Interchangeable lens SLR camera
Compact Flash (Type I, UDMA compatible)
23.5x15.7mm
SIGMA SA bayonet mount
SIGMA SA mount interchangeable lenses
Equivalent to approx. 1.5 times the focal length of the lens (for 35mm cameras)
X3 direct image sensor (CMOS)
Total Pixels 48MP, Effective Pixels 46MP (4,800x3,200x3 layers)
3:2
Exif 2.3, DCF 2.0
Lossless compression RAW data(12-bit, High, Medium, Low), JPEG(High, Medium, Low)
High Approx: 45 MB (4,704 x 3,136 x 3)
Medium Approx: 24 MB (3,264 x 2,176 x 3)
Low Approx: 12 MB (2,336 x 1,568 x 3)
Fine Approx: 10 MB (4,704 x 3,136)
Normal Approx: 5.6 MB (4,704 x 3,136)
Basic Approx: 4.2 MB (4,704 x 3,136)
Fine Approx: 5 MB (3,264 x 2,176)
Normal Approx: 2.7 MB (3,264 x 2,176)
Basic Approx: 2 MB (3,264 x 2,176)
Fine Approx: 2.5 MB (2,336 x 1,568)
Normal Approx: 1.4 MB (2,336 x 1,568)
Basic Approx: 1 MB (2,336 x 1,568)
High:5 frame/sec., Medium:6 frame/sec., Low:6 frame/sec
High:Max. 7 frames, Medium:Max. 14 frames, Low:Max. 14 frames
USB(USB2.0), Video Out (NTSC/PAL)
8 types (Auto, Daylight, Shade, Overcast, Incandescent, Fluorescent, Flash and Custom)
7 types (Standard, Vivid, Neutral, Portrait, Landscape, B&W, Sepia)
Pentaprism SLR viewfinder
98% vertical, 98% horizontal
0.95x (50mmF1.4)
18mm
-3.0 dpt - +1.5 dpt
TTL phase difference detection system
11 points twin cross sensor
EV -1 to +18 (ISO100)
Single AF, Continuous AF (with AF motion prediction function), Manual
Automatic Selection, Manual Selection
77 segment Evaluative Metering, Spot Metering, Center Area Metering, Center-Weighted Average Metering
EV 1 to 20 (50mm F1.4: ISO100)
[P] Program AE (Program Shift is possible),[S] Shutter Speed Priority AE,[A] Aperture Priority AE, [M] Manual
ISO100,200,400,800,1600,3200,6400
+/-3 EV (in 1/3 stop increments)
Three or Five frames (in 1/3 steps, Appropriate Exposure-Under Exposure-Over Exposure)
Electronically Controlled Focal Plane Shutter
1/8000 - 30 sec.,Bulb (up to 30 sec. With Extended Mode: 2 min.)
Hot shoe (contact X synchronization at 1/180 sec. or less, with dedicated flash linking contact)
Manual Pop-up Built-in flash, GN11 (17mm lens angle covered)
Type: TFT color LCD monitor, Monitor Size: 3.0", LCD Pixels: Approx. 460,000
Single frame display, Multi display [9 frames],Zoom, Slide Show
English / Japanese / German / French / Spanish /Italian / Chinese (Simplified) / Korean / Russian
Li-ion Battery Pack BP-21, Battery Charger BC-21,AC Adapter SAC-4 (optional)
145.5 mm x 113.5 mm x 80.0 mm/5.7" x 4.4" x 3.1"
700g /24.7oz (without battery and card)
846431045391, 085126928766, 085126583569
Professional and high-end enthusiast photographers will utilize the Sigma SD1 Merrill's exclusive Foveon 23.5x15.7mm APS-C x3 direct image sensor to capture exceptionally rich and detailed images that have a film-like quality. Users will also benefit from Sigma's wide selection of interchangeable lenses that are compatible with the SD1.
The Sigma SD1 Merrill features dual "Three-layer Responsive Ultimate Engine (TRUE) II" image processing engines, which improves processing speed, provides high resolution power and produces high-definition images with richly graduated tones. It also allows simultaneous RAW and JPEG recording, which is a first for Sigma cameras. Additionally, the photographer has the option to select full-size, half-size or quarter-size RAW files making it a more versatile camera for a wide range of photographers. The Foveon sensor uses three silicon-embedded layers of photo detectors, stacked vertically to take advantage of silicon's ability to absorb red, green and blue light at different respective depths. This technology efficiently reproduces color more accurately and offers sharper resolution, pixel for pixel, than any conventional image sensor.
The optical format of the Foveon sensor has been upgraded from that which was used in previous SD cameras and has increased from 1.7x focal length to the 1.5x focal length multiplier. The SD1 also benefits from improved image processing and noise reduction algorithms, with an ISO sensitivity range from 100 to 6400. This is two full stops more sensitivity than the SD15, which has a maximum 1600 ISO. An intuitive user interface and an impressive lightweight, yet solid magnesium alloy body and O-ring sealing connections that make the camera durable and splash proof are also key feature upgrades of the flagship SD1.
The SD1 Merrill adopts the TYPE 1 Compact Flash Card and is UDMA-compatible enabling fast processing of large amounts of data. The autofocus system features an 11-point shifted twin cross type sensor, which improves AF accuracy. The SD1 features a 3.0 inch TFT color monitor. This 460,000 pixel resolution LCD monitor benefits from a wide viewing angle, making it easy to check focusing and composition. The SD1 Merrill can be used with more than 40 Sigma SA mount lenses such as ultra-wide, ultra-telephoto, macro and fisheye.
Sigma's image processing software, Photo Pro 5.0, comes bundled with the camera and its simple operation allows quick and easy capture of the desired imaged. Additional functions such as Loupe, Slideshow, Print, Convert to JPEG file and Batch White Balance settings are also incorporated into this software.
