Sennheiser SZI1029 5W Emitter Panel for Single, Dual or Multi-Channel Use, White
See all Sennheiser items

Sennheiser SZI 1029 5 Watt Emitter Panel for Single, Dual or Multi-Channel Use, White

SKU: SESZI1029W

This item is no longer available.

Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Browse our FAQ

See Terms & Conditions

Sennheiser SZI1029 Specifications

  • Impedance

    5 Kohms

  • Weight

    2.1 kg / 4.62 lbs

  • Current consumption

    350 mA / Stand-by 50 mA

  • Operating voltage

    Mains: 90-260 V, 50- 60 Hz

  • Effective radiated power

    5 W

  • IR Diodes

    132 GaAlAs

  • Maximum coverage area

    800m2

  • RF input

    BNC

  • RF output

    BNC

  • Threshold for automatic on/off function

    50 mV ( HF- Signal)

  • UPC Code

    615104040762

About Sennheiser SZI1029

The Sennheiser SZI 1029 5W White Emitter Panel is a 5-W high-power radiator for use with all wideband narrow-band modulators. The radiator is automatically switched on by the RF carrier and can cover areas of up to 800 m² in single-channel operation. High-quality GaAlAs transmitting diodes have been arranged in 12 independent groups to ensure reliable transmission. A malfunction indicator is triggered when the radiating power is reduced by more than 30 %.

Sennheiser SZI1029 Features

  • High-power radiator with a maximum coverage area of 800 m²
  • RF output for connecting additional radiators
  • Automatic on/off function
  • Versatile installation due to 5/8", 3/8" and 1/2" threads
  • Excellent reliability due to 12 independent groups of transmitting diodes and malfunction indicator

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • High-power radiator with a maximum coverage area of 800 m²
  • Versatile installation due to 5/8, 3/8 and 1/2 threads
  • Excellent reliability due to 12 independent groups of transmitting diodes & malfunction indicator
  • Automatic on/off switching by the modulator's RF carrier signal
  • 144 infrared transmitting diodes
  • RF output for cascading the RF signal to additional emitters

What's in the box:

  • Sennheiser SZI 1029 5 Watt Emitter Panel for Single & Dual or Multi-Channel Use
  • Sennheiser 2 Year Warranty
