Schoeps CCM 2H U Omnidirectional Compact Microphone for Medium Distances, 20Hz-20kHz Frequency Range, 90Ohms Impedance, Matte Gray

SKU: SCCCM2HUG

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

FAQ

What is the frequency range of the Schoeps CCM 2H U Omnidirectional Compact Microphone?

The Schoeps CCM 2H U Omnidirectional Compact Microphone has a wide frequency range of 20Hz-20kHz, capturing the full spectrum of sound from deep bass to high treble.

What makes this microphone ideal for indoor medium distance recording?

The Schoeps CCM 2H U is designed to balance direct and reflected sound energy, delivering a linear response. This makes it ideal for indoor recordings at medium distances.

What is unique about the sound inlet of the CCM 2H U?

The sound inlet of the CCM 2H U is narrower than that of other pressure transducers, resulting in a slight acoustic response elevation above 6 kHz. This reduces high-frequency loss for diffuse sound, helping to maintain natural sound quality.

What is the impedance of the Schoeps CCM 2H U Omnidirectional Compact Microphone?

The Schoeps CCM 2H U Omnidirectional Compact Microphone has a 90Ohms impedance, ensuring a strong signal and minimal signal degradation, even over longer cable runs.

What is the color of the Schoeps CCM 2H U Omnidirectional Compact Microphone?

The Schoeps CCM 2H U Omnidirectional Compact Microphone comes in a sleek matte gray finish, combining professional-grade performance with a modern aesthetic.

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Schoeps CCM 2H U Specifications

  • Frequency range

    20 Hz - 20 kHz

  • Sensitivity

    15 mV/Pa

  • Equivalent noise level (A-weighted)

    11 dB-A

  • Equivalent noise level (CCIR)

    23 dB

  • Signal-to-noise ratio (A-weighted)

    83 dB-A

  • Maximum sound pressure level at 0.5% THD

    130 dB-SPL

  • Current consumption with 12 V

    8 mA

  • Current consumption with 48 V

    4 mA

  • Impedance

    90Ohms

  • Minimum recommended load impedance

    600Ohms

  • Low-cut frequency

    20 Hz

  • Length

    1.81 to 2.28" (46 to 58mm)

  • Diameter

    0.78" / 20mm

  • Weight

    1.16oz / 33g

About Schoeps CCM 2H U

Where precision and quality are paramount, the Schoeps CCM 2H U Omnidirectional Compact Microphone in Matte Gray stands out as an exceptional choice for indoor audio recording at medium distances. Engineered to balance direct and reflected sound energy, this microphone delivers a linear response, ensuring the most accurate sound reproduction possible.

Boasting an impressive frequency range of 20Hz-20kHz, the CCM 2H U captures the full spectrum of sound, from the deepest bass to the highest treble. This wide frequency range, coupled with its low noise level, makes it an ideal choice for demanding applications where superior sound quality is a must.

Unique to this model is its narrow sound inlet, a design feature that sets it apart from other pressure transducers. This innovative design results in a slight acoustic response elevation above 6 kHz, effectively reducing high-frequency loss for diffuse sound. This feature helps to maintain the natural quality of the sound, making the CCM 2H U an excellent choice for those seeking to capture audio in its purest form.

With a 90Ohms impedance, this compact microphone ensures a strong signal and minimal signal degradation, even over longer cable runs. Finished in a sleek matte gray, the Schoeps CCM 2H U Omnidirectional Compact Microphone combines professional-grade performance with a stylish, modern aesthetic.

Schoeps CCM 2H U Features

  • Mild high-frequency rise to compensate for losses at medium recording distance
  • Often chosen for "spaced microphone" stereo pickup and "Decca Tree" arrangements

Warranty Information

This product has a limited warranty of 24 months.

Product Documents

User Manual

Key Features

  • High-performance omnidirectional compact microphone for indoor audio recording
  • Wide 20Hz-20kHz frequency range captures full spectrum of sound
  • Low noise level ideal for demanding applications requiring superior sound quality
  • Unique narrow sound inlet design reduces high-frequency loss for diffuse sound
  • 90Ohms impedance ensures strong signal and minimal degradation over longer cable runs
  • Sleek matte gray finish combines professional-grade performance with modern aesthetic

What's in the box:

  • Schoeps CCM 2H U Omnidirectional Compact Microphone for Medium Distances
  • Schoeps 2 Year Limited Warranty
