Pro Co Sound RapcoHorizon G1S-3 3' Guitar Instrument Cable, Neon Blue
See all Pro Co Sound items

Pro Co Sound G1S-3 3' 24 AWG Guitar Instrument Cable with 2x 1/4" Shrink Over Barrel Connectors, Neon Blue

SKU: PRG1S3NB

This item is no longer available.

Recommended Alternatives

Pro Co Sound EG5: Picture 1 regular
Pro Co Sound Excellines EG-5 5' 1/4" Phone to 1/4" Phone Male Instrument Cable
$11.99
Pro Co Sound BP-15: Picture 1 regular
Proco 15' 1/4" TRS-M to 1/4" TRS-M Cable
$40.36$15.00
Pro Co Sound Cloth-1: Picture 1 regular
Pro Co Sound RapcoHorizon Cloth-1 1' Concert 20 AWG Instrument Cable
$22.54
Pro Co Sound Cloth-10: Picture 1 regular
Pro Co Sound RapcoHorizon Cloth-10 10' Concert 20 AWG Instrument Cable
$32.68
See More Recommendations
Overview
Compare
Specs
Protection
Q&A

Questions & Answers

FAQ

What is the purpose of the heat shrink process on the connectors?

The heat shrink process on the connectors provides an added layer of protection, enhancing the durability and longevity of the connectors.

What material is the jacket of the cable made from?

The jacket of the cable is made from an ultra-flexible matte PVC material that provides durability and resilience.

What are the connectors on this cable made of?

The connectors on this guitar instrument cable are high-quality, nickel-plated 1/4" connectors designed for reliable and consistent sound transmission.

Is this cable suitable for professional use?

Yes, the Pro Co Sound RapcoHorizon G1S-3 3' Neon Blue Guitar Instrument Cable is suitable for both professional and amateur use. It's designed to deliver high-quality sound and is individually tested for performance and quality.

Can this cable be used with different types of musical instruments?

While specifically designed for guitars, this cable can also be used with any instrument or audio equipment that has a compatible 1/4" input or output.

Reviews about this item

Review Summary

Pro Co Sound G1S-3 Specifications

  • Cable Type

    INST1

  • Connectors

    2 x 1/4" connector with an added shrink strain over the barrel of each connector

  • Conductor Gauge

    24

  • Conductor

    AWG Size & Stranding: 24 AWG 19 strands 36 AWG
    Material: Bare annealed copper

  • Insulation

    Material: Polyethylene
    Wall Thickness: 0.05" (1.27 mm) nominal
    Diameter: 0.12 +/-0.002" (3.05 +/-0.050 mm)

  • Shield

    Composite conductive vinyl and copper serve
    Inner Layer:
    Material: Semi-conductive PVC
    Wall Thickness: 0.01" (0.25 mm) nominal
    Diameter: 0.14" (3.56 mm) nominal

    Outer Layer:
    Material: Bare annealed copper serve
    Coverage: 70% nominal

  • Jacket

    Material: Matte PVC
    Wall Thickness: 0.05" (1.27 mm) nominal
    Diameter: 0.24 +/-0.005" (6.10 +/- 0.127 mm)

  • Outer Diameter

    0.24" (6.09mm)

  • Capacitance

    25 pF/ft at 1 kHz

  • Impedance

    Characteristic: 60 Ohms (nominal) at 1 MHz

  • DC Resistance

    23 Ohms/1,000.0' (304.8m) at 68 deg. F (20 deg. C)

  • Length

    3' (0.91m)

About Pro Co Sound G1S-3

Because every detail matters when it comes to your sound, the Pro Co Sound RapcoHorizon G1S-3 3' Neon Blue Guitar Instrument Cable is meticulously designed to deliver superior audio quality. This high-performance cable features two robust 1/4" connectors, each enhanced with a shrink strain relief. This unique feature employs a heat shrink process over the barrel of each connector, ensuring maximum durability and longevity.

Constructed with an ultra-flexible matte PVC jacket material, this guitar instrument cable is not only resilient but also designed to withstand the rigors of regular use. The high-quality, nickel-plated 1/4" connectors are specifically chosen for their ability to maintain excellent performance over time, providing you with consistent, high-quality sound.

Each G1S-3 3' Neon Blue Guitar Instrument Cable is individually tested for performance and quality, ensuring that you receive a product that meets the highest standards. Whether you're a professional musician or an enthusiastic amateur, this cable is an essential component in achieving the best possible sound from your instrument.

Pro Co Sound G1S-3 Features

  • Hi-Z unbalanced instrument cable for interfacing instrument level gear with amplifiers (guitars, bass guitars, keyboards, and other unbalanced hi-Z signal sources)
  • Utilizing a serve shield for quiet operation, yielding maximum flexibility
  • Low capacitance cable offers an expanded frequency response
  • Matte jacket PVC material is very flexible yet durable with very low memory
  • Pure copper conductor and shield
  • Features an added shrink strain relief utilizing a heat shrink process over the barrel of each connector

Warranty Information

This product has a limited lifetime warranty.

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Experience superior sound with this 3' Pro Co guitar instrument cable, perfect for stage or studio.
  • Enjoy noise-free performance; our audio cable's shielding ensures pristine signal transmission every time.
  • Built for durability, this Pro Co 1/4" instrument cable features robust connectors and shrink strain relief.
  • Ideal for guitars, keyboards, and more, this versatile cable delivers consistent, high-quality audio.
  • With a 24 AWG conductor, this instrument cable provides optimal signal flow and minimal signal loss.
  • Get connected quickly with this 3-foot cable, designed for easy setup and reliable performance, gig after gig.

What's in the box:

  • Pro Co Sound RapcoHorizon G1S-3 3' Guitar Instrument Cable
  • Pro Co Sound RapcoHorizon Lifetime Limited Warranty
