Quilter Labs Immerse Reverberator Mk II Reverb Pedal

SKU: QLIMMRSATMKI

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Quilter Labs Immerse Reverberator MkII Specifications

  • Controls

    Effect Select
    Mix, from 100% dry to 100% Wet
    Reverb Depth (+Echo Repeats)

    Effect Dependent Control 1:
    Tone (Wet, Plate, Hall, Spring, Shimmer, Detune)
    Echo Time
    Hold Time (Sustain)

    Effect Dependent Control 2:
    Pre-Delay (Wet, Plate)
    Modulation (Hall, Spring, Sustain)
    Reverb-to-effect Blend (Echo, Detune, Shimmer)

  • Nominal Input Level

    -10 dBV (Instrument / Consumer Line Level)

  • Max Input Level

    7 dBV Using 9 V Power Supply

  • Input Impedance

    1.175 M Ohm (Mono), 2.35 M Ohm (Stereo)

  • Output Impedance

    500 Ohm (Mono), 1 k Ohm (Stereo)

  • Gain, Enabled vs. Bypass

    Unity

  • Frequency Response

    20 Hz-20 kHz, +/-0.5 dB, Dry Signal or Bypassed

  • Total Harmonic Distortion

    < 0.005% @ 1 kHz, Dry Signal or Bypassed, -10 dBV Input 22 Hz-22 kHz Bandwidth

  • Signal-to-Noise Ratio

    110 dBA Mono / 107 dBA Stereo, Enabled @ 50% Mix or Trails Bypass
    120 dBA, Normal Bypass

  • Input

    9-12 V DC, 80 mA

  • Connector

    Center-Negative, 5.5 mm OD x 2.1 mm ID

  • Battery Info

    Optional, not included

  • Battery Material

    Alkaline

  • Battery Type

    9-volt

  • Battery Quantity

    1

  • Dimensions (W x L x H)

    2.9 x 4.6 x 2" (73 x 117 x 51mm)

  • Weight

    8.84 oz (251g)

  • UPC Code

    741459704155

About Quilter Labs Immerse Reverberator MkII

Why settle for ordinary when you can elevate your guitar's sound with the Immerse Reverberator Mk II Reverb Pedal Quilter Labs brings you a high-quality, durable, and innovative solution for achieving studio-grade reverb effects with zero learning curve. This professional-grade pedal is designed to enhance your musical expression without overshadowing your playing style.

The Immerse Mk II is a testament to versatility, offering eight stellar stereo reverb effects that cater to a wide range of sonic preferences. Each effect is meticulously crafted to provide a unique auditory experience:

- W3T (Wet v3): Our flagship reverb algorithm now delivers a smoother, more three-dimensional sound. The adjustable pre-delay ensures your playing is complemented, not overwhelmed.
- Plate: Experience the bright and diffuse reflection of a classic studio plate reverb.
- Hall: Immerse yourself in the lush, expansive sound of a concert hall, complete with adjustable modulation depth for those deep, modulated tones.
- Spring: Relive the distinctive twang of a tube-driven spring reverb, with the added ability to adjust modulation speed for a custom vibrato-spring effect.
- Sustain: Discover the magic of our new algorithm based on the W3T reverb. This versatile effect doubles as a sustainer or infinite reverb, offering endless creative possibilities.
- Echo: A harmonious blend of the W3T reverb with a rich stereo echo, adding depth and dimension to your sound.
- Detune: Create a chorus-like effect with a detuned double of your dry signal, paired with reverb. The blend control fine-tunes the balance between detune and reverb.
- Shimmer: Synth-like textures follow your instrument's play, merging the best aspects of our previous shimmer effects for an ethereal ambiance.

Reverb truly shines in stereo, and the Immerse Mk II's stereo outputs deliver an expansive, immersive reverb experience. If you're playing through a single amp, the pedal seamlessly sums a stereo input to mono when only output 1 is connected, ensuring your sound is always full and rich.

Designed with the performing artist in mind, the Immerse Mk II is optimized for low power consumption, compatible with standard 9 V or 12 V pedal power supplies, or a 100 mA output on a brick supply. The buffered bypass feature ensures your signal chain ends with clarity, while the analog dry signal path maintains the integrity of your original tone with low noise and zero latency.

Choose the Immerse Reverberator Mk II Reverb Pedal for a durable, versatile, and innovative reverb experience that stands out in the industry. Whether in the studio or on stage, this pedal is the perfect companion for musicians seeking to add depth and character to their guitar sound.

Quilter Labs Immerse Reverberator MkII Features

  • High-quality buffered bypass, perfect for placing at the end of the signal chain
  • Trails switch
  • Kill Dry switch for parallel effect loops
  • Inputs/outputs can be used mono (#1) or stereo (#1 and #2)
  • Analog dry signal for low noise and zero latency
  • Small, pedalboard-friendly footprint
  • Requires standard 9V pedal power supply (not included)
  • Designed and manufactured in California USA

Product Documents

User Manual

Key Features

  • High-quality reverb pedal designed by reputable music equipment brand Quilter Labs
  • Offers eight versatile stereo reverb effects for a wide range of sound manipulation
  • Features unique analog-digital design for enhanced sound quality and customization
  • Low power consumption, compatible with standard 9 V or 12 V pedal power supplies
  • Buffered bypass and analog dry signal for low noise and zero latency
  • Provides both stereo and mono outputs for versatile connectivity options

What's in the box:

  • Quilter Labs Immerse Reverberator Mk II Reverb Pedal
  • (Power Supply Not Included)
  • Quilter Labs 3 Year Limited Warranty
