Shure MX395AL/O Low Profile Boundary Microphone, Omnidirectional, Aluminum
See all Shure items

Shure MX395AL/O Low Profile Boundary Microphone, Omnidirectional, 3-pin XLR Output Connectors, Brushed Aluminum

SKU: SHMX395ALO

This item is no longer available.

Recommended Alternatives

Shure : Picture 1 regular
Shure CVB Boundary Condenser Microphone, 12' Cable, Cardioid
$176.00$125.00
Shure : Picture 1 regular
Shure Overhead Condenser Microphone, 25' Cable, Cardioid, Black
$158.00$113.00
Shure : Picture 1 regular
Shure Overhead Condenser Microphone, 25' Cable, Cardioid, White
$158.00$113.00
Shure MX183: Picture 1 regular
Shure MX183 Omni-Directional Lavalier Microphone
$378.00$271.00
See More Recommendations
Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Browse our FAQ

See Terms & Conditions

Shure MX395AL/O Specifications

  • Transducer

    Condenser

  • Polar Pattern

    Omnidirectional

  • Frequency Response

    50 to 17000 Hz

  • Output Impedance

    EIA Rated at 150 Ohms (170 Ohms actual)

  • Output Configuration

    Active balanced

  • Sensitivity

    -28 dBV/Pa (42 mV)
    1 Pascal=94 dB SPL (at 1 kHz, open circuit voltage)

  • Maximum SPL

    114 dB (1 kHz at 1% THD, 1 kilohms load)

  • Equivalent output Noise (A-weighted)

    21 dB SPL

  • Signal-to-Noise Ratio

    73 dB (referenced at 94 dB SPL at 1 kHz)

  • Dynamic Range (1 kilohm load at 1 kHz)

    93 dB

  • Common Mode Rejection (10 Hz - 100 kHz)

    45 dB minimum

  • Preamplifier output Clipping level

    -8 dBV (0.4 V) (1% THD)

  • Polarity

    3-Pin XLR: Positive sound pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 of output XLR connector

  • Logic Connections

    LED IN: Active low (=1.0V), TTL compatible. Absolute maximum voltage: -0.7V to 50V.

  • Environmental Conditions

    Operating Temperature: -18 to 57 deg. C (0 to 135 deg. F)
    Storage Temperature: -29 to 74 deg. C (-20 to 165 deg. F)
    Relative Humidity: 0 to 95%

  • Power Requirements

    11 - 52 Vdc phantom, 2.0 mA

  • Dimensions (Diameter)

    1.25-inch (3.17 cm)

  • Weight

    0.136 kg (0.30 lbs)

  • UPC Code

    42406141246

About Shure MX395AL/O

The Shure MX395AL/O Microflex Button Microphone is a low profile boundary microphone designed for concealed capturing of conversations, speech and ambient audio while mounted in a flat surface, such as a desktop, ceiling or podium. The MX395AL/O measures just 1.25" (3.17 cm) in diameter, making it an ideal solution for video and broadcast operation.

Shure MX395AL/O Features

  • Only 1.25 inch (3.17 cm) in diameter
  • Omni polar pattern
  • Wide dynamic range and smooth frequency response

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Only 1.25 inch (3.17 cm) in diameter
  • Omni polar pattern
  • Wide dynamic range and smooth frequency response

What's in the box:

  • Shure MX395AL/O Low Profile Boundary Microphone
  • Omnidirectional
  • Aluminum
  • Shure Limited 2 Year Warranty
