Powersoft X8 DSP+ETH 8-Channel Amplifier Platform

Powersoft X8 innovates and evolves the concept of the amplification platform through the integration of a worldwide compatible power-box and a full feature DSP inside the power amplifier.

The complete digital audio signal management system based on ARM Cortex A-8 processor and TI C6000 DSP platform heralds new and innovative level of signal processing, providing non-boolean routing and mixing, multi-stage equalization with raised-cosine, IIR and FIR filters, delay up to 4 s in input processing and 200 ms for time alignment, gain and polarity adjustment, crossover, peak limiters, TruePower limiters and Active DampingControl.

The power supply permits worldwide AC acceptance and direct connection to any regional power line configuration: it is now suitable to Single Phase, Bi-Phase or Three Phase operation from 85 VAC up to 440 VAC without the need of manual selection. True Three Phase load balancing is directly achievable by the unit without any complex load assignment in the power distribution system design.

Features

Power supply
• Advanced switch-mode power supply permitting worldwide AC acceptance and direct connection to any regional power line configuration
• Suitable to Single Phase, Bi-Phase or Three Phase operation from 85 VAC up to 440 VAC without need of manual selection
• True Three Phase load balancing is directly achievable by the unit without any complex load assignment in the power distribution system design
• Power Factor Correction PFC for extremely low mains consumption and extremely wide mains operating range
• Low Inrush Limiting reduces AC inrush current, removing the need for expensive power sequencers

Protections
Fully protected circuit design with
• Innovative operating fault protection aimed to adaptively maintain the system on its SOA by means of the active sensing of the delivered power with respect to the power drawn from the mains
• Realtime output signal measurement and processing in order to derive the actual instantaneous delivered power: all the data are collected and compared to the data about the available stored energy and the available power from the mains. This make the system is immune from any misalignment such as overvoltage, overcurrent, short circuit and so on
• Harmful signal protections: DC, VHF and clipping

General
• 6th generation fixed frequency switchmode output stage for high grade sound accuracy
• Compact size and high power density
• Modular construction allowing for rear panel customization
• AES3 digital inputs
• Two redundant Dante streams

Settings
Non-boolean channel routing
• Input signal backup policy aimed to improve reliability against signal fault
• Signal grouping for speaker routing
• Built in WiFi remote management

Monitoring
• Hardware monitor available for fast local diagnostic
• Load impedance measurement / display for each channel
• Output power measurements / display for each channel
• Mains voltage and current measurements / display

Digital Signal Processing
• TI C6000 DSP platform architecture
• AD/DA converter: dual 24bit @ 48 kHz Tandem architecture, 127 dB dynamic range, per channel
• Input/output independent equalizers per channel providing Raised-cosine, custom FIR, parametric IIR: peaking, hi/lo-shelving, all-pass, band-pass, band-stop, hi/lo-pass
• Crossovers: linear phase (FIR), hybrid (FIR-IIR), Butterworth, Linkwitz-Riley, Bessel: 6 dB/oct to 48 dB/oct (IIR)
• Input delay up to 4 s and output delay up to 200 ms for time alignment per channel
• Active DampingControl for cable compensation
• Power limiter (TruePower, RMS voltage, RMS current) + Peak Limiter

Remote management
• Control and monitoring through ArmoniaPlus
• WiFi remote management via smartphone and tablet custom interface
