NEC C651Q 65" Class 4K UHD Commercial-Grade LED Monitor with Built-In Speakers, 3840x2160

SKU: NCC651Q

This item is no longer available.

Overview
Compare
Specs
Q&A

Questions & Answers

Reviews about this item

Review Summary

NEC C651Q Specifications

Display

Display

Jump to...
  • Panel Technology

    VA

  • Aspect Ratio

    16:9

  • Supported Resolutions

    DisplayPort: V1.2 (HDCP 1.3) VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60, WUXGA60, 1920 x 1080 (60Hz), 1080p, 1080i, 720p at 50Hz/60Hz, 576p at 50Hz, 480p at 60Hz, 3840 x 2160 (24Hz/30Hz/25Hz/60Hz (DisplayPort 1.2)) HDMI: (HDCP 1.4/2.2) VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60, WUXGA60, 1920 x 1080 (60Hz), 1080p, 1080i, 720p at 50Hz/60Hz, 576p at 50Hz, 480p at 60Hz, 576i at 50Hz, 480i at 60Hz, 3840 x 2160 (24Hz/30Hz/25Hz/60Hz (MODE2)), 4096 x 2160 (30Hz, 24Hz, 25Hz, 60Hz (MODE2))

  • Pixels Per Inch

    68 PPI

  • Contrast Ratio (typical)

    4000:1 (without local dimming)

  • Response Time (typical)

    8 ms

  • Orientation

    Landscape/Portrait

  • Displayable Colors

    More than 1.07 billion

  • Viewable Image Size

    65"

  • Native Resolution

    3840x2160

  • Pixel Pitch

    0.37 mm

  • Brightness (maximum)

    400 cd/m2

  • Viewing Angle (typical)

    178deg. Vert., 178deg. Hor. (89U/89D/89L/89R) at CR>10

  • Refresh Rate

    60Hz

  • Dimming Capability

    Local Dimming Capable

Synchronization Range

Jump to...
  • Horizontal (Analog/Digital)

    26kHz - 135.0kHz

Signal Compatibility/Connectivity

Jump to...
  • PC, Macintosh Signal Compatibility

    Yes

  • Input Terminals

    Digital: HDMI 2.0 (3), DisplayPort 1.2 (2)
    Audio:Audio Mini-Jack, DisplayPort Audio, HDMI Audio
    External Control: RS-232C, LAN, IR Remote

  • Output Terminals

    Digital: DisplayPort (Outputs DisplayPort1 or Option)
    Audio: Audio Mini-Jack, External Speaker Out (2), DisplayPort Audio
    External Control: LAN

  • Power Consumption (typical)

    On: 200W
    Network Standby: 2W
    Input Current: 3.4A at 100V, 1.6A at 240V
    ECO Mode Standby: 0.5W
    Power Consumption (max): 365W (255W Brightness Max)

Environmental

Jump to...
  • Temperature

    Operating: 0 to 40 deg. C (32 to 104 deg. F)
    Storage: -20 to 60 deg. C (-4 to 140 deg. F)

  • Humidity

    Operating: 20-80%
    Storage: 10-90%

  • Altitude

    Operating: 3000m (9842.40')
    Storage: 12192m (39999.51')

General

Jump to...
  • Bezel Width (Left/Right, Top/Bottom)

    0.51in. / 0.51in. ; 0.51in. / 0.51in. : 12.9mm/12.9mm, 13.1mm/13.1mm

  • VESA Hole Configuration

    400 x 400mm (M8 x 16mm)
    600 x 400mm (M8 x 16mm)

  • Additional Functions

    Raspberry Pi Compute Module Compatible
    SpectraView Engine Color Control (Including Uniformity Adjustment)
    Integrated OPS Option Slot
    Localized Dimming
    On-Screen Key Guide
    Ethernet Control and Communication
    USB Upstream/Downstream
    RS-232 Control and Communication
    CEC Communication
    HDCP 1.4 and 2.2 support through HDMI
    HDCP 1.3 support through DisplayPort
    Firmware via USB/Network
    Landscape/Portrait Capable
    Image Flip<

  • Additional Functions (Cont.)

    TileMatrix (10 x 10)
    Carbon footprint meter
    24/7 Scheduler with Real Time Clock
    Holiday Settings
    Screen saver function
    Multi-Picture Mode
    44% haze panel
    Ambient light sensor
    Screen Saver Function
    Optional Human Sensor
    Intelligent Wireless Data (Near Field Communications)
    Metal rear cabinet
    Carrying Handles
    Variable picture modes
    Advanced video settings (Noise Reduction, Adaptive Contrast)
    Input labeling
    Backlight adjust

  • Additional Functions (Cont..)

    Aspect ratio control
    Built-in 10W x 2 speakers
    Powered USB
    NaViSet Administrator Compatible
    Auto ID/IP Address Control
    Crestron RoomView Support
    AMX Beacon
    PJLInk Support
    HDMI and DisplayPort Cable Included

  • Dimensions (WxHxD)

    With stand: 57.4 x 34.2 x 23.9" (145.80 x 86.87 x 60.71cm)
    Without stand: 57.4 x 32.7 x 3.1" (145.80 x 83.06 x 7.87cm)

  • Weight

    Without stand: 89.9 lbs (40.78kg)

  • UPC Code

    805736067828

About NEC C651Q

With industry leading experience in superior design and customer focus, the 65" NEC C651Q allows for clear, detailed imagery for unobtrusive digital signage. New contemporary and slim mechanical design with focused aesthetics allows for the smooth and stylistic integration into any type of environment while the full metal chassis coupled with real-time temperature sensors and integrated cooling fans maintain the professional quality necessary for commercial environments. With a wide range of the latest connectivity interfaces including HDMI 2.0 x3 and DisplayPort 1.2 x2/daisy chain option, these displays offer the future-proofing necessary for the investment.

These displays also include expandability options such as the Open Pluggable Specification (OPS) and Raspberry Pi Compute Module slots for source integration directly into the display. The C651Q series boasts a 400 cd/m2 brightness along with a new anti-glare surface that allows for efficient readability when ambient light is present and is ideal for 24/7 signage in Retail environments as well as when used for presentation purposes in Corporate or Educational institutions.

Stylish and sleek design
Allows for easy and unobtrusive integration into any environment.

400 cd/m2 brightness
Combined with UHD resolution and new anti-reflective screen surface will capture the attention of the audience while allowing for clear visibility in higher ambient light conditions.

Future proof modular expansion
Options including the ability to integrate Open Pluggable Specification (OPS) or a Raspberry Pi Compute Modules seamlessly into the display.

SpectraView Engine
Allows for complete color, intensity, gamma or uniformity control for the ultimate imaging performance.

Integrated Media Player
Allows for audio, video or image playback via USB or SD card.

Industrial-strength, premium-grade panel
With additional thermal protection, internal temperature sensors with self-diagnostics and fan-based technology, allows for hassle-free 24/7 operation.

Full 3 year commercial warranty
To allow for peace of mind and protection of this investment.

What's in the box:

  • NEC C651Q 65 " Class 4K UHD Commercial-Grade LED Monitor with Built-In Speakers
  • Power Cord
  • 2.0m DisplayPort Cable
  • 2.0m HDMI Cable
  • Wireless Remote Control
  • Batteries
  • CD-ROM
  • Clamps
  • Screws
  • SD Card Cover
  • Eyebolt Bracket
  • Setup Manual
  • CD-ROM (Software and Documentation)
  • NEC 3 Year Parts & Labor Limited Warranty
