New Arrival

Polecam Autopod Plus Dual Leg Unit Kit

SKU: PLCATP620 MFR: ATP620
Earn VIP Reward Points

Key Features

  • Experience superior stability with our 3-stage dual leg unit, perfect for professional video shoots.
  • Enjoy smooth, quiet operation thanks to the low and uniform noise level of this tripod accessory.
  • Achieve precise camera movements with variable speed control via proportional pedals for dynamic shots.
  • Support heavy camera setups with a robust 77.16 lbs (35kg) max payload in a single system configuration.
  • Benefit from wide temperature compatibility, ensuring reliable performance from 41 to 104 degrees F.
  • Easily transport and set up this lightweight 17.64 lbs (8kg) unit, enhancing portability for any location.
See More Product Details
Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Polecam ATP620 Specifications

General

General

Jump to...
  • Color

    Black

  • Voltage In

    110/230V AC via supplied switchmode PSU - 12Vdc @ 3 amp

  • Power Consumption (in standby)

    TX 2W

  • Dimensions

    6.49 x 4.13 x 2.16" (165 x 105 x 55mm)

  • Weight

    15.52 oz (440g)

  • Voltage In

    110/20V AC via supplied switchmode PSU - 24Vdc @ 8 amp

  • Power Consumption (in standby)

    Rx 1W

  • Dimensions

    6.5 x 4.13 x 2.17" (165 x 105 x 55mm)

  • Weight

    17.28 oz (490g)

Dual Leg Column

Jump to...
  • Design

    3 stage Leg unit with built in motor and mechanism

  • Standard Stroke

    26.57" (675mm)

  • Noise Level

    Low and Uniform

  • Speed

    Variable speed via proportional control pedals

  • Thrust

    700N

  • Max Payload

    When used in single system- 77.16 lbs (35kg)
    When used in double system- 55.11 lbs (25kg)

  • Working Ambient Temperature

    41 to 104 Degree F (5 to 40 Degree C)

  • Storage and Transport Temperature

    14 to 158 Degree F (-10 to 70 Degree C)

  • Dimensions

    Without V plates or base: 22.05" (560mm)

  • Weight

    Without mounting plates: 17.64 lbs (8kg)

Lightweight Base

Jump to...
  • Footprint

    25.59 x 25.59" (650 x 650mm)

  • Height

    2.76" (70mm)

  • Weight

    5.51 lbs (2.5kg)

About Polecam ATP620

Providing a "platform" which is a remotely operated programmable telescopic elevation unit for use with PTZ's, Teleprompters, Gyro remotes, Cameras, Speakers and more.

The unit can be used as a standalone system on a music stage, in a studio, in an orchestral pit, behind a goal, within a conference venue, or a remote location such as a golf course or a race track corner; providing an unobtrusive camera position - great for the spectators whilst not interfering with the artistes, musicians, the player's action, presenters or the sequence being shot.

Each AutoPod elevation unit is supplied with a universal camera mounting plate providing the ideal platform for your chosen object to be mounted to. The system also includes a set of "quick release in-line mounting and locking plates" which enables speedy power and data connections via XLR's, rapid deployment and also enables the individual units to be stacked upon each other 2 units high providing greater height to be achieved whilst maintaining a low profile.

Additionally, the supplied set of 2x "upstands" can be used to increase elevation height, these are 250mm long and can be stacked accordingly as required.

Polecam ATP620 Features

  • Remotely Operated Programmable Telescopic Elevation Unit
  • Ideal Platform for PTZ's, Cameras, Teleprompters and More
  • Stackable AutoPod Units for Quick, Low-Profile Height Extension

Key Features

  • Experience superior stability with our 3-stage dual leg unit, perfect for professional video shoots.
  • Enjoy smooth, quiet operation thanks to the low and uniform noise level of this tripod accessory.
  • Achieve precise camera movements with variable speed control via proportional pedals for dynamic shots.
  • Support heavy camera setups with a robust 77.16 lbs (35kg) max payload in a single system configuration.
  • Benefit from wide temperature compatibility, ensuring reliable performance from 41 to 104 degrees F.
  • Easily transport and set up this lightweight 17.64 lbs (8kg) unit, enhancing portability for any location.

What's in the box:

  • Lightweight Base
  • Dual Leg Column
  • Foot Pedals
  • 12 Vault Power Supply
  • TX Box
  • 24V Power Supply
  • 2x 9.8' IEC Cables with Continental Plug
  • RX Box
  • 9.8' 6 Pin XLR Cable
  • 2x Camera Plate Plus 1/4" Screws
  • Hex Keys
  • X2 20cm Riser Rods
  • 100ml Bowl and Adapter
  • Polecam 1 Year Limited Warranty
