PureLink HDTools 1x5 HDMI to HDBaseT Full HD Distribution Amplifier

SKU: PLHT150 MFR: HT-150
Earn VIP Reward Points

Key Features

  • Distribute Full HD HDMI signals to 5 displays using this reliable distribution amplifier.
  • Extend HDMI signals up to 330ft via HDBaseT, ensuring long-range, high-quality video distribution.
  • Enjoy wide compatibility with various resolutions from VGA to 1080p for versatile use.
  • Control your source device remotely with included IR emitter and receiver for seamless operation.
  • Simplify setup with this plug-and-play HDMI distribution amplifier, perfect for any application.
  • Ensure a reliable connection with HDCP compliance, preventing unauthorized content viewing.
See More Product Details
Special Order?Estimated to Ship: 08/19/2025
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$89.99

3 Year

$109.99

4 Year

$139.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

PureLink HDTools 1x5 HDMI to HDBaseT Full HD Distribution Amplifier Specifications

  • Input type

    HDMI, 1 port
    IR, 1 port

  • Output type

    HDMI, 1 port
    CATx, 4 ports
    IR, 1 port

  • Graphic Resolution

    VGA / SVGA / XGA / UXGA / WUXGA
    480i/p , 720i/p , 1080i/p

  • HDBaseT Output Distance

    230' / 70.10m with HCE II Rx
    330' / 100.59m with HTR Rx

  • HDBaseT IR Carrier Frequency

    30 - 60 KHz

  • HDBaseT IR Emitter/Receive angle

    Tx:+-30deg.
    Rx: +-55deg.

  • Distance

    16' / 4.88m (HDBaseT IR Emitter/Receive)

  • Connector type

    HDMI 19 Pin Female
    RJ 45
    3.5mm Phone Jack (for IR)
    DC Power Jack

  • Supported format

    HDMI 1.3

  • HDCP Compatible

    Yes

  • Power Supply

    DC +12V, 5.0A

  • Operating Temperature

    32deg. to 131deg.F (0deg. to 55deg.C)

  • Operating: Humidity

    10 - 80%, non-condensing

  • Storage: Temperature

    -4deg. to 158deg.F (-20deg. to 70deg.C)

  • Storage: Humidity

    5 - 95%, non-condensing

  • Dimensions (W x D x H)

    9.97 x 5.7 x 1.57" / 25.32 x 14.48 x 3.99cm

  • Weight

    1.9lbs / 0.86kg

About PureLink HDTools 1x5 HDMI to HDBaseT Full HD Distribution Amplifier

Be at the forefront of high-definition technology with the HDTools HT-150 1x5 HDMI over HDBaseT Full HD Distribution Amplifier. This state-of-the-art device offers a streamlined solution for distributing a single source to multiple displays, extending HDMI up to a remarkable 330 feet (100m) over a single category CATX cable.

The HT-150 stands out in the market with its unique feature of an additional HDMI output, enabling confidence or local monitoring, a capability not commonly found in other brands. This feature-rich device also provides immediate system analysis with status LEDs that indicate signal presence on the input and display sensing on the outputs, a diagnostic exclusive to the PureLink's HDTools line.

Experience the PureLink Advantage with the HT-150's advanced EDID management. This allows the operator to enable any of the output's EDID to communicate the signal requirements to the source device or select the internal 1080p EDID, ensuring successful operation regardless of EDID information from any of the connected displays.

The HT-150 also comes with an infrared repeater and transmitter, extending your infrared in either direction. This device is fully compatible with optional extenders like the HCE II RX, including infrared functions, allowing infrared control of remote displays, sources, or other IR devices.

Key features of the HT-150 include the ability to distribute a single source to five (5) displays, I/O Ports: 1 x HDMI IN, 1 x HDMI OUT, and 4 x CATX OUT (HDBaseT), and direct compatibility with PureLink's HDBaseT extender receivers, eliminating the need for matching transmitters. It supports uncompressed high-definition video up to 1080p@60Hz, is HDMI v1.3 with 3D support, and is HDCP compliant.

With the HT-150, you can also enjoy the convenience of a local HDMI output for in-room display, AVR, or cascading to another distribution amplifier. Experience the future of high-definition distribution with the HDTools HT-150 1x5 HDMI over HDBaseT Full HD Distribution Amplifier.

PureLink HDTools 1x5 HDMI to HDBaseT Full HD Distribution Amplifier Features

  • High-definition distribution amplifier with 1x5 HDMI over HDBaseT technology
  • Extends HDMI up to 330 feet over a single category CATX cable
  • Features additional HDMI output for confidence or local monitoring
  • Advanced EDID management for seamless communication with source devices
  • Includes infrared repeater and transmitter for extended control
  • Supports uncompressed high-definition video up to 1080p@60Hz, HDMI v1.3 with 3D support, and is HDCP compliant

Key Features

  • Distribute Full HD HDMI signals to 5 displays using this reliable distribution amplifier.
  • Extend HDMI signals up to 330ft via HDBaseT, ensuring long-range, high-quality video distribution.
  • Enjoy wide compatibility with various resolutions from VGA to 1080p for versatile use.
  • Control your source device remotely with included IR emitter and receiver for seamless operation.
  • Simplify setup with this plug-and-play HDMI distribution amplifier, perfect for any application.
  • Ensure a reliable connection with HDCP compliance, preventing unauthorized content viewing.

What's in the box:

  • PureLink HDTools 1x5 HDMI to HDBaseT Full HD Distribution Amplifier
  • IR Emitter
  • IR Receiver
  • DC 12V 4.2A Power Supply Adapter
  • User's Manual
  • PureLink 2 Year Warranty
