Sirchie Video-Based Optical Comparator with Color Monitor

SKU: SIFX10BC MFR: FX10BC
Earn VIP Reward Points

Key Features

  • Enhance crime scene investigation with this optical comparator's crystal-clear image clarity.
  • Utilize the video splitter for detailed forensic analysis, comparing evidence with precision.
  • Benefit from 5X-45X magnification, ideal for examining minute details in lab analysis.
  • Capture and compare video signals effortlessly using the NTSC-compatible video output.
  • Rely on robust digital decoding for accurate comparison during critical forensic tasks.
  • The comparator's adjustable split and fade range offers versatile evidence comparison options.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

1 Year

$449.99

2 Year

$639.99

3 Year

$849.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Sirchie Video-Based Optical Comparator with Color Monitor Specifications

  • Sensor

    1/4" Interline Transfer CCD

  • Effective Picture Element

    768H x 492V pixels

  • Sync. Frequency

    Horizontal: 15.734KHz
    Vertical: 59.94Hz

  • Resolution

    470 TV-lines (horizontal)

  • S/N Ratio

    More than 50Db

  • Minimum Illuminance

    Less than 2.0 lx (f/1.2)

  • Gamma

    0.45

  • Video Output

    1.0Vp-p/75W

  • White Balance

    Auto Tracking White balance

  • Zoom Ratio

    8x

  • Aperture

    F/7 (low mag.)-f/10 (high mag.)

  • Magnification

    -5X to -45X on 14 diagonal monitor

  • Lens Construction

    10 elements/7 groups

  • Filter Size

    M40.5 x P0.5

  • Video Splitter: Video Signal

    NTSC only

  • Video Splitter: Split Range

    Horizontal: 0 to 53.3uS from start of active video >98% of screen width typical
    Vertical: 0 to 485 lines, fully variable insteps of two, 100% screen height typical

  • Video Splitter: Fade Range

    A:B ratio from 100%/0% to 0%/100%, 256 steps

  • Video Splitter: Difference Range

    A:B ratio from 100%/-0%to 0%/-100%, 256 steps

  • Video Splitter: Memory

    10 megabits per channel (full frame X1 each input)

  • Video Splitter: Decoding

    9 bit multi-standard digital decoding

  • Video Splitter: Processing

    8 bit, 4:2:2, ITU-R601 and ITU-R656 standards

  • Video Splitter: Encoding

    Full Digital Modulation

  • Video Splitter: Oversampling

    4x (54MHz) output oversampling

  • Video Splitter: Output DACs

    10 bit Digital to Analog converters

  • Video Splitter: Output Filters

    Digital, plus 4 stage analog anti-aliasing filters

  • Video Splitter: Horizontal Frequency

    15.734KHz typical

  • Video Splitter: Vertical Frequency

    59.94Hz typical

  • Video Splitter: Bandwidth

    6MHz typical

  • Video Splitter: Crosstalk

    Greater than 48dB

  • Video Splitter: Gain Match A to B

    Typ. within 1%

  • 4" LCD Monitor: Resolution

    234 x 383 dpi

  • 4" LCD Monitor: Backlight

    Cold cathode fluorescent lamp

  • 4" LCD Monitor: Size

    TFT 4.1" x 3.3" LCD display

About Sirchie Video-Based Optical Comparator with Color Monitor

When it comes to precision and accuracy in optical comparisons, the Sirchie Video-Based Optical Comparator with Color Monitor stands out as a top-tier choice. This innovative device is meticulously designed to integrate high-resolution video cameras with superior optics, ensuring detailed and clear images. Its advanced internal digital circuitry is paired with a user-friendly, eye-level control panel, making it a breeze to operate.

The FX10BC model is equipped with color video cameras, enhancing the accuracy of color comparisons. This feature-rich unit is capable of directly feeding video to monitors, recorders, or computers with video capture capabilities, making it a versatile tool for various applications.

Beyond its primary function as a fingerprint projector, this reliable optical comparator allows for the examination of a wide range of items of forensic interest. Its laboratory-grade focusing jacks enable the viewing of both two-dimensional and three-dimensional objects, providing a comprehensive analysis tool for professionals.

The device's optics offer an exceptional depth of field, even when viewing curved surfaces, ensuring that no detail is overlooked. The FX10BC model also offers both vertical and horizontal split screens for evidence comparison, along with the ability to overlay one image over another, providing a more detailed and comparative analysis.

To top it all off, this durable optical comparator features a built-in LCD monitor, enhancing its usability and convenience. With the Sirchie Video-Based Optical Comparator with Color Monitor, you're investing in a high-quality, reliable tool that delivers superior performance in optical comparisons.

Sirchie Video-Based Optical Comparator with Color Monitor Features

  • Soft, indirect lighting with circular fluorescent tubes
  • Laboratory-grade focusing jacks
  • High resolution color video cameras
  • Vertical and horizontal, continuously variable split-screen image
  • Image overlay
  • Image reversal (Channel B only)
  • BNC-type video-out connector

Key Features

  • Enhance crime scene investigation with this optical comparator's crystal-clear image clarity.
  • Utilize the video splitter for detailed forensic analysis, comparing evidence with precision.
  • Benefit from 5X-45X magnification, ideal for examining minute details in lab analysis.
  • Capture and compare video signals effortlessly using the NTSC-compatible video output.
  • Rely on robust digital decoding for accurate comparison during critical forensic tasks.
  • The comparator's adjustable split and fade range offers versatile evidence comparison options.
