Shure QLXD14/84 Lavalier Wireless Microphone System, G50/470-534MHz, Includes QLXD1 Bodypack Transmitter, QLXD4 Receiver, WL184 Lavalier Condenser Mic

SKU: SHQLX1484G50

This item is no longer available.

Recommended Alternatives

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Shure QLXD14 Specifications

  • Frequency Response

    G50/470-534MHz

  • QLXD1: Mic Offset Range

    0 to 21 dB (in 3 dB steps)

  • QLXD1: Battery Type

    Shure SB900 Rechargeable Li-Ion or AA batteries 1.5 V

  • QLXD1: Battery Runtime

    at 10 mW

  • QLXD1: Shure SB900: up to 10 hours

    Alkaline: up to 9 hours

  • QLXD1: Housing

    Cast aluminum

  • QLXD1: Audio Input Connector

    4-pin male mini connector (TA4M)

  • QLXD1: Configuration

    Unbalanced

  • QLXD1: Audio Input Impedance

    1 mOhms

  • QLXD1: Maximum Input Level

    1 kHz at 1% THD

  • QLXD1: 8.5 dBV (7.5 Vpp)

    Preamplifier Equivalent Input Noise (EIN)

  • QLXD1: System Gain Setting = +20

    -120 dBV, A-weighted, typical

  • QLXD1: RF Output Connector

    SMA

  • QLXD1: Antenna Type

    1/4 wave

  • QLXD1: RF Output Impedance

    50 Ohms

  • QLXD1: Occupied Bandwidth

    <200 kHz

  • QLXD1: Modulation Type

    Shure proprietary digital

  • QLXD1: Power

    1 mW or 10 mW

  • QLXD4: Spurious Rejection

    >80 dB, typical

  • QLXD4: Connector Type

    BNC

  • QLXD4: RF Output Impedance

    50 Ohms

  • QLXD4: Gain Adjustment Range

    -18 to +42 dB in 1 dB steps

  • QLXD4: Configuration

    1/4" (6.35mm): Impedance balanced (Tip=audio, Ring=no audio, Sleeve=ground)
    XLR: Balanced (1=ground, 2=audio /+, 3=audio-)

  • QLXD4: Audio Input Impedance

    1/4" (6.35 mm): 100 Ohms (50 Ohms Unbalanced)
    XLR: 100 Ohms

  • QLXD4: Full Scale Output

    1/4" (6.35 mm): +12 dBV
    XLR: LINE setting= +18 dBV, MIC setting= -12 dBV

  • QLXD4: Mic/Line Switch

    30 dB pad

  • QLXD4: Phantom Power Protection

    1/4" (6.35 mm): Yes
    XLR: Yes

  • QLXD4: Network Interface

    Single Port Ethernet 10/100 Mbps

  • QLXD4: Network Addressing Capability

    DHCP or Manual IP address

  • QLXD4: Maximum Ethernet Cable Length

    100 m (328 ft)

  • QLXD4: Housing

    Steel

  • QLXD4: Power requirements

    12 V DC at 0.4 A, supplied by external power supply (tip positive)

  • WL184: Type

    Condenser (electret bias)

  • WL184: Frequency Response

    50 to 17,000 Hz

  • WL184: Polar Patterns (at 1 kHz)

    Supercardioid

  • WL184: Output Impedance

    1800 Ohms

  • WL184: Sensitivity

    (1 Pa = 94 dB SPL): -44.5 dBV/Pa

  • WL184: Maximum SPL

    129.5 dB SPL

  • WL184: Output Noise

    27.0 dB SPL

  • WL184: Dynamic Range

    102.5 dB

  • WL184: Polarity

    Positive pressure on diaphragm produces positive voltage on pins 3 and 4 relative to pin 1

  • WL184: Power Requirements

    Regulated nominal +5 Vdc (1.5 Vdc to 10 Vdc) provided at microphone connector pin 2 relative to pin 1 of a Shure wireless microphone transmitter

  • Dimensions (H x W x D)

    QLXD1: 86 x 65 x 23mm (3.38 x 2.57 x 0.92")
    QLXD4: 41 x 197 x 151mm (1.63 x 7.75 x 5.94")

  • Weight

    QLXD1: without Batteries: 138g (4.9oz)
    QLXD4: Without Antennas: 777g (27.40oz)

  • UPC Code

    042406350358

About Shure QLXD14

Featuring the WL184 lavalier microphone, QLXD1 & 4/84 (G50/470-534MHz) combines professional features with simplified setup and operation. The Shure QLXD4 is a half-rack digital wireless receiver. Ideal for presentation spaces, music venues and houses of worship, the QLXD4 combines professional features with streamlined setup and operation. Automatic scanning quickly finds open frequencies and one-touch sync quickly deploys them to transmitters. Ethernet networking enables networked channel scanning across multiple receivers and Wireless Workbench software integration for remote control of receiver settings from a PC or Mac.

The Shure QLXD1 bodypack transmitter is ideal for wireless vocals and instruments in presentation spaces, music venues and houses of worship. Easy to use, the QLXD1 quickly syncs with a wireless receiver over IR at the push of a button and maintains clear, uninterrupted signal over its entire 100 m (330 ft.) range. All metal construction ensures durability and a wide selection of compatible microphone choices offer legendary Shure sound signatures.

The Shure WL184 is a Supercardioid lavalier electret condenser microphones for use with a wireless bodypack transmitter. Each micro-phone has a 1.2m (4') cable terminated with a miniature 4-pin con-nector (TA4F). The furnished tie clip can be rotated in 90deg. intervals for placement flexibility. Sound reinforcement applications requiring high rejection of ambient noise and narrow pickup angle. Use of wind-screen highly recommended. Pickup angle is 115deg..

Shure QLXD14 Features

  • QLXD1: 20 Hz to 20 kHz frequency range with flat response (actual response is microphone dependent)
  • QLXD1: Over 120 dB of dynamic range - no transmitter gain adjustments needed
  • QLXD1: AES 256-bit encryption for secure transmission
  • QLXD1: Up to 9 hours continuous use with 2 x AA alkaline batteries
  • QLXD1: Optional Shure SB900 lithium ion rechargeable battery provides up to 10 hours of
  • QLXD1: Backlit LCD with easy to navigate menu and controls
  • QLXD1: 100 meter (300 feet) line-of-sight operating range
  • QLXD1: 4-Pin male mini connector (TA4M)
  • QLXD1: Rugged metal construction
  • QLXD1: Frequency and power lockout
  • QLXD4: 64 MHz tuning bandwidth (region dependent)
  • QLXD4: More than 60 preset compatible channels per frequency band (region dependent)
  • QLXD4: Up to 17 compatible systems per 6 MHz TV channel; 22 systems per 8 MHz channel
  • QLXD4: Digital predictive switching diversity ensures solid RF connection
  • QLXD4: IR sync deploys selected frequency to transmitter
  • QLXD4: Ethernet networking provides streamlined setup across multiple receivers
  • QLXD4: Networked channel scan configures open frequencies for all connected receivers
  • QLXD4: AES 256-bit encryption for secure wireless transmission
  • QLXD4: Up to 60 dB of adjustable audio gain
  • QLXD4: Audio and RF LED meters with peak indicator
  • QLXD4: Detachable 1/2 wave antennas
  • QLXD4: Mic / line switchable XLR output
  • QLXD4: 1/4" instrument output
  • QLXD4: Durable aluminum construction with brushed finish
  • QLXD4: Compatible with Shure Wireless Workbench 6 control software

Product Documents

User Manual

Key Features

  • 28 Hz to 20 kHz frequency range w flat response
  • Over 120 dB range - no gain adjustments needed
  • AES 256-bit encryption for secure transmission
  • Up to 9 hours continuous use w 2 AA batteries
  • Optional Shure SB900 lithium ion rechargeable battery
  • Backlit LCD w easy to navigate menu & controls

What's in the box:

  • Shure QLXD1 Bodypack Transmitter (G50/470-534MHz)
  • QLXD4 Digital Wireless Receiver (G50/470-534MHz)
  • WL184 Lavalier Microphone
  • Instrument Cable
  • Power Supply
  • 2 x AA Batteries
  • Two 1/2 Wave Antennas
  • 2 x BNC Cables
  • Zipper Bag
  • 2 x BNC Bulkhead Adapters
  • Rackmount Kit
  • User Guide
  • Shure Warranty
