Review Summary
24" (61cm)
HDMI, 2x 3G-SDI
HDMI, 2x 3G-SDI
4-Pin XLR in.2-pin Locking out
24" IPS LCD
1920 x 1080
1600 nits
22.5 x 14.5 x 2.5" (571.5 x 368.3 x 63.5cm)
13.9 lbs (6.3kg)
The Brightest and Most Durable 24" Production Monitor
With an incredibly fast user interface and professional software toolset, cinematographers can move swiftly as they craft their image. Tools like Exposure Assist with customizable IRE ranges, high resolution/frame rate Waveform, and Dual View are just a few of the high powered, data-driven tools available on the 2403HB.
Superior Viewing
The 2403HB boasts Rec 709 color and wide viewing angle. Each panel is color calibrated before it leaves our doors, so you're ready to take it to set right out of the box.
Durability Meets Portability
The 2403HB weighs just 13.9 pounds; a significant decrease to its predecessor. Its durability and design make it an excellent indoor/ outdoor display option for professional teams.
Professional Ports
I/O options for the 2403HB include 2x 3G-SDI inputs, 2x 3G-SDI outputs, HDMI input/output, and a stereo headphone jack. Power options include an XLR power input (12-34VDC) and a 2-pin locking power output (12V, 1A).
Powered By OS3 - Industry-Leading Software Tools
With an incredibly fast user interface and professional software toolset, cinematographers can move swiftly as they craft their image. Tools like Exposure Assist with customizable IRE ranges, high resolution/frame rate Waveform, and Dual View are just a few of the high powered, data-driven tools available on the 2403HB.
