Prism Sound ADA-8XR Audio Interface with 8-Channel 8C-AD Input Module, 8C-DA Output Module and 8C-AES AES3 I/O Module

SKU: PSADA8XRAES MFR: ADA-8XR-AES
Earn VIP Reward Points

Key Features

  • Experience pristine audio quality with this Prism Sound audio interface, perfect for critical listening.
  • Achieve ultra-low latency for seamless recording sessions using this digital audio interface.
  • Expand your studio's capabilities with versatile input/output options on this computer interface.
  • Enjoy rock-solid driver stability for uninterrupted performance during your most demanding projects.
  • Connect all your gear effortlessly; this audio interface offers superior connectivity for your studio.
  • Get exceptional value with this high-end audio interface, balancing price point and performance.
See More Product Details
Special Order?Estimated to Ship: 08/15/2025
Free Shipping

See Options

1

Need help? Ask our experts.

Overview
Compare
Specs
Q&A

Questions & Answers

Reviews about this item

Review Summary

Prism Sound ADA-8XR Specifications

ADA-8XR Audio Interface

ADA-8XR Audio Interface

Jump to...
  • Form Factor

    Rackmount

  • Channels of I/O

    None

  • Max Sample Rate/Resolution

    192 kHz / 24-Bit

  • Number of Mic Preamps

    None

  • Expansion Slots

    2x Analog I/O Slot
    2x Digital I/O Slot
    1x Utility Slot
    1x Internal DSP Slot

  • Analog Audio I/O

    1x Stereo RCA Balanced Output
    1x 1/4" TRS Headphone Output

  • Digital Audio I/O

    1x BNC Coaxial AES-3id / S/PDIF Output

  • Sync I/O

    1x BNC Video Sync/Word Clock Input
    1x BNC Word Clock Output
    1x XLR 3-Pin AES11 Input
    1x XLR 3-Pin AES11 Output

  • MIDI I/O

    None

  • Other I/O

    1x DE-9/DB-9 RS-232/RS-485 In/Out

  • Impedance

    RCA Outputs: 50 Ohms
    1/4" Outputs: 115 Ohms
    XLR Outputs: 110 Ohms
    BNC Sync Outputs: 75 Ohms
    XLR Mic Inputs: 110 Ohms
    BNC Sync Inputs: 75 Ohms

  • Dynamic Range

    RCA Outputs: 105 dB (-60 dBFS, 1 kHz)

  • THD+N

    RCA Outputs: -101 dB / 0.0009% (1 kHz, at -1 dBFS)

  • Channel Separation

    RCA Outputs: > 120 dB (1 kHz)

  • dBFS Reference Level

    +15 / +18 / +21 / +24 dBu = 0 dBFS (Selectable)

  • Sample Rates

    Up to 192 kHz

  • Bit Depths

    Up to 24-Bit

  • Clocking

    Accuracy: +/-25 ppm
    Jitter Suppression: > 60 dB (above 700 Hz)

  • OS Compatibility

    macOS
    Windows

  • AC Input Power

    90 to 125 VAC, 50 / 60 Hz
    180 to 250 VAC, 50 / 60 Hz

  • Power Consumption

    60W

  • Rackmount Size

    2 RU

  • Dimensions

    19 x 15.4 x 3.5" (483 x 390 x 88mm)

  • Weight

    16.5 lbs (7.5kg)

8C-AD 8-Channel Input Module

Jump to...
  • Inputs

    8x XLR 3-pin female (balanced)

  • Input Impedance

    21.005 kOhms

  • Input Range

    +5 to +24 dBu

  • Gain Accuracy

    +/-0.05 dB

  • CMRR

    60 Hz: < -100 dB
    1 kHz: < -90 dB
    20 Hz to 20 kHz: < -65 dB

  • Limiter

    Software selectable on/off

  • THD + N

    -105 dB (0.0006%) at 997 Hz, -1 dBFS

  • Dynamic Range

    112 dB at 997 Hz, -60 dBFS

  • Intermodulation Distortion (SMPTE)

    < -100 dB (60 Hz at -3 dBFS, 7 kHz at -12 dBFS)

  • Spurious

    Maximum Aharmonic Spurium: < -130 dBFS (997 Hz at -1 dBFS)

  • Frequency Response

    44.1 kHz: 5 Hz to 20.1 kHz (-0.05 dB), <1 Hz to 22 kHz (-3 dB)
    48 kHz: 5.5 Hz to 22.8 kHz (-0.05 dB), <1 Hz to 24 kHz (-3 dB)
    96 kHz: 6.1 Hz to 43.3 kHz (-0.05 dB), <1 Hz to 48 kHz (-3 dB)
    192 kHz: 6.2 Hz to 50.2 kHz (-0.05 dB), <1 Hz to 77.7 kHz (-3 dB)

  • Passband Ripple

    48/96 kHz: <0.015 dB

  • Inter-Channel Differential Phase

    <0.03 Degree

  • Channel Separation

    1 kHz: >125 dB
    20 Hz to 20 kHz: >117 dB

  • Latency

    44.1 kHz: 20 samples / 0.45 ms
    48 kHz: 20 samples / 0.42 ms
    96 kHz: 20 samples / 0.21 ms
    192 kHz: 20 samples / 0.10 ms

  • Dimensions

    7.9 x 7.1 x 1.2" (20 x 18 x 3cm)

  • Weight

    11.2 oz (317.5g)

8C-DA 8-Channel Output Module

Jump to...
  • Outputs

    8x XLR 3-pin male (balanced)

  • Output Impedance

    50 Ohms

  • Input Range

    +5 to +24 dBu in 1 dBu steps, trims in 0.05 dBu steps

  • Gain Accuracy

    +/-0.05 dB

  • Balance

    Output Balance: 54 dB

  • THD + N

    -102 dB (0.0007%) at 997 Hz, -1 dBFS

  • Dynamic Range

    108 dB at 997 Hz, -60 dBFS

  • Intermodulation Distortion (SMPTE)

    < -94 dB (60 Hz at -3 dBFS, 7 kHz at -12 dBFS)

  • Spurious

    Maximum Aharmonic Spurium: < -130 dBFS (997 Hz at -1 dBFS)

  • Frequency Response

    44.1 kHz: 5 Hz to 20.8 kHz (-0.05 dB), 1.4 Hz to 22 kHz (-3 dB)
    48 kHz: 5.1 Hz to 22.6 kHz (-0.05 dB), 1.4 Hz to 23.9 kHz (-3 dB)
    96 kHz: 5.1 Hz to 38.9 kHz (-0.05 dB), 1.4 Hz to 47.4 kHz (-3 dB)
    192 kHz: 5.2 Hz to 37.2 kHz (-0.05 dB), 1.4 Hz to 74.4 kHz (-3 dB)

  • Passband Ripple

    <0.005 dB

  • Inter-Channel Differential Phase

    <0.02 Degree

  • Channel Separation

    1 kHz: >115 dB
    20 Hz to 20 kHz: >110 dB

  • Latency

    44.1 kHz: 49.5 samples / 1.12 ms
    48 kHz: 49.5 samples / 1.03 ms
    96 kHz: 49.5 samples / 0.52 ms
    192 kHz: 49.5 samples / 0.26 ms

  • Dimensions

    7.9 x 7.1 x 1.2" (20 x 18 x 3cm)

  • Weight

    11.2 oz (317.5g)

8C-AES 8-Channel AES3 Digital I/O Module

Jump to...
  • I/O Connections

    1x DB25 female (transformer coupled)

  • Impedance

    AES3 Mode: 110 Ohms
    S/PDIF Mode: 75 Ohms

  • Output Signal Amplitude

    AES Mode: 3.2 V p-p (loaded)
    S/PDIF Mode: 0.5 V p-p (loaded)

  • Sample Rates

    Up to 192 kHz
    One-wire or two-wire (Split96) input and output modes are supported at 88.2 kHz, 96 kHz, 176.4 kHz, and 192 kHz

  • Bit Depth

    16-bit, 20-bit, 24-bit

  • Channel Support

    Consumer (S/PDIF) or professional (AES3)

  • Jitter Tolerance

    Below 200 Hz: 15 UI p-p
    Above 8 kHz: 0.5 UI p-p x1 (UI = 163 ns at 48 kHz)

  • Latency

    44.1 kHz: 34 samples / 0.77 ms
    48 kHz: 34 samples / 0.71 ms
    96 kHz: 34 samples / 0.35 ms
    192 kHz: 34 samples / 0.18 ms

  • Dimensions

    4.3 x 6.7 x 1.6" (11 x 17 x 4cm)

  • Weight

    3.2 oz (90.7kg)

  • UPC Code

    669014270696

About Prism Sound ADA-8XR

Be at the forefront of audio recording and processing with the ADA-8XR Audio Interface, a sophisticated and advanced piece of equipment from the reputable Prism Sound. This high-quality, professional audio interface is the epitome of British engineering and design, boasting over two decades of industry presence.

The ADA-8XR Audio Interface is a modular AD/DA converter, renowned for its ultra-detailed A/D and D/A conversion. This innovative feature ensures absolute sound focus, eliminating any distractions caused by coloration and allowing every subtle detail of a performance to be captured.

This audio interface is not just about superior sound quality, it's also about flexibility. Its modular design allows for an 8 input/8 output, 16 input, or 16 output converter, with digital I/O cards for AES. This makes it an ideal choice for systems requiring a larger number of channels, whether for a few high-quality conversions or a large multi-track setup.

The ADA-8XR Audio Interface also excels in clocking and synchronization. It can flawlessly serve as a master clock for your entire system, providing rock-solid stability and jitter rejection for crystal clear imaging. No external clock source can enhance the performance of the ADA-8XR.

The 8C-AD 8-Channel Analogue Line Input Module provides eight electronically-balanced analogue input channels, with variable input line-up level for each channel. Each channel also features a Prism Sound Overkiller progressive limiter, preventing the A/D converter from reaching full-scale.

The 8C-DA 8-Channel Analogue Line Output Module offers eight electronically-balanced analogue output channels, with variable output line-up level for each channel.

The 8C-AES 8-Channel AES3 Digital I/O Module provides eight channels of digital audio input and output, accommodating extended sample rates in Split96 or high-speed modes.

Ideal for producers, engineers, and songwriters, the ADA-8XR Audio Interface is perfect for recording vocals, single instruments, drums, or orchestras. It's equally adept at providing multiple outputs for external analogue summing. This audio interface is a staple in top studios worldwide and has been used in numerous film soundtracks.

In conclusion, the ADA-8XR Audio Interface is a testament to Prism Sound's no-compromise approach to audio. It's a modular, multi-channel, 24-bit 192kHz-capable format that delivers your recordings with perfect transparency. It's compatible with both Mac and PC, and its multiple input and output channels, including BNC word clock, RCA, and XLR, make it a versatile choice for any professional setting.

Prism Sound ADA-8XR Features

  • Modular Design for Flexible I/O Setups
  • Up to 24-Bit / 192 kHz Resolution
  • Versatile Clocking and Routing Options
  • Selectable Input Limiters

Product Documents

User Manual

Key Features

  • Experience pristine audio quality with this Prism Sound audio interface, perfect for critical listening.
  • Achieve ultra-low latency for seamless recording sessions using this digital audio interface.
  • Expand your studio's capabilities with versatile input/output options on this computer interface.
  • Enjoy rock-solid driver stability for uninterrupted performance during your most demanding projects.
  • Connect all your gear effortlessly; this audio interface offers superior connectivity for your studio.
  • Get exceptional value with this high-end audio interface, balancing price point and performance.

What's in the box:

  • Prism Sound ADA-8XR Audio Interface
  • 8C-AD 8-Channel Analogue to Digital Line Input Module
  • 8C-DA 8-Channel Digital to Analogue Line Output Module
  • 8C-AES 8-Channel AES3 Digital I/O Module with AES Breakout Loom
  • Power Cable
  • BNC to RCA Connector
  • 4.9' DB25 to XLR AES3 Breakout Cable
  • Prism Sound 3 Year Limited Warranty
