44% Off

Pro Co Sound MS43A 4 Channel 3 Way Rack Mount Mic Splitter, 20Hz-20kHz Frequency Response, < 2.5dB Voltage Loss

SKU: PRMS43A MFR: MS43A
Earn VIP Reward Points

Key Features

  • Pro Co Sound MS43A: Pristine audio splitter for clear, noise-free recordings.
  • Achieve optimal gain range with this 4-channel mic splitter for studio use.
  • Ensure impedance matching for superior signal clarity and minimal signal loss.
  • Pro Co Sound splitter offers versatile connectivity for diverse audio setups.
  • Built for durability, this robust splitter guarantees long-lasting performance.
  • Rack mountable design integrates seamlessly into any professional recording environment.
See More Product Details
Ships from Manufacturer?
Calculate Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

1 Year

$39.99

2 Year

$69.99

3 Year

$79.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Pro Co Sound MS43A Specifications

  • Frequency Response

    20 Hz - 20 kHz, +/- .25% at -15 dBv output
    -3 dB at approximately 140 kHz

  • Total Harmonic Distortion

    <.03% 20 Hz - 20 kHz at -30 dBv output
    <.1% 30 Hz - 20 kHz at -15 dBv output
    <.25% 20 Hz - 20 kHz at -15 dBv output

  • Phase Response

    <-13 degrees at 20 kHz (ref. 1.0 kHz)

  • Rise Time

    <2.4 microseconds (2.0 kHz square wave, 10%-90%)

  • Voltage Loss

    <2.5 dB at 1.0 kHz

  • Input Impedance

    >570 Ohms at 1.0 kHz.570 Ohms at 10kHz.
    Nominal source impedance is 150 Ohms

  • Output Impedance

    <255 Ohms at 1.0 KHz
    <270 Ohms at 10 kHz
    Nominal output impedance is 1.0 KOhms

  • Maximum Input Level for 1% THD

    0 dBv at 20 Hz
    4 dBv at 30 Hz
    8 dBv at 50 Hz

  • Controls 1

    Mic In : Female 3-pin XLR-type connector accepts signal from low- impedance (150 Ohms nominal) microphone or similar source. Input impedance (with 1.0 KOhms loads on LOOP and both ISO OUTS): approx. 333 Ohms
    Direct : Male 3-pin XLR-type connector wired in parallel with MIC IN provides signal to feed mixer input

  • Controls 2

    ISO OUTS : Male 3-pin XLR-type connectors provide floating transformer- isolated low impedance outputs to feed mixer inputs. Recommended load impedances: 1.0 KOhms
    GND/LIFTS : GND position connects pin 1 of MIC IN/LOOP OUT to pin 1 of ISO OUT. LIFT position floats" ISO OUT. Used to reduce hum and buzz by eliminating ground loops and providing proper grounding for various conditions

  • Dimensions (D x W x H)

    4.75 x 19 x 1.75" / 12.06 x 48.26 x 4.44cm

  • Weight

    4.40lbs /1.99kg

About Pro Co Sound MS43A

Discover the pinnacle of audio signal distribution with the Pro Co Sound MS43A, a professional-grade 4 Channel 3 Way Rack Mount Mic Splitter designed to cater to the demanding needs of live performances, recording studios, and sound reinforcement systems. This durable and reliable unit is engineered to split signals from four low-impedance microphones into three distinct outputs, allowing for simultaneous connection to multiple preamplifiers from a single source.

Crafted for versatility, the MS43A excels in large sound reinforcement setups where microphones must feed not only the main PA system but also stage monitor systems and broadcast or remote recording mixers. Its robust design effectively addresses grounding issues, which can lead to noise interference and potential shock hazards. The inclusion of high-quality transformers ensures transformer isolation, minimizing the impact of EMI/RFI and ground loops, while preserving the benefits of common-mode noise rejection associated with balanced lines.

Equipped with standard 3-pin XLR-type connectors for MIC IN, DIRECT, and ISO OUT 1 and 2, the MS43A simplifies connectivity by requiring only standard microphone cables. The Pro Co MBT-2 transformer at the heart of this splitter delivers floating, low-impedance outputs with a wide, flat frequency response ranging from 20Hz to 20kHz, ensuring ultralow distortion and minimal ringing. This translates to pristine audio quality and exceptional transient response, free from degradation.

The MS43A's rugged construction features a 16 gauge steel and aluminum "Uni-box" enclosure, finished with a durable black texture powder coat and complemented by black anodized aluminum side channels. The clear control graphics on the Lexan front and back panel overlays enhance usability, while the internal design showcases transformers that are specially crafted for superior audio fidelity and unmatched noise rejection.

Mountable in any standard 19" rack, the MS43A offers a compact and expandable solution for audio splitting, combining top-tier audio performance with unparalleled isolation. Its high-quality connectors and switches are built to withstand the rigors of remote broadcast and recording operations, ensuring consistent, trouble-free service.

In summary, the Pro Co Sound MS43A is a high-quality, professional, and versatile rack mount mic splitter that stands out for its exceptional audio integrity, ease of use, and steadfast performance in any professional audio environment.

Pro Co Sound MS43A Features

  • Provides 3-way Split for Low Impedance Microphone
  • 4 Splitter Channels in Single Rack Space
  • Allows Assembly of Economical Expandable Splitting System
  • Great for Musicians' Monitoring and Recording
  • Uses Include Press Conferences and Speeches
  • Connects with Standard Microphone Cables
  • High Quality Transformer-Isolated Output
  • Rugged Pro Co Uni-Box Construction Provides Protection and EMI/RFI Shielding

Warranty Information

This product has a limited warranty of 24 months.

Key Features

  • Pro Co Sound MS43A: Pristine audio splitter for clear, noise-free recordings.
  • Achieve optimal gain range with this 4-channel mic splitter for studio use.
  • Ensure impedance matching for superior signal clarity and minimal signal loss.
  • Pro Co Sound splitter offers versatile connectivity for diverse audio setups.
  • Built for durability, this robust splitter guarantees long-lasting performance.
  • Rack mountable design integrates seamlessly into any professional recording environment.

What's in the box:

  • Pro Co Sound MS43A 4 Channel 3 Way Rack Mount Mic Splitter
  • Pro Co Sound 2 Year Limited Warranty
