SmallHD FOCUS 5" LED Monitor Bundle, DMWBLF19 Power Adapter to Panasonic Camera Specifications

Display

Display

Jump to...
  • Panel Type

    IPS Touchscreen

  • Resolution

    1280x720

  • Pixel Density

    294 PPI

  • Aspect Ratio

    16:9

  • Active Area

    5.0"

  • Brightness

    800 nits

  • Color Gamut

    70% NTSC

  • Color Depth

    10-bit processing

  • Viewing Angle

    160 Degrees

  • Backlight Type

    White LED

  • Temperature Adaptive Color

    No

Input Signal Types/Formats

Jump to...
  • 3G-SDI

    No

  • HD-SDI

    No

  • SD-SDI

    No

  • HDMI

    Supports UHD-1 4K at 30/29.97 at RGB 444 8bit, YCC 444 8bit, YCC 422 12 bit & 24/23.98 at RGB 444 10/8 bit, YCC 444 10/8bit, YCC 422 12 bit, YCC 4:2:2, 8/10/12 bit color in RGB & YCC 4:4:4, 1080p60, 1080p59.94, 1080p50, 1080p30, 1080p29.97 1080p25, 1080p24, 1080p23.98,1080i120, 1080i119.88, 1080i100, 1080i60, 1080i59.94, 1080i50, 720p120

  • HDMI (cont.)

    720p119.88, 720p/100, 720p60, 720p59.94 , 720p50, 720p30, 720p29.97, 720p25, 720p24, 720p23.98, 480p59.94, 480p60, 480p100, 480p119.88, 480p120, 480p239.76, 480p240, 576p50, 576p100, 576p200, 480i59.94, 480i60, 480i119.88, 480i120, 480i239.76, 480i240, 576i50, 576i100, 576i200

  • Component

    No

  • Composite

    No

  • Audio

    HDMI

Output Signal Types/Formats

Jump to...
  • 3G-SDI

    No

  • HD-SDI

    No

  • SD-SDI

    No

  • HDMI

    No

  • Component

    No

  • Composite

    No

  • Audio

    Stereo Out (headphones)

Connector Type

Jump to...
  • HDMI

    1x Micro-HDMI Input

  • Audio

    1/8" Stereo mini-jack

  • Power In

    1x Sony L-Style Battery slot, barrel output for powering cameras via adaptor (NP-FW50 Sony & LP-E6 Canon)

  • Power Out

    Barrel (3.5mm outer, 1.1mm inner)

  • USB

    1x Micro-USB for camera control

Controls

Jump to...
  • Primary Control Interface

    Capacitive Touchscreen

  • Record/Capture

    Capture Tool

Data I/O

Jump to...
  • Storage

    SD Card for Image Capture / Overlay, LUT Loading, Firmware Upgrades

  • Wireless

    Compatible with SmallHD BTR1 Wireless Remote

  • Connector Type

    1x Sony L-Style Battery slot, 1x barrel connector for powering camera

  • Voltage

    6.0 - 8.4V

  • Recommended Power Supply

    Battery Only Device

  • Overload Protection

    Yes

  • Battery Chemistry

    Li-ion

  • Output Voltage

    Mirrors Input Voltage from battery

  • Battery Capacity

    2000mAh - 6300mAh

Environmental

Jump to...
  • Compliance

    CE

  • Mount Points

    3x 1/4-20 thread points (top, bottom, & right side)

  • Operating Temperature

    32 to 158 deg. F (0 to 70 deg. C)

Software

Jump to...
  • Pixel Zoom Type

    2x & 4x with smooth pan via pinch zoom gesture

  • Frame Guides

    Yes

  • DSLR Scale

    Canon, Nikon

  • Custom Scale

    Yes

  • Anamorphic De-Squeeze

    Yes

  • Image Rotate(Manual/Automatic)

    Yes

  • Image Flip (Manual/Automatic)

    Manual and Auto Flip

  • Cross Conversion

    Yes

  • Focus Assist

    Colors: Yes

  • Peaking

    Yes

  • False Color

    Yes

  • Zebra

    Yes - Multiple

  • Waveform

    Yes

  • PIP

    No

  • RGB Parade

    Yes

  • Histogram

    Yes

  • Image Capture

    Yes

  • Custom LUTS

    Yes

  • LUT Creation

    No

  • LUT Downstream

    No

  • LUT Import

    Yes

  • Onion Skinning

    Yes

  • Image Overlay

    Yes

  • Audio Meters

    Yes

General

Jump to...
  • Dimensions (HxWxD)

    3.3 x 0.75 x 5.25" (8.38 x 1.91 x 13.34cm)

  • Weight

    Without Battery: 3.75 oz (106.31g)

  • UPC Code

    850324007311

About SmallHD FOCUS 5" LED Monitor Bundle, DMWBLF19 Power Adapter to Panasonic Camera

rofessional grade camera-top monitor that can power your Panasonic mirrorless camera. The FOCUS is sure to add instant production value for mirrorless and DSLR shooters. Its bright display, professional software tools and convenient mounting is invaluable for shooters looking to do more with less gear.

Daylight Viewable 5" Touchscreen
The FOCUS is the camera-top monitor many shooters have been waiting for. With a light and compact form factor, the FOCUS is bright enough to see and sharp enough to pull focus.

• 800 nits bright
• 5", 1280x720 IPS LCD
• More pixels per inch than retina displays

Big Production Value for Small Camera Setups
The FOCUS is an ideal camera-top monitor for DSLR and mirrorless camera shooters because the Sony L Series battery powering the monitor, can also power the camera. With a battery adapter cable, the FOCUS extends camera run-time as much as 4x, while providing a more useable display.

• Auxiliary power out to DSLR and mirrorless cameras
• Micro HDMI input with port protection
• 1/8 stereo headphone jack
• 6 watt power draw

Convenient Mounting
Every FOCUS monitor will ship with a cold shoe mounted Tilt Arm. Shooters will have a secure way to position their monitor while maintaining a low profile.

• Allows the FOCUS to tilt 180 degrees for viewing convenience
• Secure and lightweight mounting via shoe adapter or 1/4" 20
• Includes a shoe mount of its own for accessories like microphones
• Ships with every FOCUS monitor

Access to Professional Features
Waveform, False Color, Focus Assist, 3D LUTs and Pixel Zoom are just a few professional software tools at your fingertips with the SmallHD FOCUS. Thanks to an intuitive user interface we're calling Swipe OS, interacting and managing these powerful tools has never been easier.

What's in the box:

  • SmallHD FOCUS 5 " On-Camera Monitor
  • FOCUS Tilt Arm
  • 12 " Thin Micro-HDMI Type-D to Micro-HDMI Type-D Cable
  • FOCUS to Panasonic DMW-BLF19 Power Adapter
  • Sony NPF L-Series Battery & Charger
  • 24 " Thin Micro-HDMI Type-D to HDMI Type-A Cable
  • 12 " Micro-USB Male Cable
  • International Battery Charger Power Supply
  • SmallHD 1 Year Limited Warranty
