Shure FP25/SM58-G4 FP Wireless Handheld System with FP5 Receiver, G4/470-494MHz
See all Shure items

Shure FP25/SM58-G4 FP Wireless Handheld System with FP5 Diversity Receiver, FP2 Handheld Transmitter, SM58 Cardioid Capsule, G4 / 470 - 494MHz

SKU: SHFP25SM58G4

This item is no longer available.

Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Shure FP25/SM58 Specifications

  • System: Working Range Line of Sight

    100 m (300 ft)

  • System: Tone Key

    32.768 kHz

  • System: Audio Frequency Response

    45 to 15,000 Hz (+/-2 dB)

  • System: Total Harmonic Distortion

    <0.5%, typical
    (Ref. +/-38 kHz deviation with 1 kHz tone)

  • System: Frequency Band/ Range

    G4 / 470 - 494MHz

  • System: Dynamic Range

    >100 dB, A-weighted

  • System: Operating Temperature Range

    -18deg.C (0deg.F) to +57deg.C (135deg.F)

  • FP5 Receiver: Audio Output Type

    TA3F

  • FP5 Receiver: Configuration

    Impedance balanced

  • FP5 Receiver: Pin Assignments

    1=ground, 2=hot, 3=cold

  • FP5 Receiver: Maximum Audio Output Level

    -5 dBV (into 600 Ohms load) Ref. +/-38 kHz deviation with 1 kHz tone

  • FP5 Receiver: Impedance

    200 Ohms

  • FP5 Receiver: Housing

    Molded polycarbonate case

  • FP5 Receiver: Sensitivity

    -108 dBm for 12 dB SINAD, typical

  • FP5 Receiver: Power Requirements

    2 AA batteries, 1.5V

  • FP5 Receiver: Battery Life

    Up to 12 hours (alkaline)

  • FP2 Transmitter: Maximum Input Level

    At -10 dB gain setting: +2 dBV / at 0 dB gain setting: -8 dBV

  • FP2 Transmitter: Gain Adjustment Range

    10 dB

  • FP2 Transmitter: RF Output Power

    10 to 30 mW (varies by region)

  • FP2 Transmitter: Housing

    Molded PC/ABS handle and battery cup

  • FP2 Transmitter: Power Requirements

    2 AA batteries, 1.5V

  • FP2 Transmitter: Battery Life

    Up to 12 hours (alkaline)

  • SM58 Microphone: Type

    Dynamic

  • SM58 Microphone: Frequency Response

    50 to 15,000 Hz

  • SM58 Microphone: Polar Pattern

    Cardioid

  • SM58 Microphone: Sensitivity

    -54.5 dBV/Pa (1.85 mV)
    1 Pa = 94 dB SPL

  • SM58 Microphone: Impedance

    Rated impedance is 150Ohms (300Ohms actual) for connection to microphone
    inputs rated low impedance

  • SM58 Microphone: Polarity

    Positive pressure on diaphragm produces positive voltage on pin 2 with respect to pin 3.

  • SM58 Microphone: Connector

    Three-pin professional audio connector (male XLR type)

  • Dimensions

    FP5 Receiver (H x W x D): 108 mm x 64 mm x 19 mm/4.25 x 2.51 x 0.74"
    FP2 Transmitter: 254 mm x 51mm (Dia) /10 x 2" (Dia)
    SM58 Microphone (L x W): 162 mm x 51 mm/6.37 x 2"

  • Weight

    FP5 Receiver: 81 g (3 oz.)
    FP2 Transmitter: 290 g (10.2 oz.) without batteries
    SM58 Microphone: 298 grams (10.5 oz)

  • UPC Code

    042406232890

About Shure FP25/SM58

The Shure FP25/SM58-G4 FP Wireless Handheld System (G4 / 470 - 494MHz) features the FP5 portable diversity receiver and FP2 handheld transmitter with SM58 cardioid capsule. The FP5 receiver features diversity reception, easy one-touch channel search and lightweight plastic housing. Infrared sync provides quick and easy channel syncing between the FP5 receiver and FP2 transmitter. The FP2 handheld transmitter is lightweight and features the SM58 cardioid capsule. An input gain control is featured for flexible input level adjustment. The FP5 receiver and FP2 transmitter is ruggedly built and powered on a pair of AA batteries.

Shure FP25/SM58 Features

  • FP5 Receiver: Shure patented Audio Reference Companding for crystal-clear audio
  • FP5 Receiver: Automatic Frequency Selection locates an open frequency at the touch of a button
  • FP5 Receiver: Automatic Transmitter Setup instantly syncs the transmitter to the receiver frequency
  • FP5 Receiver: Power LED with low battery indicator
  • FP5 Receiver: RF LED indicates transmitter sync when illuminated
  • FP5 Receiver: Up to 20 compatible systems simultaneously
  • FP5 Receiver: Powered by 2AA batteries - no power cord required
  • FP5 Receiver: Receiver output level control manages output to camera/mixer
  • FP5 Receiver: TA3F cable output to either XLR or 1/8" connectors (included)
  • FP5 Receiver: Diversity antennas for consistent reception of signal transmission
  • FP5 Receiver: Rugged and lightweight Shure construction
  • FP5 Receiver: Camera Shoe Mount (included)
  • FP2 Handheld Transmitter: Automatic Transmitter Setup instantly syncs the transmitter to the receiver frequency
  • FP2 Handheld Transmitter: LED indicator for control lockout, IR RF sync, low battery indicator
  • FP2 Handheld Transmitter: Powered by 2AA batteries
  • FP2 Handheld Transmitter: Legendary SM58 or VP68 microphone capsule options
  • FP2 Handheld Transmitter: Rugged and lightweight Shure construction
  • SM58 Microphone: Frequency response tailored for vocals, with brightened midrange and bass roll off
  • SM58 Microphone: Uniform cardioid pickup pattern isolates the main sound source and minimizes background noise
  • SM58 Microphone: Pneumatic shock-mount system cuts down handling noise
  • SM58 Microphone: Effective, built-in spherical wind and pop filter
  • SM58 Microphone: Supplied with break-resistant stand adapter which rotates 180 degrees
  • SM58 Microphone: Legendary Shure quality, ruggedness and reliability
  • SM58 Microphone: Cardioid (unidirectional) dynamic

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Patented Audio Reference Companding
  • Automatic Frequency Selection at touch of button
  • Instantly syncs transmitter to receiver frequency
  • Power LED with low battery indicator
  • RF LED indicates transmitter sync when illuminated
  • Up to 20 compatible systems simultaneously

What's in the box:

  • Shure FP5 Portable Diversity Receiver
  • FP2 Handheld Transmitter
  • SM58 Cardioid Capsule
  • Camera Shoe Mount
  • TA3F Cable to XLR or 1/8" Mini
  • Shure Warranty
