Pro Co Sound SEG-10 10' StageMASTER Instrument Cable, Right-Angle- Straight 1/4"
See all Pro Co Sound items

Pro Co Sound SEGL-10 10' StageMASTER 24 AWG Instrument Cable, Right-Angle Plug to Straight 1/4" Phone Plug

SKU: PRSEGL10
Be the first to review this item

This item is no longer available.

Recommended Alternatives

Pro Co Sound Cloth-1: Picture 1 regular
Pro Co Sound RapcoHorizon Cloth-1 1' Concert 20 AWG Instrument Cable
$22.54
Pro Co Sound Cloth-10: Picture 1 regular
Pro Co Sound RapcoHorizon Cloth-10 10' Concert 20 AWG Instrument Cable
$32.68
Pro Co Sound Cloth-10: Picture 1 regular
Pro Co Sound RapcoHorizon Cloth-10 10' Concert Instrument Cable, Brown/White
$48.65$18.47
Pro Co Sound Cloth-12: Picture 1 regular
Pro Co Sound RapcoHorizon Cloth-12 12' Concert 20 AWG Instrument Cable
$35.95
See More Recommendations
Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Pro Co Sound SEGL-10 Specifications

  • Cable Length

    10' / 0.91m

  • Wire

    CS-INST.K 1-Conductor, Shielded

  • Conductor Gauge

    24 AWG / 20mm2

  • Stranding: No. Strands X AWG

    7x 32 / 7x .254mm2

  • Conductor Material

    Bare Annealed Copper

  • Connector

    Right-angle plug to straight 1/4" phone plug

  • Insulation

    .030" / 0.762mm

  • Insulation Material

    Polypropylene

  • Insulation Diameter

    .084 +/-.002" / 2.13 +/-.051mm

  • Shield

    Composite Conductive Vinyl and Copper Serve
    Inner layer:
    Material: Semi-conductive PVC
    Wall Thickness: .010" (.254 mm)
    Diameter: .104" (2.64 mm)
    Outer Layer:
    Material: Bare Annealed Copper Serve

  • Shield Coverage

    0.5

  • Jacket Material

    Matte Polyvinyl Chloride

  • Jacket Wall Thickness

    0.060" / 1.62mm

  • Outer Diameter

    0.235"+/- .005 / 5.97 +/-.127mm

  • Capacitance @ 1kHz

    30pf/ft / 98 pf/m

  • Impedance @1 MHz

    70Ohms

  • Velocity Of Propagation

    0.66

  • Nominal Conductor Resistance @20 ½C

    24 Ohms/kft / 79 Ohms/km

About Pro Co Sound SEGL-10

The Pro Co Sound SEGL-10 10' StageMASTER 24 AWG Instrument Cable (Right-Angle Plug to Straight 1/4" Phone Plug) is designed to be quiet, durable and dependable. It is hand-soldered to perfection using top quality metal 1/4" connectors and extremely low-noise cable.

Pro Co Sound SEGL-10 Features

  • Quiet, Durable and Dependable CS-INST1.K 1-conductor Shielded Audio Cable
  • Extremely Low-Noise Cable
  • Hand-Soldered with Top Quality Metal 1/4" Connectors

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Extremely Low-Noise Cable

What's in the box:

  • Pro Co Sound SEGL-10 10' StageMASTER 24 AWG Instrument Cable
  • Pro Co Sound 1 Year Limited Warranty
