Ricoh D6510 65" HD LED Interactive Flat Panel Display Whiteboard

SKU: RCD6510

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Ricoh D6510 Specifications

Display Touch Panel

Display Touch Panel

Jump to...
  • Panel Size

    Diagonal: 65" wide

  • Display Type

    Liquid crystal display

  • Backlight

    LED system

  • Effective Display Area (WxH)

    56.2 x 31.6" (142.75 x 80.26cm)

  • Resolution

    Maximum: 1,920x 1,080 dpi

  • Display Color

    Maximum: Over 1.07 billion colors

  • Brightness

    Maximum: 350 cd/m2

  • Aspect Ratio

    16:9

  • Contrast Ratio

    4,000 : 1

  • Pixel Pitch

    0.744 x 0.744 mm

  • Response Speed

    8 ms (Gray to Gray, Ave.)

  • Viewing Angle HV

    178 deg./178 deg.

  • Display Orientation

    Landscape

Touch Sensor

Jump to...
  • Technology

    Shadow Sense

  • Touch Points

    Standalone: 10

  • Touch Pen Request

    >= 10 mm

  • Accuracy

    +/-6.5 mm (over 90% area)

  • Operating System

    Multi-touch (up to 10): Windows 7, 8, 8.1, 10
    Single Touch: Windows 7, Mac OS 10.6+

  • Touch Output

    USB 2.0 (Type B)

  • Cover Glass

    Pretreated anti-glare 3 mm thick

Controller

Jump to...
  • Controller Type

    Windows

  • CPU

    Intel Core i5 6500TE 2.3GHz

  • Operating Systems

    Windows 10

  • HDD

    500GB

  • RAM

    16GB

  • Interfaces

    VGA, HDMI out, Microphone in (3.5mm), Speakers out (3.5mm)

  • Network Connection

    Wired LAN: 10BASE-T/100BASET/ 1000BASE-T

Environmental

Jump to...
  • Power Consumption

    Less than 350W

  • Stand-by mode

    Less than .5W

General

Jump to...
  • Video Input

    Display unit: Mini D-SUB15pin, DisplayPort (HDCP), HDMI (HDCP), DVI-D (HDCP)

  • Video Output

    1x Displayport

  • Audio Input

    1x 3.5 mm Line in Jack (For VGA, DVI)

  • Audio Output

    Pin plugs (R+L) and terminals for 10W + 10W speakers

  • Interfaces

    1x USB 2.0 TYPE B for touch control

  • Power Source

    100 - 240V, 50/60 Hz

  • Enhanced functions

    RS232 Control Daisy Chain, Picture Mode (including Low Blue Light mode), Backlight, Adaptive Contrast (Dimming Control), Brightness, Chroma, Phase, Sharpness, Color Temperature, Treble, Bass, Balance, Volume, Mute, Speaker, Audio Source, Picture-in-Picture, Picture-by-Picture, Aspect, Adjust Screen, Touch Feature, Language, Power Save, Control Setting, Touch Control Setting, Set Monitor ID, Advanced Features, Information

  • Remote sharing function

    Up to 20 interactive whiteboards and projector systems
    Up to 50 remote devices (iPad, Android and PC)

  • Others

    Brightness will depend on input mode and other picture settings. Brightness level will decrease over time. USB with security or anti-virus software installed are not compatible. Remote sharing function requires Remote License. Remote License is required for collaborative meetings. For wall mounting, use a standard VESA 400x400 mount (not supplied by Ricoh). Via intranet, required line speed: Min. 200Kbps, recommended over 512Kbps

  • Dimensions (WxDxH)

    60.9 x 6.0 x 34.9" (154.69 x 15.24 x 88.65cm)

  • Weight

    132.3 lbs (60.01kg)

About Ricoh D6510

Work smarter with an interactive whiteboard
Empower your onsite and mobile team members, clients or customers to be more engaged with you in meetings and document collaboration with our 65" HD LED RICOH D6510 Interactive Whiteboard. Bundle the D6510 with our visual communication equipment and services for all-in-one solutions. Now, transform presentations and collaboration into modern interactive experiences that include touchscreen annotations, video and fast information sharing.

• Work on a 65" HD LED display
• Impress with 1920 x 1080 HD resolution
• Connect laptops and mobile devices
• Work in the cloud and use your preferred apps with our Windows 10 controller

Be flexible with our Windows 10-based controller
Connect your laptop or mobile device to the D6510 to use your preferred business apps and get right to work on your open documents. Or simply use the D6510's Windows 10 controller standalone and download your preferred business apps to get started, including Office 365 and Skype for Business. If you want to present and interactively collaborate with large onsite groups, bundle the D6510 with a Ricoh Digital Projector.

Deploy quickly and painlessly
Configure the D6510 interactive flat panel display with our optional mobile stand to easily move it from room to room. If you want to use the D6510 as a display, connect old or new devices via plenty of options: VGA, HDMI, DVI-D and DisplayPort. Deploy the D6510 anywhere without headaches: its intuitive UX needs little or no training. And there's no need to connect the D6510 to a server or dedicated computer requiring costly management software and mandatory maintenance.

Maximize engagement with brilliant HD
Showcase graphics and convey your ideas clearly in crisp 1920 x 1080 HD resolution to participants sitting up close and faraway. The anti-glare touchscreen with LED backlighting and deep contrast help to ensure that participants can see what is on the screen in almost any lighting conditions. Powerful 10-bit processing of more than one billion colors helps your participants notice precise details and see lifelike images.

Collaborate across your network
Add a collaborative license to our IWB Lt. software on the D6510 to enable two-way collaboration with as many as 19 additional IWBs. Each IWB can also connect to as many as 50 endpoints with two-way collaboration. That means you could distribute 20 licensed IWBs on your network for real-time collaboration and to join interactive remote meetings with up to 1,000 participants without incurring an additional public cloud service fee.

Enhance collaboration with videoconferencing
Enable face-to-face interactions with remote participants while working on shared documents by bundling the D6510 with our videoconferencing equipment. Scale videoconferencing for many participants with our optional UCS Service, which uses only 2Mbps to help avoid delays due to slow network speeds. We also offer our UCS Service Advanced, a WebRTC solution that lets participants videoconference with you from any online endpoint.

Make the most of your investment
Benefit from our expertise and 24/7 global customer support, so you can focus on competing in a smarter, faster world. Let us ensure that your collaboration technology stays ahead of trends and helps you thrive in today's economy. And we believe that relationships matter: Wherever you deploy our D6510, our extensive network and consulting services will be there to help you reach your goals.

What's in the box:

  • Ricoh D6510 65" HD LED Interactive Flat Panel Display Whiteboard
  • Ricoh 3 Year Warranty
