Prism Sound ADA-8XR Audio Interface with 8-Ch 8C-AD, 8C-DA and 8C-FW I/O Module
See all Prism Sound items

Prism Sound ADA-8XR Audio Interface with 8-Channel 8C-AD Input Module, 8C-DA Output Module and 8C-FW FireWire I/O Module

SKU: PSADA8XRFW MFR: ADA-8XR-FW
Be the first to review this itemAsk a Question
$10,499.00
OR
$875/mo suggested payments with 12‑month special financing. Learn how.
Earn VIP Reward Points

Key Features

  • Capture pristine audio with this Prism Sound interface, offering up to 192kHz resolution.
  • Experience ultra-low latency for seamless recording and mixing with this audio interface.
  • Expand your studio with 8-channel analog I/O, perfect for complex recording setups using this interface.
  • Achieve superior sound quality with the ADA-8XR, featuring high-end A/D and D/A converters.
  • Enjoy rock-solid driver stability on both macOS and Windows for worry-free audio production.
  • Integrate easily via FireWire, making this digital audio interface a versatile studio centerpiece.
See More Product Details
Special Order?Estimated to Ship: 12/04/2025
Free Shipping

See Options

1
Add to ListGet Sale Alert

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

FAQ

What is the ADA-8XR Audio Interface used for?

The ADA-8XR Audio Interface is used for professional audio recording and processing. It serves as an audio interface for connecting various types of audio devices, such as microphones, mixers, and musical instruments, to a computer or other digital audio workstation for recording, mixing, and playback.

What makes the ADA-8XR Audio Interface stand out?

The ADA-8XR Audio Interface stands out due to its high-quality A/D and D/A conversion, flexible modular design, and ability to function as a master clock for entire audio systems. It's designed to provide ultra-detailed sound capture and playback without any distracting coloration.

What are the input and output options for the ADA-8XR Audio Interface?

The ADA-8XR Audio Interface comes with an 8C-AD 8-Channel Analogue Line Input Module, an 8C-DA 8-Channel Analogue Line Output Module, and an 8C-FW FireWire I/O Module. These modules provide multiple input and output options, including 1/4" phone, BNC word clock, RCA, and XLR.

Is the ADA-8XR Audio Interface compatible with both Mac and Windows operating systems?

Yes, the ADA-8XR Audio Interface is compatible with both Mac and Windows operating systems, allowing for seamless integration into any setup.

Who would benefit from using the ADA-8XR Audio Interface?

The ADA-8XR Audio Interface is ideal for producers, engineers, and songwriters who want to produce the best results when recording, tracking & overdubbing, mixing to stereo or surround, mastering, and monitoring. It's also suitable for applications in music and sound recording, mastering, broadcast, and post-production.

Reviews about this item

Review Summary

Prism Sound ADA-8XR Specifications

ADA-8XR Audio Interface

ADA-8XR Audio Interface

Jump to...

  • Form Factor

    Rackmount

  • Channels of I/O

    None

  • Max Sample Rate/Resolution

    192 kHz / 24-Bit

  • Number of Mic Preamps

    None

  • Expansion Slots

    2x Analog I/O Slot
    2x Digital I/O Slot
    1x Utility Slot
    1x Internal DSP Slot

  • Analog Audio I/O

    1x Stereo RCA Balanced Output
    1x 1/4" TRS Headphone Output

  • Digital Audio I/O

    1x BNC Coaxial AES-3id / S/PDIF Output

  • Sync I/O

    1x BNC Video Sync/Word Clock Input
    1x BNC Word Clock Output
    1x XLR 3-Pin AES11 Input
    1x XLR 3-Pin AES11 Output

  • MIDI I/O

    None

  • Other I/O

    1x DE-9/DB-9 RS-232/RS-485 In/Out

  • Impedance

    RCA Outputs: 50 Ohms
    1/4" Outputs: 115 Ohms
    XLR Outputs: 110 Ohms
    BNC Sync Outputs: 75 Ohms
    XLR Mic Inputs: 110 Ohms
    BNC Sync Inputs: 75 Ohms

  • Dynamic Range

    RCA Outputs: 105 dB (-60 dBFS, 1 kHz)

  • THD+N

    RCA Outputs: -101 dB / 0.0009% (1 kHz, at -1 dBFS)

  • Channel Separation

    RCA Outputs: > 120 dB (1 kHz)

  • dBFS Reference Level

    +15 / +18 / +21 / +24 dBu = 0 dBFS (Selectable)

  • Sample Rates

    Up to 192 kHz

  • Bit Depths

    Up to 24-Bit

  • Clocking

    Accuracy: +/-25 ppm
    Jitter Suppression: > 60 dB (above 700 Hz)

  • OS Compatibility

    macOS
    Windows

  • AC Input Power

    90 to 125 VAC, 50 / 60 Hz
    180 to 250 VAC, 50 / 60 Hz

  • Power Consumption

    60W

  • Rackmount Size

    2 RU

  • Dimensions

    19 x 15.4 x 3.5" (483 x 390 x 88mm)

  • Weight

    16.5 lbs (7.5kg)

8C-AD 8-Channel Input Module

Jump to...

  • Inputs

    8x XLR 3-pin female (balanced)

  • Input Impedance

    21.005 kOhms

  • Input Range

    +5 to +24 dBu

  • Gain Accuracy

    +/-0.05 dB

  • CMRR

    60 Hz: < -100 dB
    1 kHz: < -90 dB
    20 Hz to 20 kHz: < -65 dB

  • Limiter

    Software selectable on/off

  • THD + N

    -105 dB (0.0006%) at 997 Hz, -1 dBFS

  • Dynamic Range

    112 dB at 997 Hz, -60 dBFS

  • Intermodulation Distortion (SMPTE)

    < -100 dB (60 Hz at -3 dBFS, 7 kHz at -12 dBFS)

  • Spurious

    Maximum Aharmonic Spurium: < -130 dBFS (997 Hz at -1 dBFS)

  • Frequency Response

    44.1 kHz: 5 Hz to 20.1 kHz (-0.05 dB), <1 Hz to 22 kHz (-3 dB)
    48 kHz: 5.5 Hz to 22.8 kHz (-0.05 dB), <1 Hz to 24 kHz (-3 dB)
    96 kHz: 6.1 Hz to 43.3 kHz (-0.05 dB), <1 Hz to 48 kHz (-3 dB)
    192 kHz: 6.2 Hz to 50.2 kHz (-0.05 dB), <1 Hz to 77.7 kHz (-3 dB)

  • Passband Ripple

    48/96 kHz: <0.015 dB

  • Inter-Channel Differential Phase

    <0.03 Degree

  • Channel Separation

    1 kHz: >125 dB
    20 Hz to 20 kHz: >117 dB

  • Latency

    44.1 kHz: 20 samples / 0.45 ms
    48 kHz: 20 samples / 0.42 ms
    96 kHz: 20 samples / 0.21 ms
    192 kHz: 20 samples / 0.10 ms

  • Dimensions

    7.9 x 7.1 x 1.2" (20 x 18 x 3cm)

  • Weight

    11.2 oz (317.5g)

8C-DA 8-Channel Output Module

Jump to...

  • Outputs

    8x XLR 3-pin male (balanced)

  • Output Impedance

    50 Ohms

  • Input Range

    +5 to +24 dBu in 1 dBu steps, trims in 0.05 dBu steps

  • Gain Accuracy

    +/-0.05 dB

  • Balance

    Output Balance: 54 dB

  • THD + N

    -102 dB (0.0007%) at 997 Hz, -1 dBFS

  • Dynamic Range

    108 dB at 997 Hz, -60 dBFS

  • Intermodulation Distortion (SMPTE)

    < -94 dB (60 Hz at -3 dBFS, 7 kHz at -12 dBFS)

  • Spurious

    Maximum Aharmonic Spurium: < -130 dBFS (997 Hz at -1 dBFS)

  • Frequency Response

    44.1 kHz: 5 Hz to 20.8 kHz (-0.05 dB), 1.4 Hz to 22 kHz (-3 dB)
    48 kHz: 5.1 Hz to 22.6 kHz (-0.05 dB), 1.4 Hz to 23.9 kHz (-3 dB)
    96 kHz: 5.1 Hz to 38.9 kHz (-0.05 dB), 1.4 Hz to 47.4 kHz (-3 dB)
    192 kHz: 5.2 Hz to 37.2 kHz (-0.05 dB), 1.4 Hz to 74.4 kHz (-3 dB)

  • Passband Ripple

    <0.005 dB

  • Inter-Channel Differential Phase

    <0.02 Degree

  • Channel Separation

    1 kHz: >115 dB
    20 Hz to 20 kHz: >110 dB

  • Latency

    44.1 kHz: 49.5 samples / 1.12 ms
    48 kHz: 49.5 samples / 1.03 ms
    96 kHz: 49.5 samples / 0.52 ms
    192 kHz: 49.5 samples / 0.26 ms

  • Dimensions

    7.9 x 7.1 x 1.2" (20 x 18 x 3cm)

  • Weight

    11.2 oz (317.5g)

8C-FW 8-Channel FireWire I/O Module

Jump to...

  • Form Factor

    Internal

  • Channels of I/O

    8 Input / 8 Output at 48/96 kHz
    4 Input / 4 Output at 176.4/192 kHz

  • Max Sample Rate/Resolution

    192 kHz / 24-Bit

  • Number of Mic Preamps

    None

  • Analog Audio I/O

    None

  • Digital Audio I/O

    None

  • Host Connection / USB

    2x FireWire 6-Pin (FireWire 400)

  • MIDI I/O

    None

  • Sample Rates

    Up to 192 kHz

  • OS Compatibility

    macOS 10.3.7 or Later
    Windows XP or Later

  • Processor Requirement

    Mac: 700 MHz PowerPC G4
    PC:900 MHz Intel Pentium

  • RAM Requirements

    256 MB

  • Minimum Display Resolution

    800 x 600

  • Required Hardware

    Available FireWire 400 Port

  • Dimensions

    4.3 x 6.7 x 1.6" (11 x 17 x 4cm)

  • Weight

    3.2 oz (90.7kg)

Other

Jump to...

  • UPC Code

    669014270726

About Prism Sound ADA-8XR

Make your audio recording and processing more sophisticated and professional with the ADA-8XR Audio Interface. This advanced piece of equipment, designed and engineered in Britain, is a testament to Prism Sound's commitment to uncompromising audio quality.

The ADA-8XR Audio Interface is a modular AD/DA converter that has been the cornerstone of audio performance in world-renowned recording facilities like Metropolis and British Grove. Its high-quality conversion capabilities have been utilized in high-profile projects such as Star Wars and Lord of the Rings.

This innovative audio interface offers ultra-detailed A/D and D/A conversion, allowing every nuance of a performance to be heard without any distracting coloration. Its modular design offers the flexibility of having an 8 input/8 output, 16 input, or 16 output converter, with digital I/O cards for FireWire.

The ADA-8XR is not just an audio interface; it also serves as a master clock for your entire system, providing rock-solid stability and jitter rejection for crystal clear imaging. It supports different sample rates being sent and received simultaneously, making it a versatile tool for any audio setup.

This high-quality audio interface comes with an 8C-AD 8-Channel Analogue Line Input Module, an 8C-DA 8-Channel Analogue Line Output Module, and an 8C-FW FireWire I/O Module. These modules provide multiple input and output options, including 1/4" phone, BNC word clock, RCA, and XLR, and are compatible with both Mac and Windows operating systems.

Whether you're a producer, engineer, or songwriter, the ADA-8XR Audio Interface is the perfect tool for recording, tracking & overdubbing, mixing to stereo or surround, mastering, and monitoring. Its transparent conversion capabilities make it the go-to choice for the most exacting applications in music and sound recording, mastering, broadcast, and post-production.

Experience the pinnacle of audio performance with the ADA-8XR Audio Interface. Its advanced features, high-quality conversion, and professional design make it the natural choice for those seeking the best in audio recording and processing.

Prism Sound ADA-8XR Features

  • Modular Design for Flexible I/O Setups
  • Up to 24-Bit / 192 kHz Resolution
  • Versatile Clocking and Routing Options
  • Selectable Input Limiters

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

Product Documents

User Manual

Key Features

  • Capture pristine audio with this Prism Sound interface, offering up to 192kHz resolution.
  • Experience ultra-low latency for seamless recording and mixing with this audio interface.
  • Expand your studio with 8-channel analog I/O, perfect for complex recording setups using this interface.
  • Achieve superior sound quality with the ADA-8XR, featuring high-end A/D and D/A converters.
  • Enjoy rock-solid driver stability on both macOS and Windows for worry-free audio production.
  • Integrate easily via FireWire, making this digital audio interface a versatile studio centerpiece.

What's in the box:

  • Prism Sound ADA-8XR Audio Interface
  • 8C-AD 8-Channel Analogue to Digital Line Input Module
  • 8C-DA 8-Channel Digital to Analogue Line Output Module
  • 8C-FW 8-Channel FireWire I/O Module
  • Power Cable
  • BNC to RCA Connector
  • Prism Sound 3 Year Limited Warranty
