Planar PCT2265 Specifications

  • Viewable Size

    21.5" diagonal (18.77" horizontal x 10.56" vertical)

  • Touchscreen Type

    Projected Capacitive

  • Number of Touch Points

    10

  • Touchscreen Interface

    USB

  • Contrast Ratio (typ)

    3000:1

  • Viewing Angle (typ)

    178 Degree H,V

  • Response Time (typ)

    18 ms

  • Brightness

    With Touchscreen: 225 cd/sq. m
    Without Touchscreen: 250 cd/sq. m

  • Display Type

    Edge-Lit LED LCD

  • Display Resolution

    1920 x 1080

  • Aspect Ratio

    16:9

  • Tilt Range

    -5 Degree to +90 Degree

  • Palette

    16.7 million colors

  • Pixel Pitch

    0.2482

  • Refresh Rate

    50-76 Hz

  • Video Inputs

    Analog, HDMI, DVI-D (w/HDCP)

  • HDCP

    Yes

  • Audio Output

    2 speakers, 2W/ch

  • Compatibility

    Windows 7, 8, 10 - HID Compliant - no drivers needed for basic touchscreen operation

  • External Connections

    VGA D-Sub 15-pin, DVI 24-pin, HDMI 19-pin, USB - Type A to B, 3.5 mm audio in, AC Power In, USB 3.0 Hub (1 up, 4 down)

  • Power Supply

    Internal

  • Power Requirements

    100 to 240 VAC, 50/60Hz

  • Power Consumption (max)

    <=28W (<=.5W standby and off)

  • Operating Temperature

    32 Degree to 104 Degree F (0 Degree to +40 Degree C)

  • Humidity

    10 - 85% RH (non-condensing)

  • Mount

    Built-in 100 mm VESA, back

  • Recommended Usage

    Up to 16 hours per day

  • Options / Features

    Dual-hinge stand, built-in USB Hub -USB 3.0 (1 up, 4 down), Kensington Security Slot

  • Product Approvals

    cTUVus, CE, FCC-B, RoHS II

  • Dimensions (W x H x D)

    With Stand: 20.57 x 15.16 x 9.39" (522.4 x 385.0 x 238.5mm)
    Without Stand: 20.57 x 12.54 x 2.49" (522.4 x 318.4 x 63.2mm)
    Panel Depth: 2.49" (63.2mm)

  • Weight

    With Stand: 14.6 lbs (6.64kg)
    Without Stand: 9.5 lbs (4.31kg)

  • UPC Code

    810069810270

About Planar PCT2265

When it comes to enhancing your digital workspace with sleek design and high-tech functionality, the Helium PCT2265 21.5" 16:9 Full-HD Touchscreen LED LCD Monitor stands out as a top contender. This modern and stylish monitor boasts a vibrant 21.5-inch display with a crisp 1920 x 1080 Full HD resolution, ensuring that every image and text is displayed with stunning clarity and detail.

The Helium PCT2265 is not just about looks; it's built for interactivity and user-friendly experiences. Featuring advanced projected capacitive technology, the monitor supports up to 10 simultaneous touch points, allowing for intuitive navigation and control whether you're using your finger or a passive stylus. This responsiveness makes it perfect for a wide range of applications, from browsing the web and managing emails to engaging in graphic design and photo editing.

Optimized for the latest operating systems, the Helium PCT2265 is designed to leverage the capabilities of Microsoft Windows 10, providing seamless integration with its multi-touch functionalities. This makes it an ideal choice for businesses, small offices, home offices, or enterprise applications looking for a touch solution that enhances productivity and interaction.

The dual-hinge Helium Desk Stand is a standout feature, offering unparalleled stand flexibility. Effortlessly adjust the monitor from a passive viewing angle to an interactive touchscreen position, catering to your specific needs whether you're analyzing spreadsheets or scrolling through social media.

In terms of connectivity, the Helium PCT2265 excels with its built-in USB 3.0 hub, allowing you to connect a variety of peripherals directly to the monitor for a streamlined workspace. Additionally, the monitor is equipped with multiple video inputs, including analog, HDMI, and DVI-D, ensuring compatibility with a vast array of devices and facilitating easy integration into your existing setup.

With built-in speakers, the Helium PCT2265 offers an all-in-one audio-visual solution, eliminating the need for external speakers and reducing desk clutter. The larger 21.5" screen size provides ample space for multitasking and enjoying multimedia content, making it a superior choice for those seeking a comprehensive monitor that combines aesthetic appeal with practicality.

Upgrade your computing experience with the Helium PCT2265 21.5" Full-HD Touchscreen LED LCD Monitor, where functionality meets contemporary design for the ultimate user experience.

Planar PCT2265 Features

  • 21.5" touch screen monitor with 1920x1080 resolution
  • Smooth edge-to-edge glass surface
  • 10-point simultaneous multi-touch capability
  • Dual-hinge Helium Desk Stand
  • Supports both portrait and landscape orientation

Product Documents

User Manual

Key Features

  • 21.5-inch Full-HD touchscreen LED LCD monitor for enhanced digital workspace
  • Advanced projected capacitive technology supporting up to 10 simultaneous touch points
  • Seamless integration with Microsoft Windows 10 for optimized multi-touch functionalities
  • Adjustable dual-hinge Helium Desk Stand for versatile viewing and interaction
  • Built-in USB 3.0 hub and multiple video inputs including HDMI, DVI-D, and analog
  • Integrated speakers for all-in-one audio-visual solution and clutter-free workspace

What's in the box:

  • Helium PCT2265 21.5" 16:9 Full-HD Touchscreen LED LCD Monitor with Built-In Speakers
  • Power Cord
  • VGA Cable
  • DVI-D Cable
  • HDMI Cable
  • USB Cable
  • Audio-In Cable
  • User Guide
  • Planar 3 Year Limited Warranty
