SmartSystem Matrix One R2 Lite Bundle with 3-Stud Battery Mount

SKU: SMART8097 MFR: 000008097
Earn VIP Reward Points

Key Features

  • Achieve smooth, professional footage with this SmartSystem stabilizer bundle.
  • Enjoy versatile shooting with the Matrix Sled R2 Lite's adjustable height.
  • Benefit from robust support; the Arm X1 boasts a 74.9 lbs maximum payload.
  • Ensure equipment safety with the included hard case, IP67 certified.
  • Experience comfortable operation using the lightweight Vest Lite design.
  • Get steady shots using a high-quality video stabilizer for filmmaking.
See More Product Details
Special Order?Estimated to Ship: 08/18/2025
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$229.99

3 Year

$274.99

4 Year

$369.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

SmartSystem Matrix One R2 Lite Bundle with 3-Stud Battery Mount Specifications

Arm X1
  • Material

    Arm: Aluminum alloy like 7075 (Ergal)

  • Boom Range

    28.5" (728mm)

  • Maximum Payload

    74.9 lbs (34kg)

  • Width

    1.77" (45mm)

  • Weight

    9.92 lbs (4.5kg)

Matrix Sled R2 Lite

Jump to...
  • Mount

    3-Stud Mount

  • Material of Construction

    Carbon Fiber

  • Stabilizer Type

    Single-Grip Handheld

  • Height

    20.9 to 37.0" / 53 to 94 cm

  • Center Column Diameter

    1.6" (40mm)

  • Number of Sections

    2

  • Counterweights

    None

  • Battery Info

    Required, not included

  • Battery Material

    Lithium-ion

  • Battery Type

    Non-universal

  • Battery Quantity

    1

Vest Lite

Jump to...
  • Material

    Aluminum, Stainless Steel

  • Weight

    5.95 lbs (2.7kg)

Hard Case

Jump to...
  • Compatibility

    SmartCAM Arm & Sled System

  • Material

    Polypropylene

  • Certifications

    IP67
    STANAG 4280
    DEF STAN 81-41 Compliancy

  • Operating Temperature

    -22 to 194 Degree F (-30 to 90 Degree C)

  • Dimensions

    Outer: 32.12 x 21.26 x 12.04" (816 x 540 x 306mm)

  • Weight

    23.8 lbs (10.8kg)

About SmartSystem Matrix One R2 Lite Bundle with 3-Stud Battery Mount

Where professional quality and robust design meet, the Matrix One R2 Lite Bundle with 3-Stud Battery Mount stands out. This durable and reliable bundle is designed to support a wide range of cameras and equipment, with a weight capacity of up to 12 lbs. It's an ideal choice for those using a DSLR or mirrorless camera with a lens attached, or a small video camera.

The Matrix One R2 Lite Bundle is specifically designed to work seamlessly with the DJI Ronin 2, a handheld camera stabilizer. This ensures your camera remains steady and stable during filming or photography sessions. The bundle includes a 3-stud battery mount, allowing you to attach a battery or other accessories to the stabilizer with ease.

The Matrix One R2 Lite is based on the Matrix 40mm / 1.57" post in R2 Lite flavor, and comes with ArmX1. This combination allows you to transition your Ronin 2 from High Mode to Low Mode without any issues. It's perfect for those who prefer to use a compact monitor on the gimbal handle as opposed to the Horizon System.

The Matrix R2 Lite is a lighter version derived from the Matrix R2, designed for those who prefer a smaller monitor on the Gimbal Handle. It features an ultra-smooth gimbal, 5-AXIS CNC Machined, and a completely tool-free 40mm (1.57") telescopic carbon fiber post. This post can extend from 530mm (20.86") to 940mm (37.00"), providing flexibility for your filming needs.

The bundle also includes a unique Ronin 2 tilt-able Battery plate. This can be used as a standard battery on a sled, with no external cable needed to power your favorite gimbal. The magic is all inside the sled, providing a clean and clutter-free setup.

The Arm X1, designed, engineered, manufactured, and hand-built exclusively in Italy, is made from AL7075 Ergal alloy. This high-performing aluminum alloy offers performance similar to carbon steel but at a fraction of the weight. It's the slimmest arm on the market with outstanding load capabilities, able to lift up to 32kg (70.4 lbs) with a maximum payload of 34kg (74.9 lbs).

The Vest Lite, engineered around a proven design and made from top-quality materials, is adjustable and can perfectly adapt to the body. It's made from solid Ergal T7075 Aluminum and features a ratchet system for progressive tightening force.

The Matrix One R2 Lite Bundle with 3-Stud Battery Mount is a high-quality, sturdy, and robust solution for your filming needs. It's designed to provide the support and stability you need, whether you're filming with a DSLR, mirrorless camera, or small video camera.

SmartSystem Matrix One R2 Lite Bundle with 3-Stud Battery Mount Features

  • Arm X1 Features
  • Double section articulated stabilization arm with an ultimate payload of 34kg (74.9lbs) based on an exclusive Patented Design
  • Extremely light and compact: it's one of the smallest and lightest stabilizer arm in the market (only 45mm of width)
  • Exclusive X-Tune system allows the operator to set up Arm X1 to obtain the correct dynamic response for its needs
  • Completely milled from highest quality Ergal 7075 aluminum, shot peened and hard anodized for ultimate strength and lightness (only 4.5kg in its heavier configuration)
  • Equipped with Patent Pending DynaSpring Technology that dynamically adapt the answer of the springs all over the boom range
  • Perfectly compatible with every type of professional stabilizer Vest or Sled on the market
  • Matrix Sled R2 Lite Features
  • Professional Sled with 40mm Telescopic Post designed to work with DJI Ronin 2 thanks to the Ronin 2 Plate adapter included in the bundle
  • No external cable needed to power Ronin 2. Forget the umbilical cable era
  • The standard Ronin 2 Battery can be attached as regular batteries with the ability to move fore-aft on carbon fiber rods and to tilt +90 Degree -90 Degree for perfect Balance
  • The topstage can be assembled on the lower part of the sled to grant ultra precision balancing with the Standard VLock or 3Studs battery plate included on the bundle
  • An additional U-bracket and a specific plate to increase mass in the lower part help you in finding the right setup
  • Vest Lite Features
  • Great comfort and Perfect fit to any operator height and weight, male or female
  • Most probably, the lightest vest on the market: just 2.9kgs (6.4 lbs)
  • Buckle system for quick tighten and release operation
  • Memory foam padding
  • Balanced weight distribution
  • Removable and washable textile parts
  • Standard Arm connector. Compatible with all Professional Arms on the market

Key Features

  • Achieve smooth, professional footage with this SmartSystem stabilizer bundle.
  • Enjoy versatile shooting with the Matrix Sled R2 Lite's adjustable height.
  • Benefit from robust support; the Arm X1 boasts a 74.9 lbs maximum payload.
  • Ensure equipment safety with the included hard case, IP67 certified.
  • Experience comfortable operation using the lightweight Vest Lite design.
  • Get steady shots using a high-quality video stabilizer for filmmaking.

What's in the box:

  • Arm X1 Stabilizer Arm
  • Matrix Sled R2 Lite with 3-Stud Battery Mount
  • Vest Lite with Backpack
  • Hard Case
  • SmartSystem 1 Year Limited Warranty
