Roland Rubix44 Audio Interface Specifications

  • Channels

    Record: 4 channels
    Playback: 4 channels

  • Signal Processing

    Interface: 24-bit
    AD/DA conversion: 24-bit

  • Sampling Frequency

    AD/DA Conversion: 44.1, 48, 96, 192 kHz

  • Interface

    Hi-speed USB
    MIDI in/out

  • Connectors

    Input (1L, 2R, 3L, 4R) Connectors: XLR, balanced, phantom power (+48 V, 6 mA max.)
    Input (1L, 2R, 3L, 4R) Jacks: 1/4" TRS phone, balanced, input 1L and 3L supports high impedance
    Phones Jack: Stereo 1/4" phone
    Output (1L, 2R, 3L, 4R) Jacks: 1/4" TRS phone, impedance balanced
    MIDI (In/Out) connectors
    USB port: USB Type-B
    5 VDC Port: USB Micro-B

  • Controllers

    SENS 1L, 2R, 3L, 4R knobs
    Hi-Z switches
    48 V switches
    THRS knobs
    COMP/LIMIT switches
    COMP/LIMIT TYPE 1/2 switch
    COMP/LIMIT TYPE 3/4 switch
    DIRECT MONITOR 1/2 knob
    DIRECT MONITOR 3/4 knob
    MONO switches
    OUTPUTknob
    PHONESknob
    PHONES SOURCES switches
    POWER switch
    LOOPBACK switch
    GROUND LIFT switch

  • Indicators

    Level indicators (1L, 2R, 3L, 4R)
    Level indicator (COMP/LIMIT)
    POWER indicator
    Hi-Z indicators
    48 V indicators
    COMP/LIMIT indicators

  • Nominal Input Level

    Input(1L, 2R, 3L, 4R) Connectors (XLR): -60 to -12 dBu
    Input (1L, 2R, 3L, 4R) Jacks (1/4" TRS Phone): -44 to +4 dBu

  • Maximum Input Level

    Input (1L, 2R, 3L, 4R) Connectors (XLR): +2 dBu
    Input (1L, 2R, 3L, 4R) Jacks (1/4" TRS Phone): +18 dBu

  • Nominal Output Level

    Output (1L, 2R, 3L, 4R) Jacks: -6 dBu, impedance balanced

  • Maximum Output Level

    Output (1L, 2R, 3L, 4R) Jacks: +8 dBu, impedance balanced
    Phones Output: 20 mW + 20 mW / L + R, 47 Ohms load

  • Headroom

    14 dB

  • Input Impedance

    Input (1L, 2R, 3L, 4R) Connectors (XLR): 4k Ohms or greater (balanced)
    Input (1L, 2R, 3L, 4R) Jacks (1/4" TRS Phone): 15k Ohms or greater (balanced)
    Input(1L, 3L) Jack (1/4" Phone): 500k Ohms or greater when Hi-Z is turned on

  • Output Impedance

    Output (1L, 2R, 3L, 4R) Jacks: 2 kOhms, balanced
    Phones Jack: 47 Ohms

  • Residual Noise Level (IHF-A, typ.)

    Input (1L, 2R) to Output (1L, 2R): -94 dBu typ. (SENS 1L, SENS 2R knobs: min., input terminated with 600 Ohms, IHF-A, typ.)

  • Dynamic Range

    AD Block Input (1L, 2R, 3L, 4R) Jacks: 104 dB typ. (SENS 1L, SENS 2R knobs: min.)
    DA Block Output (1L, 2R, 3L, 4R) Jacks: 109 dB typ.

  • Power Supply

    AC adapter

  • Operating System

    Windows 7, 8, 8.1,10
    Mac OS X 10.10 or later
    iPad iOS 9 or later

  • Dimensions (WxDxH)

    12.2 x 6.5 x 1.8" (30.99 x 16.51 x 4.57cm)

  • Weight

    Main Unit Only: 3.9 lbs (1.77kg)

  • UPC Code

    761294508954

About Roland Rubix44 Audio Interface

4-In/4-Out, High-resolution interface for MAC, PC and iPad
Rubix44 offers a perfect balance of high-fidelity sound, solid build quality, compact size, affordable price and crucial features for today's musicians and producers. With support for high-resolution audio up to 24-bit/192kHz, Rubix44 sounds clear and defined and is carefully engineered to have extremely low noise from input to output. Its near universal USB support means it works seamlessly with Mac and PC computers and even supports iPads, for the ultimate in portable music production and performance.

• 4-in/4-out USB audio interface
• 4 low-noise mic preamps with XLR combo jacks
• Hardware compressor/limiter
• Hi-Z input for guitar and other high impedance sources
• MIDI In/Out ports
• Extensively shielded, low-noise design
• Sturdy and compact metal construction
• Big, easy-to-read indicators show vital information
• Low latency, class compliant drivers
• Ground lifts for quiet operation in a variety of venues
• Includes Ableton Live Lite

Studio-grade sound you can take anywhere
Nothing is more important than sound quality when it comes to audio interfaces. And you shouldn't have to sacrifice sound quality to have an affordable interface that you can take with you. Rubix44 sounds clean and detailed with transparent, low noise mic preamps and supports audio resolutions up 24-bit/192kHz. It's made of durable metal and a lot went into its compact, low-noise design. With all the places Rubix44 can go, you'll appreciate its extensive shielding and ground lifts, making sure you get good clean audio just about anywhere.

4 high-quality mic preamps and 4 separate outputs
Rubix44's four microphone preamps are designed for low noise and high definition. They sound clean and transparent with plenty of headroom for capturing all the impact and detail of whatever you're recording. And the flexible combo jacks mean you can easily connect a wide variety of sources without the need for adapters or special cables. Four individual outputs mean you can create more sophisticated routing and monitoring setups. This is useful for sending a click track to a performer, setting up a stage monitor or routing audio to external gear.

Hardware compressor/limiter

Highly dynamic sources like vocalists and percussion instruments often need taming, especially when recording on location. Dynamics processors help ensure a good hot signal without clipping and causing unwanted distortion. Rubix44's built-on compressor/limiter provides peace of mind in the heat of a recording session.

Big, clear level indicators

Studios and stages can be dark places and getting proper levels is critical. You want to focus on the performance, not on small, hard-to-see clip and level indicators from across the room. Rubix44 has highly visible indicators that are an integral part of its design. They clearly show if a channel has incoming signal or if you're going to overload, even from a distance.

Built for Mac, PC and iPad
Rubix44 is compact and ultra-flexible. It has low latency class compliant drivers for Mac and PC, so it's simple to get up and running with smooth, reliable audio performance. It's got plenty of inputs and outputs for growing studio setups and it also supports iPad giving you a compact system for on-location recording, on-the-go production or live performance. It even includes Ableton Live Lite, powerful studio production and live performance software that works perfectly with Rubix44, right out of the box.

What's in the box:

  • Roland Rubix44 4 In/4 Out USB Audio Interface
  • USB Cable
  • Ableton Live Lite Serial Number Card
  • Setup Guide
  • Leaflet
  • Roland 1 Year Parts and 90 Day Labor Limited Warranty
