Prolycht Orion 300 FS 320W Full Spectrum RGBACL LED Spotlight Kit, Ballast with Dual V-Mount Battery Plates

SKU: PLY20001 MFR: PL20001
Earn VIP Reward Points

Key Features

  • Achieve stunning color accuracy with this Prolycht LED spotlight, boasting a CRI of 96 for true-to-life hues.
  • Enjoy versatile power options; this 320W LED monolight runs on AC/DC, perfect for studio or on-location shoots.
  • Fine-tune your lighting with a wide 2000-20000K color temperature range, ideal for any creative vision.
  • Control brightness easily with the included controller, dimming from 0-100% for perfect illumination every time.
  • Create dynamic scenes using RGBACL color modes; this LED light offers unmatched color mixing capabilities.
  • Mount with ease using the 1-1/8" stud; this durable LED light is designed for fast & secure studio setup.
See More Product Details
Special Order?Estimated to Ship: 08/13/2025
Free Shipping

See Options

Qty
1

Need help? Ask our experts.

Overview
Compare
Specs
Q&A

Questions & Answers

Reviews about this item

Review Summary

Prolycht Orion 300 FS Specifications

General

General

Jump to...
  • Edition

    320 W

  • Kit Style

    1 Light Kit

Light Fixture

Jump to...
  • Number of Heads/Lights

    1

  • Display

    Yes

  • Photometrics

    55° at 3200K
    2555fc / 27,510Lux at 3.3 / 1 m (with Reflector)
    272fc / 2930Lux at 9.8 / 3m (with Reflector)
    98fc / 1060Lux at 16.4 / 5m (with Reflector)
    55° at 5600K
    2888fc / 31,090Lux at 3.3 / 1 m (with Reflector)
    304fc / 3276Lux at 9.8 / 3m (with Reflector)
    111fc / 1200Lux at 16.4 / 5m (with Reflector)

  • Color Temperature

    Bi-Color, RGBACL

  • Color Temperature Range

    2000-20000K

  • Color Modes

    RGB, Daylight, Tungsten

  • Color Rendering Index (CRI)

    CRI 96

  • Beam Angle

    15 to 55°

  • Dimmable

    Controller Included (Stepped) 0 to 100%

  • Cooling

    Fan

  • Power Source

    AC/DC

  • Max Power

    320 W

  • Input Voltage

    100 to 240 VAC, 50 / 60 Hz

Connectivity

Jump to...
  • Battery Connection

    V Mount Included

Mounting

Jump to...
  • Fixture Mount

    1x 1-1/8" Stud with 5/8" Receiver (Via Yoke Mount)

Physical Details

Jump to...
  • Dimensions

    15 x 7.9 x 5.7" / 38 x 20.1 x 14.6cm (Fixture)

Physical Dimensions

Jump to...
  • Weight

    7.1lb / 3.2kg (Power Supply/Controller)8.2lb / 3.7kg (Fixture with Yoke)

  • UPC Code

    6974152780001

About Prolycht Orion 300 FS

The Prolycht Orion 300 FS is a powerful LED spotlight that revolutionizes professional lighting with its incredible full color spectrum output. By using multiple LEDs in six colors precisely mixed together - red, green, blue, amber, cyan and lime (RGBACL) - the Hyperlight color engine at the core of the Orion 300 FS can authentically emit almost any color and accurately emulate any light source.

Paint your scene with washes of bold color, dancing flames, embers of evening light subtly focused on your subject, or flashing red and blue cop car effects - all using the Orion 300 FS. The user can quickly choose from hundreds of preset Lee or Rosco filter colors. The Orion 300 FS can also emulate the specific color signatures of dozens of light sources such as halide street lamps or cool fluorescents to match with background fixtures. Or set to any of a wide range of color temperatures and still maintain accurate, pleasing skin tones.

The output can be hard or soft and shaped with a wide variety of tools. The Orion 300 FS uses the ubiquitous Bowens-style reflector mount and Prolycht offer a comprehensive range of modifiers including a 2x Fresnel lens, projection lens with gobos, dome softbox, diffuser, lantern, barn doors and reflector. The Orion 300 FS is also compatible with a wide array of third-party modifiers.

The extreme accuracy, combined with the ability to shape and control light in a multitude of ways, offers cinematographers and gaffers remarkable new creative opportunities in a light of this size, power and cost.

The Prolycht Orion 300 FS is a powerful LED spotlight that revolutionizes professional lighting with its incredible full color spectrum output.

The six-channel RGBACL LEDs controlled by Prolychtf s unique Hyperlight color engine guarantee quality of light not achievable with LEDs until now.

The extreme accuracy, combined with the ability to shape and control light in a multitude of ways, offers cinematographers and gaffers remarkable new creative opportunities in a light of this size, power and cost.

The Hyperlight LED Engine - The future of lighting
• RGBACL Hypercolor LED Engine. (Red+Green+Blue+Amber+Cyan+Lime)
• CRI 98 TLCI 98.
• Extreme Flexbility and Accuracy.

Ultra-wide CCT range
• 2,000K to 20,000K.
• Magenta/Green adjustment.

Quiet and firm
A quiet fan and an efficient cooling system ensure the flexibility in your lighting layout. The Orion 300 FS is a quiet and reliable pal in your creation.

Seven color modes
• Individual colors
• Color wheel
• Gel
• Source matching
• Lighting Effect
• Recording
• Color picker

19+ Adjustable Dynamic Lighting Effects

All the connectivity you need
• On-board Screen
• Bluetooth
• Wi-Fi
• DMX

Chromalink App
Smooth, precise and intuitive.

Various lighting modifiers
Bowen's mount supporting more 3rd party madifiers

Multiple power options
• 220V/110V AC port
• PROLYCH V mount or AB mount batteries (2 pieces of 14.4V batteries).

Responsive Service
• We continuous publish new firmware. You can upgrade by a flash drive.
• Each Orion 300 FS has a unique ID. Register at our website and we are always here for your questions and needs.

Prolycht Orion 300 FS Features

  • Color: 2000-20,000K, CRI/TLCI: 96/98
  • 19 Special FX, Dims 0-100%, RGB Mode
  • 27 DMX Modes, 100-240V, Optional Battery
  • HSI Color Tuning, 316 Rosco/Lee Filters
  • 46 Natural/Artificial Light Sources
  • Silent, Slow, Medium, High, and Auto Fan
  • DMX, Bluetooth Control, 19 Special FX

Product Documents

User Manual

Key Features

  • Achieve stunning color accuracy with this Prolycht LED spotlight, boasting a CRI of 96 for true-to-life hues.
  • Enjoy versatile power options; this 320W LED monolight runs on AC/DC, perfect for studio or on-location shoots.
  • Fine-tune your lighting with a wide 2000-20000K color temperature range, ideal for any creative vision.
  • Control brightness easily with the included controller, dimming from 0-100% for perfect illumination every time.
  • Create dynamic scenes using RGBACL color modes; this LED light offers unmatched color mixing capabilities.
  • Mount with ease using the 1-1/8" stud; this durable LED light is designed for fast & secure studio setup.

What's in the box:

  • Prolycht Orion 300 FS 320W Full Spectrum RGBACL LED Spotlight
  • Ballast with Dual V-Mount Battery Plates
  • Reflector-Intensifier
  • Diffuser
  • Power Cord (Switched)
  • 5m Signal Cord
  • Safety Cord
  • Quick-Release Clamp
  • Wristband
  • Carry Bag with Shoulder Strap
  • QC Certificate
  • (Batteries Not Included)
  • Prolycht 1 Year Limited Warranty
