PureLink HDTools HT-150 1x 5 HDMI to HDBaseT Distribution Amplifier with 2x HCE II Rx Receiver

SKU: PLHT150KIT12 MFR: HT-150-KIT1-2
Earn VIP Reward Points

Key Features

  • Extend HDMI signals up to 230ft with this HDBaseT distribution amplifier for reliable video.
  • Enjoy wide compatibility, supporting VGA to WUXGA resolutions for diverse display setups.
  • This HDMI distribution amplifier is HDCP compliant, ensuring protected content plays flawlessly.
  • Use this video distribution kit for low latency signal transmission in live streaming setups.
  • Easy setup with included IR emitter and receiver for seamless remote control integration.
  • Perfect for distributing high resolution video across multiple displays with its 1x5 configuration.
See More Product Details
Special Order?Estimated to Ship: 08/17/2025
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$99.99

3 Year

$119.99

4 Year

$154.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

PureLink HDTools HT-150 Specifications

  • HT-150: Input type

    HDMI, 1 port
    IR, 1 port

  • HT-150: Output type

    HDMI, 1 port
    CATx, 4 ports
    IR, 1 port

  • HT-150: Graphic Resolution

    VGA / SVGA / XGA / UXGA / WUXGA
    480i/p , 720i/p , 1080i/p

  • HT-150: HDBaseT Output Distance

    230' / 70.10m

  • HT-150: HDBaseT IR Carrier Frequency

    30 - 60 KHz

  • HT-150: HDBaseT IR Emitter/Receive angle

    Tx:+-30 deg.
    Rx: +-55 deg.

  • HT-150: Distance

    16' / 4.88m (HDBaseT IR Emitter/Receive)

  • HT-150: Connector type

    HDMI 19 Pin Female
    RJ 45
    3.5mm Phone Jack (for IR)
    DC Power Jack

  • HT-150: Supported format

    HDMI 1.3

  • HT-150: HDCP Compliant

    Yes

  • HT-150: Power Supply

    DC +12V , 4.2A

  • HCE II Rx: Input type

    CATx (HDBaseT), 1 port
    IR, 1 port

  • HCE II Rx: Output type

    HDMI, 1 port
    IR, 1 port

  • HCE II Rx: Graphic Resolution

    VGA / SVGA / XGA / UXGA / WUXGA
    480i/p , 720i/p , 1080i/p

  • HCE II Rx: HDBaseT Distance

    230' / 70.10m

  • HCE II Rx: HDBaseT IR Carrier Frequency

    30 - 60 KHz

  • HCE II Rx: Angle

    Tx:+-30 deg.
    Rx: +-55 deg. (HDBaseT IR Emitter/Receive)

  • HTR Rx: Distance

    16' / 4.88m (HDBaseT IR Emitter/Receive)

  • HCE II Rx: Connector type

    HDMI 19 Pin Female
    RJ 45
    3.5mm Phone Jack (for IR)
    DC Power Jack

  • HCE II Rx: Supported format

    HDMI 1.4

  • HCE II Rx: HDCP Compliant

    Yes

  • HCE II Rx: Power Supply

    DC +5V , 2A

  • Operating Temperature

    32 deg. to 131 deg. F (0 deg. to 55 deg. C)

  • Operating Humidity

    10 - 80%, non-condensing

  • Storage Temperature

    -4 deg. to 158 deg. F (-20 deg. to 70 deg. C)

  • Storage Humidity

    5 - 95%, non-condensing

  • Dimensions (W x D x H)

    HT-150: 9.97 x 5.7 x 1.57" / 25.32 x 14.48 x 3.99cm
    HCE II Rx: 1.93 x 3.6 x 0.98" / 4.90 x 9.14 x 2.49cm

  • Weight

    HT-150: 1.9lbs / 0.86kg
    HCE II Rx: 0.61lbs / 0.28kg

About PureLink HDTools HT-150

Discover the power and versatility of the HDTools HT-150 1x5 HDMI over HDBaseT Distribution Amplifier. This innovative device offers a streamlined solution for distributing a single source to multiple displays, extending HDMI up to 330 feet (100 meters) over a single category CATX cable.

Experience the unique features of the HT-150, including four HDBaseT outputs for extended HDMI distribution to remote locations. An additional HDMI output provides local monitoring, setting this device apart from its competitors.

The HT-150 is part of PureLink's HDTools line, known for its advanced system analysis capabilities. With status LEDs, you can easily monitor signal presence on the input and display sensing on the outputs. This exclusive diagnostic feature is a testament to PureLink's commitment to innovation and quality.

Benefit from the PureLink Advantage with the HT-150's advanced EDID management. This feature allows operators to enable any of the output's EDID to communicate signal requirements to the source device. Alternatively, you can select the internal 1080p EDID to ensure successful operation, regardless of EDID information from connected displays.

The HT-150 also includes an infrared repeater and transmitter, enabling infrared control of remote displays, sources, or other IR devices. This device is fully compatible with optional extenders like the HCE II RX, enhancing its functionality and versatility.

Key features of the HT-150 include the ability to distribute a single source to five displays, extend a single source at 1080p up to 330 feet over a single category CATX cable, and direct compatibility with PureLink's HDBaseT extender receivers. The HT-150 supports uncompressed high definition video up to 1080p at 60Hz, is HDMI v1.3 with 3D support, and is HDCP compliant. It also offers a local HDMI output for in-room display, AVR, or cascading to another distribution amplifier.

Explore the capabilities of the HDTools HT-150 1x5 HDMI over HDBaseT Distribution Amplifier and experience the difference in your audio and video distribution needs.

PureLink HDTools HT-150 Features

  • Streamlined HDMI distribution amplifier, extending HDMI up to 330 feet over a single category CATX cable
  • Advanced system analysis capabilities with status LEDs for signal monitoring
  • Innovative EDID management for effective signal communication to the source device
  • Infrared repeater and transmitter included for remote control of displays and devices
  • Supports uncompressed high definition video up to 1080p at 60Hz, HDMI v1.3 with 3D support, and is HDCP compliant
  • Local HDMI output feature for in-room display, AVR, or cascading to another distribution amplifier

Key Features

  • Extend HDMI signals up to 230ft with this HDBaseT distribution amplifier for reliable video.
  • Enjoy wide compatibility, supporting VGA to WUXGA resolutions for diverse display setups.
  • This HDMI distribution amplifier is HDCP compliant, ensuring protected content plays flawlessly.
  • Use this video distribution kit for low latency signal transmission in live streaming setups.
  • Easy setup with included IR emitter and receiver for seamless remote control integration.
  • Perfect for distributing high resolution video across multiple displays with its 1x5 configuration.

What's in the box:

  • PureLink HT-150 1x 5 HDMI to HDBaseT Distribution Amplifier
  • 2x HCE II Rx Receiver
  • IR Emitter
  • IR Receiver
  • DC 12V 4.2A Power Supply Adapter
  • User's Manual
  • PureLink 2 Year Warranty
