SmallHD 1303 HDR 13" Full HD LED Production Monitor, Open Box

SKU: SMM1303HDROB

This item is no longer available.

Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

2023-03-01T09:22:43

Rated 5 out of 5

Great production monitor.

For a focal puller this monitor is a dream. Great tools and great picture. For dit's or directors it has plenty of scopes to check the picture. Very solid and well designed.

ANDREW K.

2022-12-27T09:13:21

Rated 5 out of 5

Well Built Monitor

Crisp, well built, and light.

Tania C.

2022-04-13T05:53:25

Rated 4 out of 5

Kind if disappointed

Kind if disappointed so far. Only had on one job so far, left everything in factory settings, which seem to be rec.709. Ended up having to increase brightness 20% because the picture was just too dark. Camera looked fine on other monitors and scope. Focus was pretty good, and it looks like it will be able to be bright enough for my outdoor usage. It doesn't have VESA mounting points; couldn't get more than two to line up at either 75 or 100. Luckily I had an extra arm with 1/4-20 and a clamp. I had an AC try it, and he said nope, out of luck with a VESA mount. I know they have their own stand mount, but the angle can't be adjusted. I did run about 6 hours with one 90wh battery, and appeared to have plenty left. If it had been $2k or less, I might not be as disappointed. Well, OK, except for not having a VESA mount. I was also a bit disappointed it doesn't have a built in power supply. At least the Boland I also use has a mount to hold their power supply.

Scott S.

2021-02-14T09:03:04

Rated 5 out of 5

Great focus monitor

Great monitor, it’s pretty much the standard for pulling focus on film/tv production. Very bright, perfect size.

NICOLAS M.

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

SmallHD 1303 HDR Monitor Specifications

Display

Display

Jump to...
  • Panel Type

    IPS-Type LCD

  • Display Size

    13.00" (33.0cm)

  • Screen Area

    11.59 x 6.52" (29.44 x 16.56cm)

  • Resolution

    1920 x 1080p

  • Aspect Ratio

    '16:9

  • Viewing Angle

    178 Degree

  • Touchscreen

    No

  • Maximum Brightness

    1500 cd/sq. m

  • Contrast Ratio

    '1140:1

  • Bit Depth / Color Support

    10-Bit (1.07 Billion Colors)

  • HDR Compatibility

    Yes

  • Pixels Per Inch (ppi)

    170 ppi

  • Color Gamut

    100% Rec. 709

  • Image Controls

    False Color, Focus Assist, Focus Peaking, Pixel Zoom, Waveform

  • Video I/O

    1x HDMI Input
    1x HDMI Output
    2x BNC (3G-SDI) Input
    2x BNC (3G-SDI) Output

  • Embedded Audio

    HDMI
    SDI

  • Audio I/O

    1x 1/8" / 3.5 mm Headphone Output

  • Built-In Speaker

    None

  • Power I/O

    1x XLR 4-Pin (12 VDC) Input
    1x LEMO 2-Pin (4 A / 12 VDC) Input

  • Other I/O

    2x USB-A 2.0 Input

  • Media/Memory Card Slot

    None

  • Wi-Fi

    None

Format Support

Jump to...
  • Video Format

    HDMI (8/10/12-Bit 4:4:4/4:2:2 YCC):
    1080p: 60/59.94/50/30/29.97/25/24/23.98
    1080i: 120/119.88/100/60/59.94/50
    720p: 120/119.88/100/60/59.94/50/30/29.97/25/24/23.98
    576p: 100/50
    480p: 120/119.88/100/60/59.94

  • Video Format (Contd.)

    SDI (10-Bit 4:2:2):
    1080p: 120/119.88/100/60/59.94/50/30/29.97/25/24/23.98
    1080PsF: 30/29.97/25/24/23.98
    1080i: 120/119.88/100/60/59.94/50
    720p: 120/119.88/100/60/59.94/50/30/29.97/25/24/23.98
    576i: 25
    480i: 59.94

  • AC Input Power

    110 to 240 VAC, 50 / 60 Hz at 6 to 15 A

  • DC Input Power

    12 to 34 VDC at 18 A

  • Power Consumption

    25 W (Typical)
    39 W (Maximum)

Mounting

Jump to...
  • Mounting

    6x 1/4"-20 Female

Environmental

Jump to...
  • Operating Temperature

    32 to 100 Degree F (0 to 37 Degree C)

  • Storage Temperature

    33 to 115 Degree F (0 to 46 Degree C)

Battery

Jump to...
  • Battery Info

    Optional, not included

  • Battery Material

    Lithium-ion

  • Battery Type

    Non-universal

  • Battery Quantity

    1

General

Jump to...
  • Dimensions

    13 x 9 x 2.88" (33 x 22.9 x 7.32cm)

  • Weight

    9.0 lbs (4.1kg)

About SmallHD 1303 HDR Monitor

FEATURED REVIEWS

Great production monitor.

By ANDREW K.

For a focal puller this monitor is a dream. Great tools and great picture. For dit's or directors it has plenty of scopes to check the picture. Very solid and well designed.

Well Built Monitor

By Tania C.

Crisp, well built, and light.

Clarity that produces certainty
The display size, resolution and pixel density of the 1303 production monitor make it an invaluable tool for precision focus pulling. When you don't have the time or proper measurements, a razor-sharp, low latency display will help you hit your marks.

Calibrated for collaboration
Preview what you're sending downstream using the Output Preview Page, while utilizing software features like customizable focus assist and peaking on your 1303 monitor. If it's the only monitor near by, its color accuracy (100% REC 709) and broad viewing angle make it easy to share with clients and directors.

Can you see me now Good
With a panel roughly 3x brighter than most production monitors, the 1303 is not restrained by ambient light. Its optically bonded LCD combats glare and sunlight, allowing you to pull focus in less than ideal shooting environments.

Proper power options
Power options for the 1303 monitor are simple and convenient. The 2-pin LEMO out allows for a seamless integration with accessories such as the Teradek Bolt wireless receiver.

Travel made easy: carry-on accessories
All SmallHD production monitors are equipped with the Rapid Rail Mounting System; the simplest way to connect, store and travel with critical monitor accessories.

Smooth is fast
Transitioning from table to C-Stand happens safely and securely with the 1303's VESA compatible mounting accessory.

Boldly go
The 1303 monitor is the perfect blend of functionality and portability. With a razor-sharp display and a rugged build quality, the 1303 will boldly go where no other production monitor has ever gone before.

SmallHD 1303 HDR Monitor Features

  • 13" Full HD HDR LCD Display
  • HDR Preview
  • SDI and HDMI Inputs
  • Bright 1500 cd/sq. m Panel
  • Colorflow 3D LUT Processing
  • 10-Bit Color Intelligence Engine
  • Page Builder OS
  • RapidRail Shoe-Mount System
  • Aluminum Construction

Key Features

  • 13" Full HD HDR LCD Display
  • HDR Preview
  • SDI and HDMI Inputs
  • Bright 1500 cd/sq. m Panel
  • Colorflow 3D LUT Processing
  • 10-Bit Color Intelligence Engine

What's in the box:

  • SmallHD 1303 HDR 13" Full HD LED Production Monitor
  • 72" HDMI to HDMI Cable
  • AC Adapter
  • SmallHD 1 Year Limited Warranty
