Pro Co Sound G1S-20 Specifications

  • Cable Type

    INST1

  • Connectors

    2 x 1/4" connector with an added shrink strain over the barrel of each connector

  • Conductor Gauge

    24

  • Conductor

    AWG Size & Stranding: 24 AWG 19 strands 36 AWG
    Material: Bare annealed copper

  • Insulation

    Material: Polyethylene
    Wall Thickness: 0.05" (1.27 mm) nominal
    Diameter: 0.12 +/-0.002" (3.05 +/-0.050 mm)

  • Shield

    Composite conductive vinyl and copper serve
    Inner Layer:
    Material: Semi-conductive PVC
    Wall Thickness: 0.01" (0.25 mm) nominal
    Diameter: 0.14" (3.56 mm) nominal

    Outer Layer:
    Material: Bare annealed copper serve
    Coverage: 70% nominal

  • Jacket

    Material: Matte PVC
    Wall Thickness: 0.05" (1.27 mm) nominal
    Diameter: 0.24 +/-0.005" (6.10 +/- 0.127 mm)

  • Outer Diameter

    0.24" (6.09mm)

  • Capacitance

    25 pF/ft at 1 kHz

  • Impedance

    Characteristic: 60 Ohms (nominal) at 1 MHz

  • DC Resistance

    23 Ohms/1,000.0' (304.8m) at 68 deg. F (20 deg. C)

  • Length

    20' (6.09m)

About Pro Co Sound G1S-20

Let your music resonate with the Pro Co Sound RapcoHorizon G1S-20 20' Neon Blue Guitar Instrument Cable, a high-quality audio accessory designed for the discerning musician. This 24 AWG guitar cable is engineered with two robust 1/4" connectors, each fortified with an innovative shrink strain relief system. This system employs a heat shrink process over the barrel of each connector, enhancing the cable's durability and longevity.

Crafted with an ultra-flexible matte PVC jacket material, this 20-foot guitar instrument cable is built to withstand the rigors of regular use while maintaining its aesthetic appeal with its vibrant neon blue color. The cable is terminated with superior, nickel-plated 1/4" connectors, promising consistent performance and excellent value over the years.

Each Pro Co Sound RapcoHorizon G1S-20 cable undergoes individual testing to ensure optimal performance and quality, providing you with a reliable and efficient solution for your audio needs. Whether you're a professional musician or an audio enthusiast, this guitar instrument cable is a valuable addition to your audio equipment collection.

Pro Co Sound G1S-20 Features

  • Hi-Z unbalanced instrument cable for interfacing instrument level gear with amplifiers (guitars, bass guitars, keyboards, and other unbalanced hi-Z signal sources)
  • Utilizing a serve shield for quiet operation, yielding maximum flexibility
  • Low capacitance cable offers an expanded frequency response
  • Matte jacket PVC material is very flexible yet durable with very low memory
  • Pure copper conductor and shield
  • Features an added shrink strain relief utilizing a heat shrink process over the barrel of each connector

Warranty Information

This product has a limited lifetime warranty.

Key Features

  • Experience superior sound quality with this Pro Co Sound 20' instrument cable.
  • Durable 24 AWG guitar cable ensures long-lasting performance for studio and stage.
  • Minimize noise and interference with excellent shielding in this instrument cable.
  • Get a reliable connection with high-quality 1/4" connectors on this guitar cable.
  • Enjoy clear audio with low capacitance, ideal for guitars and other instruments.
  • The 20-foot cable length offers flexibility for live performances and recording sessions.

What's in the box:

  • Pro Co Sound RapcoHorizon G1S-20 20' Guitar Instrument Cable
  • Pro Co Sound RapcoHorizon Lifetime Limited Warranty
