Pro Co Sound AVP1V Audio-Visual Interface Wallplate with Input Level Control, 20Hz-20kHz Frequency Response, <200 Ohms Output Impedance, Stainless Steel

SKU: PRAVP1VSTS MFR: AVP1VSTS
Earn VIP Reward Points

Key Features

  • Enjoy superior audio control with this pro audio visual interface wallplate.
  • Easily manage input levels using the convenient, calibrated input level control.
  • Achieve optimal sound with a wide 20Hz-20kHz frequency response on this unit.
  • Reduce unwanted noise with the ground-lift switch, ensuring clear audio output.
  • Connect various devices using RCA, XLR, and 1/4" jacks on the wallplate.
  • Durable stainless steel construction ensures long-lasting performance for your setup.
See More Product Details
Ships from Manufacturer?
Calculate Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

1 Year

$24.99

2 Year

$42.99

3 Year

$64.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Pro Co Sound AVP1V Specifications

  • Input Impedance

    >130 KOhms at 1kHz (line in L/R jacks, monaural source)
    4.0 KOhms (line in L/R jacks, stereo source, resistively mixed) (approx.)
    16 Ohms (Speaker Input jack) (approx.)
    Nominal source impedance is 0 Ohms. Speaker Input jack loads source with 16 ohm 5.0 watt dummy load

  • Output Impedance

    <200 Ohms at 1kHz
    Nominal load impedance is >1.0 KOhms

  • Maximum Input Level at 50 Hz for 1% THD

    26 dBv (Line In jack)
    46 dBv (Speaker In jack)

  • Frequency Response

    20Hz - 20kHz, /-.5dB at-15dBv output
    -3dB at 85 kHz (approx.)
    Speaker Input introduces 6 dB/octave attenuation above 8.0 kHz

  • Total Harmonic Distortion

    < .03% 20 Hz-20 kHz at -30 dBv output
    < .1% 30 Hz-20 kHz at -15 dBv output
    < .25% 20 Hz-20 kHz at -15 dBv output

  • Voltage Stepdown

    < 22 dB at 1.0 kHz
    Speaker Input attenuates signal by 20 dB

  • Speaker Input

    1/4" 3-conductor phone jack

  • Line Input L/R

    RCA phono jacks

  • Input Level Control

    10kW linear input level control with a 0 to 10 calibrated knob

  • Mic In

    Female 3-pin XLR-type connector

  • Hum Cancel

    Ground-lift switch, used to reduce hum and buzz by eliminating ground loops and providing proper grounding for various conditions. Breaks connection between input and output shields

  • Dimensions (W x H x D)

    4.56 x 4.56 x 1.25" / 11.58 x 11.58 x 3.17cm

  • Weight

    0.45lbs / 0.20kg

About Pro Co Sound AVP1V

Discover the Pro Co Sound AVP1V, a stylish and professional audio-visual interface wallplate that seamlessly integrates into any modern or traditional setting. Crafted from high-quality stainless steel, this durable wallplate is designed to withstand the rigors of frequent use while maintaining its sleek appearance.

The AVP1V is the perfect solution for connecting the line or speaker-level outputs from a diverse range of audio and video equipment, including movie projectors, tape and cassette recorders, and phonographs, to the microphone inputs of house public address (P.A.) systems. Its comprehensive design ensures audio interfacing and isolation with a wide frequency response of 20Hz-20kHz and low distortion, delivering high-quality sound across various applications.

Equipped with a 1/4" phone jack input, the AVP1V caters to monaural A/V equipment, including movie projectors. It includes a built-in 16-ohm, 5-watt load resistor to simulate speaker impedance, safeguarding the amplifier output stage from potential damage. Additionally, a high-frequency filter is in place to minimize hiss from older, noisy electronics.

The wallplate features a 10k© linear input level control, complete with a calibrated knob ranging from 0 to 10, allowing for precise volume adjustments. The dual RCA phono jack line inputs are resistively mixed to monaural, which is ideal for connecting CD players and cassette recorders. These inputs can also function as recording outputs for devices connected to the Speaker Input Jack.

For optimal signal integrity, the AVP1V incorporates a DBT-1 transformer that provides a floating 150-ohm output to a user-friendly screw-type barrier strip, simplifying the wiring installation process without the need for crimp-on terminals. The integrated Hum Cancel switch is a critical feature that eradicates hum and buzz caused by AC ground loops, ensuring a clean audio experience.

The wallplate also includes an independent low-impedance microphone input through a female XLR-type connector, directly wired to the output barrier strip for additional versatility.

Designed to fit any standard two-gang masonry box, the AVP1V's installation is straightforward and efficient. The wallplate's lustrous brushed finish and laser-engraved legends not only enhance its functionality but also add an element of sophistication to any space.

In summary, the Pro Co Sound AVP1V Audio-Visual Interface Wallplate is an essential tool for audio professionals and enthusiasts who demand a functional, high-quality, and aesthetically pleasing solution for interfacing and controlling audio signals within their environments.

Pro Co Sound AVP1V Features

  • Better Sound from Projectors, Computers and DVDs
  • Ideal for Churches, Meeting Rooms, and Schools
  • Output is Transformer-isolated and includes a Ground/Lift Switch
  • 16 Ohms Dummy Load Prevents Amplifier Damage
  • Stereo Line Inputs are Mixed to Mono Output
  • Independent XLR Microphone Input
  • Barrier Strip Output Connections

Warranty Information

This product has a limited warranty of 24 months.

Key Features

  • Enjoy superior audio control with this pro audio visual interface wallplate.
  • Easily manage input levels using the convenient, calibrated input level control.
  • Achieve optimal sound with a wide 20Hz-20kHz frequency response on this unit.
  • Reduce unwanted noise with the ground-lift switch, ensuring clear audio output.
  • Connect various devices using RCA, XLR, and 1/4" jacks on the wallplate.
  • Durable stainless steel construction ensures long-lasting performance for your setup.

What's in the box:

  • Pro Co Sound AVP1V Audio Visual Interface Wallplate
  • Pro Co Sound 2 Year Limited Warranty
