Pyle PLCM4560 Rearview Backup Camera & 4.3" Monitor System Kit
See all Pyle items

Pyle PLCM4560 Rearview Backup Camera & 4.3" Monitor System Kit, Waterproof, Night Vision

SKU: PYPLCM4560
Be the first to review this item

This item is no longer available.

Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Browse our FAQ

See Terms & Conditions

Pyle PLCM4560 Specifications

Monitor

Monitor

Jump to...

  • Screen size

    4.3" TFT LCD

  • Total Pixels

    480 x 272

  • Aspect Ratio

    16:9

  • Video System

    PAL/NTSC

  • LCD Display

    ON/OFF

  • Power Consumption

    4W

Camera

Jump to...

  • Total Pixels

    656 x 492

  • Resolution

    420 TV Lines

  • Viewing Angle

    170 Degree

  • Video Output

    1.0V PP-75 Ohms

  • Power Supply

    DC 12V

General

Jump to...

  • Dimensions

    Monitor (LxWxH): 10.6 x 3.5 x 1.8" (26.92 x 8.89 x 4.57cm)
    Camera (LxWxH): 10.0 x 0.7 x 1.3" (25.40 x 1.78 x 3.30cm)

  • Weight

    Camera: 2.75 lbs (1.25kg)

About Pyle PLCM4560

System Features
• Kit Includes Rearview Mirror Monitor Assembly + Backup Camera
• Rearview Mirror Designed to Replace Existing Mirror Assembly
• Includes All Necessary Cables/Wires for Installation
• Responsive / Moving Digital Rearview Distance Scale Line
• Automatic Activation When Car is Placed in Reverse Gear
• Backup/Reverse Camera Trigger

Rearview Mirror Assembly
• 4.3" TFT LCD Display Built-into Mirror Panel
• Auto Dimming and Brightness
• Compass and Dual Temperature Display
• Ability to Connect up to (2) Video Sources
• RCA Video Connector Types

Backup Camera
• Marine Grade Camera Construction
• Waterproof & Fog Resistant (IP67 Rating)
• Low Lux Light Performance (0.2 LUX)
• Preferably Mounted Above the Rear License Plate
• Tilt Adjustable Camera Lens Angle
• 420 TVL Horizontal Resolution
• True Color Reproduction
• Auto White Balance

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

What's in the box:

  • Pyle PLCM4560 Rearview Backup Camera
  • 4.3 " Mirror Monitor
  • Mounting Hardware
  • Power & Wiring Harness
  • RCA Video Cable
  • Pyle 1 Year Limited Warranty
