-pin aviation power input/output port,

  • Camera Control

    Yes

  • Image Calibration

    Yes: In-factory calibrated and can be re-calibrated with an optional Xrite i1 Display Pro prob

  • Mounting Points

    1x 1/4-20" at the bottom

  • Software Functions

    3D LUT, Waveform, New Peaking, Histogram, Guides, Zebra, Check Field, Grids, Audio Meters, Tint, Touch Capability, Backlight, Adjustable Fan, Zooming, Image Flip, OSD Flip, Cross Hair, Camera Control, False Color, Anamorphicf

Supported

Jump to...
  • Supported

    Canon
    5D MARK III, 5D MARK II, 6D, 6D MARK II, 80D [MINI USB control cable]
    1DX, 1DX MARK II, 5DS, 5DS R, 5D MARK IV [MICRO USB control cable]
    R5, R6, EOS R [TYPE-C (USB-C) control cable)]
    C70, C700 PL, C700 GSPL, C300 MARK 2, C300 MARK 2 PL, C200, C200B, C100, C100 MARK 2 [LANC control cable]

    REC key (LANC control cable)

Interface

Jump to...
  • Video Input/Output

    Input Interface: 4KP30 HDMI
    Output Interface: 4KP30 HDMI

  • Support Battery Model

    Sony NP-F 970 / F960 /F750 / F550

  • 5-pin Aviation Connector Power I/O

    7-24V power supply or batterycan be used to power LH5P

  • USB-A

    Upgrade Firmware, Load 3D LUT.
    It can output5V2A voltage, and power to otherdevices while using NPF 7.4Vbattery.

  • Audio Output

    3.5mm Headphone Jack

Battery

Jump to...
  • Battery Info

    Required, not included

  • Battery Material

    Lithium-Ion

  • Battery Type

    Non-Universal

  • Battery Quantity

    1

  • UPC Code

    5059718989164

About Portkeys LH5P

Why settle for less when you can have the best The LH5P 5.5" Full HD Touchscreen Monitor is a sleek, high-tech, and compact device designed specifically for select Canon cameras. This multifunctional monitor supports 4K HDMI, ensuring you get the highest quality video output. With a resolution of 1920 x 1080, you can expect crystal clear images every time.

The LH5P is not just a monitor, it's a control center for your camera. The integrated camera controller offers a range of controls such as record, shutter, focus, and more, depending on the capabilities of your Canon camera. This user-friendly feature allows you to navigate your camera's settings and menus with ease, making your photography or videography experience more efficient and enjoyable.

The monitor's 1700 cd/sq. m brightness ensures optimal visibility, even in bright conditions. It's capable of inputting and outputting up to 4K30 video via HDMI, making it a versatile tool for any photographer or videographer.

For quick and easy access to your preferred settings, the LH5P features four F-keys on the top, allowing you to set presets. It also comes equipped with various monitoring tools such as waveform, histogram, false color, and vectorscope, as well as focusing aids like peaking, zoom, and markers.

The LH5P is designed with a built-in L-Series battery plate at the rear, which accepts a separately available battery or dummy battery for power. An integrated power output can also power your camera via the included cable, making it a convenient and practical addition to your Canon camera equipment.

In conclusion, the LH5P 5.5" Full HD Touchscreen Monitor with Camera Control for Canon Select Cameras is a compact, user-friendly, and high-tech device that supports 4K HDMI. It's the perfect tool for photographers and videographers seeking to enhance their Canon camera experience.

Portkeys LH5P Features

  • 5.5" HDMI 4K30 Touchscreen Monitor
  • HDMI input and output up to 4K30P
  • 1700 cd/sq. m Brightness, HDR Preview
  • Wireless Camera Control Sony A7MIII and BMPCC 4K/6K/6K Pro
  • Control camera functions such as REC, focus, iris, and more
  • 3D LUT support with custom LUTs via USB

Key Features

  • High-tech 5.5" Full HD Touchscreen Monitor, compatible with select Canon cameras
  • Supports 4K HDMI input and output for superior video quality
  • Integrated camera controller for record, shutter, focus, and more
  • Four F-keys for quick access to preset settings
  • Equipped with monitoring tools such as waveform, histogram, false color, and vectorscope
  • Built-in L-Series battery plate and integrated power output for convenient power options

What's in the box:

  • Portkeys LH5P 5.5" Full HD Touchscreen Monitor
  • Straight to Elbow DC Power Cable
  • Short Head Antenna
  • Right Angle Antenna
  • Warm Prompt
  • LANC Control Cable
  • Type-C Control Cable
  • User Manual
  • Safety Plastic Box
  • Portkeys 1 Year Limited Warranty
