QNAP TVS-672X 6-Bay Desktop NAS Enclosure/iSCSI IP-SAN, Intel Core i3-8100T 4-Core 3.1GHz, 8GB RAM
SKU: QNTVS672XI38
This item is no longer available.
Recommended Alternatives
Share:
Overview
Compare
Specs
Protection
Q&A
About QNAP TVS-672X
Powered by an Intel Core i3 processor, the high-performance TVS-672X NAS features built-in 10GbE connectivity for boosted virtualization performance and streamlined backup and application workflows from multiple workstations. The TVS-672X also supports M.2 NVMe SSDs for cache acceleration, PCIe expansion, multi-cloud backup, 4K HDMI 2.0 output and real-time transcoding, alongside expandable storage capacity and feature-rich apps to perform as a cost-efficient, reliable, and multifunctional NAS solution.
• 5-speed 10GBASE-T RJ45 connectivity accelerates virtualization, intensive file access, large backup/restoration tasks, and media transfer
• Dual M.2 PCIe Gen 3 x2 NVMe SSD slots enable cache acceleration or SSD storage pools for improved performance
• PCIe expansion allows for 2.5/5/10/25GbE network cards, QM2 card, QXP storage expansion cards, or graphics cards
• 4K media playback and real-time transcoding; display multimedia content saved on the NAS via HDMI 2.0 (4K @60Hz) output
• Host multiple virtual machines and containers to run a wide range of applications and services
• A business-class backup center supporting backup/restore of cloud data and VMs (including Google Workspace, Microsoft 365, VMware and Hyper-V)
Quad-core 3.1 GHz processor with up to 64 GB memory
The TVS-672X adopts an Intel Core i3-8100T quad-core 3.1 GHz processor with dual-channel DDR4 memory (expandable to 64 GB) to tackle heavy multitasking workloads. AES-NI encryption support boosts encryption performance to secure NAS data without impacting overall system operations.
Build a budget-friendly 10GbE environment
The TVS-672X has two Gigabit ports and one 10GBASE-T Multi-Gig (10G/5G/2.5G/1G/100M) port for high-speed networking to satisfy bandwidth-demanding applications (including virtualization, massive file transfer, high-speed backup/restoration, and multimedia transmission). QNAP's managed and unmanaged 10GbE switches are a perfect match for organizations to build budget-friendly high-speed networks for productive team collaboration. The TVS-672X also include four USB 3.2 Gen 2 ports with up to 10Gb/s transfer speeds, allowing compatibility with newer, faster USB drives/expansion enclosures for transferring large media files.
Get performance benefits from SSD caching and Qtier Technology
To attain optimal I/O and reduce latency, you can configure SSD caching by using either 2.5-inch SSDs or two M.2 NVMe 2280 SSDs (sold separately) in the TVS-672X. Extra M.2 SSD slots can also be added by installing QM2 PCIe cards, allowing you to configure your M.2 SSDs in a RAID 5/6 array to achieve higher sequential speed or a read-only cache speed similar to the performance of a RAID 10 array while maintaining high storage efficiency.
SSD over-provisioning (Over-provisioning)
Add additional SSD over-provisioning to avoid write amplification and improve SSD random write speeds and endurance. You can potentially attain enterprise-grade SSD performance levels from affordable consumer-grade SSDs!
SSD cache acceleration
Enables SSD caching for increasing IOPS performance and reducing latency for storage volumes. This is perfect for IOPS-demanding applications including databases and virtualization.
Qtier for auto-tiering
Qtier Technology drives auto-tiered storage with continuous data optimization across high-performance SSDs and high-capacity HDDs based on access frequency. I/O-Aware Qtier can reserve a cache-like space in the SSD tiered to handle burst I/O in real time.
Abundant I/O capabilities with PCIe expansion
The TVS-672X has two PCIe Gen 3 slots that allow for installing various expansion cards for expanding application potential.
2.5/5/10/25GbE network cards
Enable lightning-fast throughput for bandwidth-demanding tasks (virtualization, massive data transmission, fast backup/restore).
QM2 card
Adds M.2 SSD caching or 10GbE (10GBASE-T) connectivity to the NAS for optimize performance and bandwidth.
Wireless adapter
Install a QXP-W6-AX200 Wi-Fi 6 wireless adapter to turn the TVS-672X into a wireless NAS. Or make the TVS-672X a wireless access point by installing the QWA-AC2600 wireless adapter and the WirelessAP Station app.
Graphics card
Install a low-profile, entry-level graphics card to supercharge your video editing and transcoding, or enable GPU pass-through to virtual machines.
Direct 4K HDMI output for multimedia and virtual machines
The TVS-672X features Intel UHD Graphics 630 that supports hardware decoding and real-time transcoding. The HDMI 2.0 output supports up to 4K (3840 x 2160p) @60Hz, providing great benefits for applications like video production/editing or industrial design that demands high resolution and color realism as well as intensive media storage, transfer and display. By connecting the TVS-672X to an HDMI display, you can operate virtual machines from Virtualization Station or Ubuntu Linux Station, or directly watch multimedia content saved on the NAS. QNAP's HD Station also allows users to directly enjoy multimedia using HD Player or third-party players like Plex Home Theater.
Protect your data with higher security
The TVS-672X is loaded with comprehensive security features to keep your data safe.
• QuFirewall for network security: Supports IPv6, firewall access lists, and GeoIP filtering to restrict access upon the geographical location for higher network security
• WPA2 Enterprise: Provides enterprise-grade wireless security for business networks, including certificate authority, encryption key, and enhanced encryption/decryption.
• Security Counselor: A security portal that checks for weaknesses and offers recommendations for enhancing NAS security. It also integrates anti-virus and anti-malware scanning software.
A secure file center supporting regular backups and snapshot protection
The TVS-672X provides a reliable, flexible backup and disaster recovery solution to simplify routine backup jobs cost-efficiently and with high productivity.
HBS simplifies 3-2-1 backup plans
HBS centralizes backup, restoration, and synchronization for easily backing up Windows and Mac data and transferring data in the TVS-672X to another QNAP NAS, remote server, or cloud storage space. HBS supports QuDedup technology that eliminates redundant data at the source and makes multi-version backup faster.
Snapshots multiply backup protection
Block-level snapshots are dependable data protection methods, especially in the face of growing ransomware threats. The TVS-672X supports up to 256 snapshots per volume/LUN, and up to 1,024 snapshots per NAS.
All-in-one virtual machine and container hosting solution
You can count on Virtualization Station and Container Station for comprehensive virtualization support. Coupled with the Network & Virtual Switch app that boosts interoperability between virtual machines, containers, QNAP NAS, and other networked devices, you can flexibly allocate physical and virtual network resources to simplify network deployment.
Virtualization Station
Run multiple Windows, Linux, UNIX, Android, and QuTScloud virtual machines and access them via a web browser or Virtual Network Computing (VNC). Businesses can run virtualized server applications on a single NAS without the need for additional physical servers.
Container Station
Experience LXC and Docker lightweight virtualization technologies, download apps from the built-in Docker Hub Registry, import and export containers, and create abundant microservices.
License-free VMware and Hyper-V backup appliance
With Hyper Data Protector, the TVS-672X becomes an agentless backup tool for unlimited VMware vSphere and Microsoft Hyper-V VM backup. Hyper Data Protector features incremental backup, global deduplication, backup scheduling and recovery compression. Hyper Data Protector also simultaneously backs up multiple VMs, providing you with a cost-effective and reliable disaster recovery plan, ensuring 24/7 operation of your services.
Optimized collaboration with seamless file sharing and sync
The TVS-672X centrally stores data and files, and supports SMB/CIFS, AFP and NFS protocols for file sharing across Windows, Mac, and Linux/UNIX networks. Coupled with the Qsync utility, any file uploaded to the TVS-672X will become available for all linked devices (such as computers, laptops and mobiles). You can sync shared folders and team folders for group file sharing to enhance the flexibility of team projects and collaboration. The support of Azure Active Directory Domain Services (Azure AD DS), Windows AD and LDAP services assist system administrators in managing user accounts and permissions for multiple NAS devices with greater efficiency.
Build an affordable Fibre Channel SAN environment
Common Fibre Channel Storage Area Networks (SAN) devices are often costly. By installing QNAP dual-port 16Gb/32Gb Fibre Channel expansion cards in the TVS-672X, you have more budget-friendly options to add a NAS to a SAN environment. You can set a Fibre Channel Target using the iSCSI & Fibre Channel app. Moreover, the LUN Masking and Port Binding features provide an additional layer of data security.
More productivity-boosting applications
Ubuntu Linux Station
Run Ubuntu applications (including apps from the Ubuntu Software Center) directly on the NAS and remotely access the Ubuntu desktop from a web browser.
Boxafe
Safeguard enterprise cloud data by backing up/syncing files, emails, calendars and contacts from Google Workspace and Microsoft Office 365 to the NAS.
QNAP TVS-672X Features
- Quad-core 3.1GHz processor with 8GB memory
- Build a budget-friendly 10GbE environment
- Get performance benefits from SSD caching and Qtier Technology
- Abundant I/O capabilities with PCIe expansion
- Direct 4K HDMI output for multimedia and virtual machines
- Protect your data with higher security
- A secure file center supporting regular backups and snapshot protection
- All-in-one virtual machine and container hosting solution
- License-free VMware and Hyper-V backup appliance
- Optimized collaboration with seamless file sharing and sync
- Build an affordable Fibre Channel SAN environment
- Flexible and economical storage expansion
- Switch operating systems for optimal data integrity and reliability
