Roland V-1SDI 4 Channel HD Video Switcher, 3x SDI Inputs, 2x HDMI Inputs

SKU: ROV1SDI MFR: V-1SDI
Earn VIP Reward Points

Key Features

  • Seamlessly switch between 3 SDI & 2 HDMI sources with this Roland video switcher.
  • Create dynamic presentations using the V-1SDI's easy-to-use video switching interface.
  • Broadcast in high quality with low latency thanks to the reliable SDI connections.
  • Enjoy wide compatibility with various cameras and devices using HDMI & SDI inputs.
  • Easily stream live events with professional transitions using this affordable switcher.
  • Enhance your video production with advanced features like audio mixing and fade effects.
See More Product Details
Special Order?Estimated to Ship: 08/17/2025
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$89.99

3 Year

$109.99

4 Year

$139.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Accessories
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

2020-08-26T12:34:41

Rated 4 out of 5

Nice Entry-Level Switcher

The Roland V-1SDI has been at work in our church video workflow for a few months now. For the most part, it is a really nice little switcher. It does insert an annoying digital audio noise, and the RCA audio jacks are not the best line input for high-quality audio coming out of our Behringer X32 board. We have since bypassed the Roland for audio input directly into the capture card. There are some function limitations that more expensive switchers allow. But if you have 2-3 cameras and a computer graphics input that need "semi-professional" output for streaming or recording, this is a nice entry-level switcher. The included "non-branded" capture card failed after 3-4 weeks. We got a nice Magewell card that works great so far.

JEFFREY E.

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Roland V-1SDI Specifications

  • Video Processing

    8-bit 4:2:2 (Y/Pb/Pr)

  • Audio Processing

    24-bit at 48 KHz

  • Input Signal Format: SDI

    Inputs 1 to 3: 1080p: 59.94/50
    1080i: 59.94/50
    720p: 59.94/50
    Conforms to SMPTE 424M (SMPTE 425M-AB), 292M, 259M-C

  • Input Signal Format: HDMI

    Input 3: 1080p: 59.94/50
    1080i: 59.94/50
    720p: 59.94/50
    HDCP supported
    Input 4:
    1080p: 59.94/50
    1080i: 59.94/50
    720p: 59.94/50
    480p: 59.94
    576p: 50
    480i: 59.94
    576i: 50
    WUXGA: 1920 x 1200 at 60 Hz
    UXGA: 1600 x 1200 at 60 Hz
    SXGA+: 1400 x 1050 at 60 Hz
    FWXGA: 1366 x 768 at 60 Hz
    SXGA: 1280 x 1024 at 60 Hz
    WXGA: 1280 x 768 at 60 Hz
    XGA: 1024 x 768 at 60 Hz
    SVGA: 800 x 600 at 60 Hz
    VGA: 640 x 480 at 60 Hz
    HDCP supported

  • Output Signal Format: Program & Preview

    SDI:
    1080p: 59.94/50
    1080i: 59.94/50
    720p: 59.94/50
    Conforms to SMPTE 424M (SMPTE 425M-AB), 292M, 259M-C

  • Output Signal Format: Multi-View

    HDMI
    HDCP supported

  • Output Signal Format: Input Level

    Audio In: -10 dBu (Maximum: +8 dBu)
    Mic: -41 to -13 dBu (Maximum: -1 dBu)

  • Output Signal Format: Output Level

    Audio Out: -10 dBu (Maximum: +8 dBu)
    Phones: 92 mW + 92 mW (32 Ohms)

  • Input Connector

    Video:
    3x SDI, BNC
    2x HDMI Type A
    Audio:
    Analog: RCA phono
    Mic: Stereo mini jack

  • Output Connector

    Program:
    1x HDMI Type A
    1x HD DB-15 type (RGB/component)
    1x BNC (composite)
    Preview:
    1x HDMI Type A
    Audio:
    Analog: RCA phono
    Headphones: Stereo mini jack

  • Remote

    USB Type B (for remote control from PC)
    RS-232: DB-9

  • Other Functions

    Memory (8 types)
    Freeze (input video captured)
    Output Fade (Audio, Video: White or Black)

  • Audio Impedance

    Input:
    Audio: 15 kOhms
    Mic: 10 kOhms
    Output:
    Audio: 1 kOhms
    Phones: 10 Ohms

  • Power Supply

    AC adapter

  • Current Draw

    2.1 A

  • Power Consumption

    25 W

  • Operating Temperature

    32 to 104 deg. F (0 to 40 deg. C)

  • Dimensions (H x W x D)

    12.3 x 4.3 x 2.3" (312.42 x 109.22 x 58.42mm)

  • Weight

    2.6lbs (1.18kg) Excluding AC adapter

  • UPC Code

    761294509357

11 Accessories for Roland V-1SDI 4 Channel HD Video Switcher, 3x SDI Inputs, 2x HDMI Inputs

  • All Accessories (11)
  • Bags & Cases (1)
  • Cables & Adapters (10)

About Roland V-1SDI

Make your video production seamless and professional with the V-1SDI 4 Channel HD Video Switcher, a high-quality and reliable solution for live events, webcasting, and videography. This durable and user-friendly switcher is designed to effortlessly connect and switch between 3G SDI cameras and playback sources, as well as a variety of HDMI inputs including cameras, smartphones, computers, tablets, and Blu-ray players.

The V-1SDI's compact and portable design ensures that professional switching results are always within reach, thanks to its intuitive hardware interface featuring a smooth T-Fader and clearly backlit buttons. With support for 3G-SDI, the V-1SDI operates at full 1080p resolution, leveraging the extended cable distance capabilities of SDI to deliver top-tier performance even in expansive venues.

Versatility is at the core of the V-1SDI, with three 3G-SDI and two HDMI inputs, complemented by two 3G-SDI and one HDMI output. This allows for a multitude of configurations, catering to all-camera setups or combinations of cameras, video sources, and computer data sources. Inputs 1 to 3 support standard video resolutions of 1080p/1080i/720p, while Input 4's scaler accommodates a broader range of video and VESA resolutions. The switcher accepts both progressive and interlaced signals, enabling simultaneous use of 1080i and 1080p signals.

For secure content, HDCP support is available for input from devices like Blu-ray disc players. The output flexibility is further enhanced with assignable SDI PVW and MULTI-VIEW outputs, supporting both SDI or HDMI input display devices.

The quad-input multi-viewer feature provides a comprehensive preview screen that displays all four input sources simultaneously, ensuring confident monitoring. Visual cues such as a red border for the current output and a green border for the next output, along with audio metering for all sources, keep you in full control.

Creative composition effects are built into the V-1SDI, including DSK (Downstream Keying), Picture-in-Picture (PinP), Split, and Quad, perfect for crafting news broadcasts or corporate presentations. The DSK function allows for the overlay of text or logos, with support for both Luminance and Chroma Keying.

A robust 14-channel digital audio mixer is included, capable of mixing stereo audio inputs from SDI or HDMI ports, line level, and mic level inputs. Each input features a delay function to sync audio with video, and the audio follow function ensures audio transitions with video. The final audio mix is embedded in the SDI and HDMI outputs and can also be directed to external devices via stereo audio output jacks.

For remote control, the V-1SDI RCS software provides detailed control over video switching, audio mixing, and settings adjustments from Mac or PC. Additionally, RS-232 serial control integration is available for A/V control systems, making the V-1SDI a versatile choice for fixed installations.

Elevate your video production capabilities with the V-1SDI 4 Channel HD Video Switcher, where flexibility, reliability, and professional results come together in one user-friendly package.

Roland V-1SDI Features

  • High-quality 4 Channel HD Video Switcher with 3x SDI and 2x HDMI inputs
  • Compact and portable design with user-friendly hardware interface and backlit buttons
  • Full 1080p resolution support with extended SDI cable distance capabilities
  • Versatile input and output configurations for various source and display devices
  • Quad-input multi-viewer for confident monitoring and professional composition effects
  • Includes 14-channel digital audio mixer with delay function and audio follow feature
  • Remote control capability with V-1SDI RCS software and RS-232 serial control integration

Warranty Information

This product has a limited warranty of 12 months.

Key Features

  • Seamlessly switch between 3 SDI & 2 HDMI sources with this Roland video switcher.
  • Create dynamic presentations using the V-1SDI's easy-to-use video switching interface.
  • Broadcast in high quality with low latency thanks to the reliable SDI connections.
  • Enjoy wide compatibility with various cameras and devices using HDMI & SDI inputs.
  • Easily stream live events with professional transitions using this affordable switcher.
  • Enhance your video production with advanced features like audio mixing and fade effects.

What's in the box:

  • Roland V-1SDI 4 Channel HD Video Switcher
  • AC Adapter
  • Power Cord
  • Cord Hook
  • Owner's Manual
  • Roland 1 Year Limited Warranty
