Qysea 300m Underwater Quick Positioning System

SKU: QYUQPS300 MFR: QY-UQPS-300
Earn VIP Reward Points

Key Features

  • Enhance underwater drone navigation with this Qysea quick positioning system.
  • Pinpoint your underwater drone's location accurately within a 984' radius range.
  • Utilize real-time tracking for your drone, ensuring efficient underwater missions.
  • The Qysea system's acoustic technology offers unparalleled underwater positioning.
  • Achieve reliable drone recovery with precise location data from this system.
  • This underwater positioning system is compatible with FIFISH drones for seamless use.
See More Product Details
Special Order?Estimated to Ship: 12/04/2025
Free Shipping

See Options

1

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

FAQ

What is the main function of the Qysea Underwater Quick Positioning System?

The Qysea Underwater Quick Positioning System is designed to provide a real-time 3D map of the FIFISH ROV's location, record Points of Interest (POI), track three-dimensional dive paths, and return to the original location with a single click.

Can the Qysea Underwater Quick Positioning System perform reliably in different underwater conditions?

Yes, the Qysea Underwater Quick Positioning System is engineered to perform reliably amidst a variety of underwater interferences, making it a sturdy and durable solution for underwater navigation.

What features does the Qysea U-QPS-IK software offer?

The Qysea U-QPS-IK software provides a real-time display of the ROV's position, angle, depth, altitude, and distance. It also integrates with various mapping applications to display and track the ROV's movement path. Additionally, you can set POI locations at any time.

Is the Qysea Underwater Quick Positioning System suitable for underwater photography?

Yes, the Qysea Underwater Quick Positioning System is ideal for underwater photography, scuba diving, and other underwater activities. It enhances navigation capabilities and allows for detailed exploration.

Reviews about this item

Review Summary

Qysea Quick Positioning System Specifications

Topside: Electrical/Interface

Topside: Electrical/Interface

Jump to...
  • Input Voltage

    10-30 V DC

  • Power Consumption

    0.25A at 12V

  • Power On Current Surge

    2.30A at 12V

  • Communication

    Wi-Fi (802.11ac/a/b/g/n)
    Ethernet (100 Mbps)
    NMEA 0183

  • User Interface

    FIFISH App

Topside: Acoustic/Performance

Jump to...
  • Range

    984' (300m) Radius

  • Ping Rate

    2-4 Hz

  • Accuracy

    Horizontal Range: <0.2 %
    Horizontal Angle: <1 Degree
    Vertical (Depth): <1%

  • Long Term Drift

    Locator U1/P1: 1m per 6 hours

  • Frequency

    31.25 - 250 kHz (200 kHz typically)

  • Operating Principle

    Time of Flight, Triangulation

  • Integrated IMUs

    Yost Labs TSS-NANO
    TDK Invensense ICM-20948

  • Integrated GPS

    U-Blox NEO-M8T

Topside: Approval

Jump to...
  • RoHS Compliant

    Yes

  • CE Compliant

    Yes

Topside: Mechanical

Jump to...
  • Material

    Housing: Polypropylene Copolymer

  • IP Rating

    Pelican Case: IP67

  • Operating Temperature

    14 Degree F to 140 Degree F (-10 Degree C to 60 Degree C)

  • Dimensions (L x W x H)

    Pelican Case: 11.65 x 8.34 x 3.77" (29.6 x 21.2 x 9.6cm)

  • Weight

    4.4 lbs (2kg)

Antenna: Acoustic

Jump to...
  • Transducers

    4x

  • Baseline

    Triangle 38.6 x 19.3" (98 x 49cm)

  • Directivity

    Omnidirectional, 360 Degree

  • Max Range

    984' (300m) Radius

Antenna: Interface

Jump to...
  • Cable Length

    32.8' (10m) With Binder Connector (Cable Length can not be Extended)

Antenna: Approval

Jump to...
  • CE

    Yes

Antenna: Mechanical

Jump to...
  • Material

    Aluminum 6060-T6 (Tubes)
    PEEK (Transducers)
    POM (Joint Spacer)

  • Depth Rating

    984' (300m)

  • Operating Temperature

    14 Degree F to 140 Degree F (-10 Degree C to 60 Degree C)

  • Dimensions (L x W x H)

    Folded: 21.3 x 4.9 x 5.7" (54 x 12.5 x 14.5cm)
    Expanded: 59.4 x 38.6 x 21.1" (151 x 98 x 53.5cm)

  • Weight

    4.2 lbs (1.9kg)

Locator: Acoustic

Jump to...
  • Range

    Radius: 984' (300m)
    Down: 656' (200m)

  • Directivity

    Omnidirectional

Locator: Approval

Jump to...
  • RoHS Compliant

    Yes

  • CE Compliant

    Yes

Locator: Electrical/Interface

Jump to...
  • Charging Type

    USB-C

  • Charging Time

    Approx. 6 Hours

  • Indicator

    GPS Status LED (Displays: Searching, Lock, No Signal)

  • Battery Size

    3.7 Volt, 3300mAh

  • Battery Lifetime

    10 Hours

  • Battery Info

    Required, included

  • Battery Material

    Lithium ion

  • Battery Type

    Non-universal

  • Battery Quantity

    1

Locator: Mechanical

Jump to...
  • Material

    PEEK

  • Depth Rating

    984' (300m)

  • Operating Temperature

    14 Degree F to 140 Degree F (-10 Degree C to 60 Degree C)

  • Dimensions (Dia. x L)

    1.26 x 4.76" (32 x 121mm)

  • Weight

    Submerged: 2.65 oz (75g)
    Air: 6.17 oz (175g)

  • UPC Code

    711471421379

About Qysea Quick Positioning System

Overcome the challenges of underwater navigation with the Qysea Underwater Quick Positioning System (U-QPS). This innovative system is a comprehensive blend of software and hardware, designed to provide a real-time 3D map of the FIFISH ROV's location. With the U-QPS, you can record Points of Interest (POI), track three-dimensional dive paths, and even return to your original location with a single click.

Engineered to perform reliably amidst a variety of underwater interferences, the U-QPS is a sturdy and durable solution for enhancing your underwater inspection tasks and discovery missions. This high-quality system takes professional underwater exploration to a whole new level.

The Qysea U-QPS-IK software offers a range of features to improve your underwater navigation experience. It provides a real-time display of the ROV's position, angle, depth, altitude, and distance. This software also integrates with various mapping applications to display and track the ROV's movement path.

With the U-QPS, you can set POI locations at any time, track and record the ROV's movement path, and enjoy the convenience of a real-time position display. Whether you're into scuba diving, underwater photography, or other underwater activities, the Qysea Underwater Quick Positioning System is a reliable tool that enhances your underwater navigation capabilities.

Qysea Quick Positioning System Features

  • 300m Working Depth
  • 3D Underwater Map Display
  • Dive Path Recordings
  • Point of Interest (POI) Recordings
  • Real-Time Location Display

Key Features

  • Enhance underwater drone navigation with this Qysea quick positioning system.
  • Pinpoint your underwater drone's location accurately within a 984' radius range.
  • Utilize real-time tracking for your drone, ensuring efficient underwater missions.
  • The Qysea system's acoustic technology offers unparalleled underwater positioning.
  • Achieve reliable drone recovery with precise location data from this system.
  • This underwater positioning system is compatible with FIFISH drones for seamless use.

What's in the box:

  • Topside Control Box
  • Antenna
  • Locator
  • Qysea 1 Year Limited Warranty
