Q-See 4 Channel 1080p Analog HD 4-In-1 Hybrid DVR with PIR Camera Support No HDD

SKU: QSQTH94

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Q-See QTH94 Specifications

System
  • Compression Standard

    H.264 High Profile

  • CPU

    Cortex A7

  • OS

    Embedded Linux

  • Video Input

    4x BNC

  • Resolution

    AHD/ TVI / CVI / ANALOG: 1080P, 720P, WD1 real time

  • Output

    1x HDMI: 1920 x 1080, 1x VGA: 1920 x 1080, 1x BNC: CVBS (used as the main or spot output)

  • Input

    4x RCA

  • Output

    1x RCA

  • Two-way audio

    Take up channel one audio input

  • Resolution

    1080P, 1080P lite, 720P, WD1

  • Frame Rate

    1080P: 50 fps (PAL) / 60 fps (NTSC)
    1080P Lite / 720P / WD1: 100 fps (PAL) / 120 fps (NTSC)

  • Bit Rate

    768Kbps - 8Mbps

  • Mode

    Manual, timer, motion, sensor

Playback

Jump to...
  • Playback

    4 CH

  • Search

    Time slice / time / event / tag search

  • Smart Search

    Highlighted color to display the camera record in a certain period of time, different colors refers to different record events

  • Function

    Play, pause, FF, FB, digital zoom, etc

  • Mode

    Manual, sensor, motion, exception

  • Input

    4

  • Output

    1

  • Triggering

    Record, snap, preset, e-mail, etc.

Network

Jump to...
  • Interface

    1x RJ45 10M / 100Mbps

  • Protocol

    TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP

  • Web Client

    Max 5 users online

Mobile Device

Jump to...
  • OS

    iOS, Android

  • Local Backup

    U-Disk, USB mobile HDD

  • Network Backup

    Yes

  • RS485

    1x RS485, connect to PTZ or keyboard

  • USB

    2x USB 2.0 (one in the front panel and the other in the rear panel)

  • Remote Controller

    Optional

  • Remote Monitoring

    Android, iOS, PC, Mac

  • Power Supply

    DC 12V 2A

  • Consumption

    <= 5W (without HDD)

  • Work Environment

    -10 to 50 deg. C (14 to 122 deg. F), 10% - 90% humidity

General

Jump to...
  • Dimensions (WxDxH)

    300 x 248 x 52mm (11.81 x 9.76 x 2.05")

  • UPC Code

    645439258082

About Q-See QTH94

Time to take your security needs to the next step and provide your business with the level of technology it deserves. By using our 4 Channel Analog HD 1080p DVR, you gain the ability to cover all areas and possible vulnerable spots inside and outside your business property. PIR Technology takes your motion detection to the next level by greatly reducing inaccuracies and false motion alerts to ensure your security is in the top of its class.

Larger objects are even capable of being detected such as cars, trucks and vans that can pose additional security threats to your business or property. With a recorded and live view resolution up to 1080p, never miss a detail with stunning image quality and performance! Enjoy the capability of remote monitoring when it matters the most - your personal or business-related security.

Q-See QTH94 Features

  • 1080p recording for highly-detailed, rich security footage
  • Passive Infrared Technology (PIR) - heat-sensing, motion detection provides more accurate motion alerts while triggering fewer false alarms
  • 264 Video Compression Support - Offers reduced file sizes, optimized video and bandwidth reductions. Save on data, record more video!
  • Remote Monitoring through multiple devices including: Windows/Mac, Apple Devices and Android Devices
  • Click-and-drag digital zoom in live view and playback modes
  • Easy to use and convenient front panel button controls
  • Instant backup of live video to a USB flash drive
  • Multi video outputs (HDMI/VGA/CVBS) to connect multiple displays
  • Instant notifications for motion events and Instant email alerts with snapshot attachments
  • Multi-streaming compatibility to conserve bandwidth
  • Supports QTH BNC HD/PIR Cameras and Analog Cameras

What's in the box:

  • Q-See 4 Channel 1080p Analog HD 4-In-1 Hybrid DVR
  • Power Supply
  • HDMI Cable
  • USB Mouse
  • Quick Start Guide
  • Q-See 2 Year Limited Warranty and Lifetime Online Technical Support
