24% Off

Shure SLXD14 Single-Channel Digital Wireless Instrument System, J52: 558-602MHz and 614-616MHz

SKU: SHS14J52 MFR: SLXD14-J52
Earn VIP Reward Points

Key Features

  • Experience freedom with this Shure wireless instrument microphone system for dynamic stage performances.
  • Enjoy exceptional audio clarity with a digital wireless microphone that captures every nuance of your instrument.
  • The Beta 98H/C clip-on gooseneck microphone delivers precise sound reproduction for brass, woodwinds, and drums.
  • Achieve a reliable wireless connection up to 328 feet, perfect for large stages and dynamic movement.
  • Benefit from low latency (3.2ms) ensuring real-time performance without distracting delays during crucial moments.
  • The rugged design of the Shure SLXD14 offers durability and consistent performance for touring musicians.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$119.99

3 Year

$154.99

5 Year

$269.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Accessories
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Shure SLXD14 Specifications

System: RF

System: RF

Jump to...
  • RF Carrier Frequency Range

    558-602MHz and 614-616MHz

  • Working Range

    328' (100m)

  • RF Tuning Step Size

    25 kHz

  • Image Rejection

    >70 dB (typical)

  • RF Sensitivity

    -97 dBm at 10-5 BER

System: Audio

Jump to...
  • Latency

    3.2 ms

  • Audio Frequency Response

    20 Hz-20 kHz (+1, -2 dB)

  • Audio Dynamic Range

    120 dB @1% THD (A-weighted, typical)

  • Total Harmonic Distortion

    <0.02%

  • System

    Audio PolarityXLR: Positive pressure on microphone diaphragm produces positive voltage on pin 2 with respect to pin 3 of XLR output
    TRS: Positive pressure on microphone diaphragm produces positive voltage on the tip of the 6.35mm (1/4-inch) with respect to the ring of the 6.35mm output

  • Mic Offset Range

    0 to 21 dB (in 3 dB steps)

System: Temperature Range

Jump to...
  • Operating Temperature Range

    0 Degree F to 122 Degree F (-18 Degree C to 50 Degree C)

  • Storage Temperature Range

    -20 Degree F to 165 Degree F (-29 Degree C to 74 Degree C)

System: Battery

Jump to...
  • Battery Info

    Required, included

  • Battery Material

    -

  • Battery Quantity

    2

  • Battery Type

    AA

SLXD1 Transmitter: Audio Input

Jump to...
  • Connector

    4-Pin male mini connector (TA4M)

  • Configuration

    Unbalanced

  • Impedance

    1 M Ohm

  • Maximum Input Leve

    l8.2 dBV (2.57 Vrms, 7.27 Vpp)

  • Preamplifier Equivalent Input Noise

    -118 dBV (EIN)

SLXD1 Transmitter: RF Output

Jump to...
  • Antenna Type

    1/4 Wave

  • Occupied Bandwidth

    <200 kHz

  • Modulation Type

    Shure Propietary Digital

  • Power

    1 mW/10 mW

SLXD1 Transmitter: General

Jump to...
  • Battery Type

    Rechargeable Li-Ion or 1.5 V AA batteries

  • Housing

    PC/ABS

  • Dimensions (H x W x D)

    3.86 x 2.68 x 1.0" (98 x 68 x 25.5mm)

  • Weight

    3.1 oz (89g)

SLXD4 Receiver: RF Input

Jump to...
  • Spurious Rejection

    >75 dB Typical

  • Connector Type

    BNC

  • Impedance

    50 Ohm

SLXD4 Receiver: Audio Output

Jump to...
  • Gain Adjustment Range

    -18 to +42 dB in 1 dB steps

  • Configuration

    1/4" (6.35 mm): Balanced (Tip=audio +, Ring=audio -, Sleeve=ground)
    XLR: Balanced (1=ground, 2=audio +, 3=audio -)

  • Impedance

    1/4" (6.35 mm): 1.3 k Ohm (670 Ohm Unbalanced)
    XLR (line): 400 Ohm (200 Ohm Unbalanced)
    XLR (mic): 150 Ohm

  • Full Scale Output

    1/4" (6.35 mm): +15 dB differentially (+9 dBV single)
    XLR (LINE setting): +15 dBV
    XLR (MIC setting): -15 dBV

  • Mic/Line Switch

    30 dB pad

  • Phantom Power Protection

    1/4" (6.35 mm): Yes
    XLR: Yes

SLXD4 Receiver: Networking

Jump to...
  • Network Interface

    Single Port Ethernet 10/100 Mbps

  • Network Addressing Capability

    DHCP or Manual IP address

  • Maximum Cable Length

    328' (100m)

SLXD4 Receiver: General

Jump to...
  • Housing

    Galvanized Steel

  • Power Requirements

    15 VDC @ 600 mA Supplied by external power supply (tip positive)

  • Dimensions (H x W x D)

    1.65 x 7.76 x 5.98" (42 x 197 x 152mm)

  • Weight

    1.8 lbs (816g) without antennas

  • UPC Code

    042406562706

14 Accessories for Shure SLXD14 Single-Channel Digital Wireless Instrument System, J52: 558-602MHz and 614-616MHz

  • All Accessories (14)
  • Batteries & Power Supply (8)
  • Cables & Adapters (4)
  • XLR Cables (1)
  • Microphones (1)

About Shure SLXD14

From presentations to performances, the SLXD14 Single-Channel Digital Wireless Instrument System, operating in the J52: 558-602MHz and 614-616MHz frequency range, ensures your audio quality is never compromised. This advanced digital wireless system is designed to provide a solid foundation for any audio setup, catering to the varying demands of day-long conferences and nighttime performances.

The SLXD14 system offers superior digital audio clarity with an impressive >120 dB dynamic range. Leveraging industry-leading digital wireless technology, it ensures stable, high-efficiency signals for reliable performance. The system is equipped to deliver up to 8 hours of continuous use from either 2 AA batteries (included) or optional Shure SB903 Li-ion rechargeable batteries and charging accessories.

The SLXD1 Digital Wireless Bodypack Transmitter, a key component of the system, delivers transparent, 24-bit digital audio and features an extended 20 Hz to 20 kHz frequency range. With a dynamic range of 120 dB and digital predictive switching diversity, it offers a tuning bandwidth of 44 MHz and up to 32 available channels per frequency band. The transmitter is designed for easy pairing with receivers over scan and IR sync and offers TQG connectivity for a variety of microphone options.

The SLXD4 Digital Wireless Receiver, another integral part of the system, mirrors the transmitter's features, delivering transparent, 24-bit digital audio and an extended 20 Hz to 20 kHz frequency range. It also offers easy pairing with transmitters over scan and IR sync and is housed in a rugged metal construction for durability.

Whether you're hosting an event, leading a presentation, or performing at a club, the SLXD14 Single-Channel Digital Wireless Instrument System ensures your audio comes through clear and strong, making it an ideal solution for a wide range of applications.

Shure SLXD14 Features

  • Extended 20 Hz to 20 kHz frequency range (microphone dependent)
  • 120 dB dynamic range
  • Digital predictive switching diversity
  • 44 MHz tuning bandwidth (region dependent)
  • 32 available channels per frequency band (region dependent)
  • Up to 10 compatible systems per 6MHz TV band; 12 systems per 8 MHz band
  • Easy pairing of transmitters and receivers over IR scan and sync
  • Up to 8 hours from 2 AA batteries or optional Shure SB903 rechargeable battery (sold separately)

Warranty Information

This product has a limited warranty of 24 months.

Product Documents

User Manual

Key Features

  • Experience freedom with this Shure wireless instrument microphone system for dynamic stage performances.
  • Enjoy exceptional audio clarity with a digital wireless microphone that captures every nuance of your instrument.
  • The Beta 98H/C clip-on gooseneck microphone delivers precise sound reproduction for brass, woodwinds, and drums.
  • Achieve a reliable wireless connection up to 328 feet, perfect for large stages and dynamic movement.
  • Benefit from low latency (3.2ms) ensuring real-time performance without distracting delays during crucial moments.
  • The rugged design of the Shure SLXD14 offers durability and consistent performance for touring musicians.

What's in the box:

  • Shure SLXD1 Digital Wireless Bodypack Transmitter
  • SLXD4 Digital Wireless Receiver
  • Beta 98H/C Clip-on Gooseneck Microphone
  • 2x AA Batteries
  • Zippered Carrying Bag
  • Windscreen
  • In-Line Preamplifier
  • 3m High-Flex Cable with Attached Preamplifier (XLR Connection)
  • Shure 2 Year Limited Warranty
