Shure SLXD14 Single-Channel Digital Wireless Instrument System, H55: 514-558MHz

SKU: SHS14H55 MFR: SLXD14-H55
Earn VIP Reward Points

Key Features

  • Experience freedom with this Shure wireless instrument microphone system, perfect for dynamic stage performances.
  • Enjoy exceptional sound quality with a Beta 98H/C mic, designed to capture every nuance of your instrument.
  • The SLXD1 bodypack transmitter offers a reliable wireless range up to 328 feet for unrestricted movement.
  • Achieve low latency digital audio, ensuring your performance is perfectly in sync with the band every time.
  • Simple setup and easy to use interface gets you playing quickly, making it great for musicians of all levels.
  • Built with durability in mind, this Shure wireless system withstands the rigors of touring and frequent use.
See More Product Details
FREE 2-Day Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$119.99

3 Year

$154.99

5 Year

$269.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Accessories
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Shure SLXD14 Specifications

System: RF

System: RF

Jump to...
  • RF Carrier Frequency Range

    514-558MHz

  • Working Range

    328' (100m)

  • RF Tuning Step Size

    25 kHz

  • Image Rejection

    >70 dB (typical)

  • RF Sensitivity

    -97 dBm at 10-5 BER

System: Audio

Jump to...
  • Latency

    3.2 ms

  • Audio Frequency Response

    20 Hz-20 kHz (+1, -2 dB)

  • Audio Dynamic Range

    120 dB @1% THD (A-weighted, typical)

  • Total Harmonic Distortion

    <0.02%

  • System

    Audio PolarityXLR: Positive pressure on microphone diaphragm produces positive voltage on pin 2 with respect to pin 3 of XLR output
    TRS: Positive pressure on microphone diaphragm produces positive voltage on the tip of the 6.35mm (1/4-inch) with respect to the ring of the 6.35mm output

  • Mic Offset Range

    0 to 21 dB (in 3 dB steps)

System: Temperature Range

Jump to...
  • Operating Temperature Range

    0 Degree F to 122 Degree F (-18 Degree C to 50 Degree C)

  • Storage Temperature Range

    -20 Degree F to 165 Degree F (-29 Degree C to 74 Degree C)

System: Battery

Jump to...
  • Battery Info

    Required, included

  • Battery Material

    -

  • Battery Quantity

    2

  • Battery Type

    AA

SLXD1 Transmitter: Audio Input

Jump to...
  • Connector

    4-Pin male mini connector (TA4M)

  • Configuration

    Unbalanced

  • Impedance

    1 M Ohm

  • Maximum Input Leve

    l8.2 dBV (2.57 Vrms, 7.27 Vpp)

  • Preamplifier Equivalent Input Noise

    -118 dBV (EIN)

SLXD1 Transmitter: RF Output

Jump to...
  • Antenna Type

    1/4 Wave

  • Occupied Bandwidth

    <200 kHz

  • Modulation Type

    Shure Propietary Digital

  • Power

    1 mW/10 mW

SLXD1 Transmitter: General

Jump to...
  • Battery Type

    Rechargeable Li-Ion or 1.5 V AA batteries

  • Housing

    PC/ABS

  • Dimensions (H x W x D)

    3.86 x 2.68 x 1.0" (98 x 68 x 25.5mm)

  • Weight

    3.1 oz (89g)

SLXD4 Receiver: RF Input

Jump to...
  • Spurious Rejection

    >75 dB Typical

  • Connector Type

    BNC

  • Impedance

    50 Ohm

SLXD4 Receiver: Audio Output

Jump to...
  • Gain Adjustment Range

    -18 to +42 dB in 1 dB steps

  • Configuration

    1/4" (6.35 mm): Balanced (Tip=audio +, Ring=audio -, Sleeve=ground)
    XLR: Balanced (1=ground, 2=audio +, 3=audio -)

  • Impedance

    1/4" (6.35 mm): 1.3 k Ohm (670 Ohm Unbalanced)
    XLR (line): 400 Ohm (200 Ohm Unbalanced)
    XLR (mic): 150 Ohm

  • Full Scale Output

    1/4" (6.35 mm): +15 dB differentially (+9 dBV single)
    XLR (LINE setting): +15 dBV
    XLR (MIC setting): -15 dBV

  • Mic/Line Switch

    30 dB pad

  • Phantom Power Protection

    1/4" (6.35 mm): Yes
    XLR: Yes

SLXD4 Receiver: Networking

Jump to...
  • Network Interface

    Single Port Ethernet 10/100 Mbps

  • Network Addressing Capability

    DHCP or Manual IP address

  • Maximum Cable Length

    328' (100m)

SLXD4 Receiver: General

Jump to...
  • Housing

    Galvanized Steel

  • Power Requirements

    15 VDC @ 600 mA Supplied by external power supply (tip positive)

  • Dimensions (H x W x D)

    1.65 x 7.76 x 5.98" (42 x 197 x 152mm)

  • Weight

    1.8 lbs (816g) without antennas

  • UPC Code

    042406562713

14 Accessories for Shure SLXD14 Single-Channel Digital Wireless Instrument System, H55: 514-558MHz

  • All Accessories (14)
  • Batteries & Power Supply (8)
  • Cables & Adapters (4)
  • XLR Cables (1)
  • Microphones (1)

About Shure SLXD14

Enhance your performance and connection with your audience using the SLXD14 Single-Channel Digital Wireless Instrument System, operating in the H55: 514-558MHz frequency range. This state-of-the-art system is designed to meet the evolving demands of various settings, from day-long conferences to nighttime performances, ensuring your message always comes through with crystal-clear clarity.

The SLXD14 system is a product of SLX-D Digital Wireless Systems, a leader in digital wireless technology. It offers superior audio quality with a dynamic range of over 120 dB, providing a clear, transparent, 24-bit digital audio that is simply essential when you're in front of an audience. With this system, audio dropouts are a thing of the past, as it maintains stable signals with high efficiency for rock-solid, reliable performance.

Designed with the user in mind, the SLXD14 system is ready to perform for extended periods. It offers up to 8 hours of use from either 2 AA batteries (included) or optional Shure SB903 Li-ion rechargeable batteries and charging accessories. This makes it an ideal solution for all-day conferences and nighttime performances.

The system includes the SLXD1 Digital Wireless Bodypack Transmitter, which easily syncs with a wireless receiver. It features TQG connectivity, offering a variety of microphone options to suit a wide range of applications. The transmitter boasts an extended 20 Hz to 20 kHz frequency range (microphone dependent), a 120 dB dynamic range, and digital predictive switching diversity. It also offers a 44 MHz tuning bandwidth (region dependent) and up to 32 available channels per frequency band (region dependent).

The SLXD14 system also includes the SLXD4 Digital Wireless Receiver. Like the transmitter, it delivers transparent, 24-bit digital audio and rock-solid RF performance. It features an easy pairing process with transmitters over scan and IR sync, and a rugged metal construction for durability. With a variety of interchangeable vocal microphone choices, the SLXD4 guarantees the right solution for a wide range of applications.

In summary, the SLXD14 Single-Channel Digital Wireless Instrument System is a versatile, reliable, and high-quality solution for your audio needs, ensuring your performance always resonates with your audience.

Shure SLXD14 Features

  • Extended 20 Hz to 20 kHz frequency range (microphone dependent)
  • 120 dB dynamic range
  • Digital predictive switching diversity
  • 44 MHz tuning bandwidth (region dependent)
  • 32 available channels per frequency band (region dependent)
  • Up to 10 compatible systems per 6MHz TV band; 12 systems per 8 MHz band
  • Easy pairing of transmitters and receivers over IR scan and sync
  • Up to 8 hours from 2 AA batteries or optional Shure SB903 rechargeable battery (sold separately)

Warranty Information

This product has a limited warranty of 24 months.

Product Documents

User Manual

Key Features

  • Experience freedom with this Shure wireless instrument microphone system, perfect for dynamic stage performances.
  • Enjoy exceptional sound quality with a Beta 98H/C mic, designed to capture every nuance of your instrument.
  • The SLXD1 bodypack transmitter offers a reliable wireless range up to 328 feet for unrestricted movement.
  • Achieve low latency digital audio, ensuring your performance is perfectly in sync with the band every time.
  • Simple setup and easy to use interface gets you playing quickly, making it great for musicians of all levels.
  • Built with durability in mind, this Shure wireless system withstands the rigors of touring and frequent use.

What's in the box:

  • Shure SLXD1 Digital Wireless Bodypack Transmitter
  • SLXD4 Digital Wireless Receiver
  • Beta 98H/C Clip-on Gooseneck Microphone
  • 2x AA Batteries
  • Zippered Carrying Bag
  • Windscreen
  • In-Line Preamplifier
  • 3m High-Flex Cable with Attached Preamplifier (XLR Connection)
  • Shure 2 Year Limited Warranty
