Sonnet Tempo Duo PCle 6Gb/s eSATA and Super Speed USB 3.0 PCI Express Card

Adds eSATA and USB 3.0 Connectivity to Your System
Cost-effective solution for adding two 6Gb/s eSATA ports plus two USB 3.0 ports to your setup with one adapter card

Powered USB 3.0 Ports
Support bus-powered hard drives, SSDs, DVDs and Blu-ray drives with 2.0A of power per port (no need to connect an additional AC power adapter)

Supports iDevice Charging
Enables simultaneously charging/syncing of iPad, iPhone and other devices that support USB 3.0 charging

Fast Data Transfers
eSATA ports support data transfers at up to 500 MB/s; USB ports support data transfers at up to 350 MB/s

Supports Multi-Drive Enclosures
eSATA ports support drive enclosures with port multipliers; eSATA and USB ports support drive enclosures with hardware RAID controllers expansion systems

Wide USB 3.0 Support & Compatibility
USB 3.0 ports support storage, hubs and other USB 3.0 devices; also compatible with USB 2.0 devices

Optimized for Thunderbolt
Provides maximum performance over Thunderbolt through Thunderbolt-to-PCIe card expansion systems such as Sonnet's Echo Express or xMac family of PCI Express card expansion systems

Two Cards in One - Add Fast 6Gb/s eSATA and SuperSpeed USB 3.0 Ports to Your Computer With One PCIe Card
Do you need to hook up USB 3.0 or eSATA drives to your Mac Pro tower, Windows PC or Thunderbolt-to-PCIe card expansion system If you are looking for great performance and flexible choice of connections, install the Tempo Duo PCIe adapter. This cost-effective Sonnet card delivers the capabilities of two cards in one, adding two 6Gb/s eSATA and two SuperSpeed USB 3.0 ports to your computer.

The Power to Charge and Sync
Sonnet specially engineered the Tempo Duo PCIe to provide extra power to devices connected to the USB 3.0 ports without the need for you to connect an auxiliary power adapter and cable to the card. Delivering up to 2.0A of power per port, this Sonnet solution provides enough power to support USB 3.0 bus-powered hard drives, SSDs, DVDs and Blu-ray devices. The Tempo Duo also supports the USB 3.0 charging specification that enables you to simultaneously charge and sync your iPad, iPhone or other device that supports USB 3.0 charging.

eSATA for Extra Speed
Capable of transferring files at up to 500 MB/s, the Tempo Duo PCIe adapter's fast 6Gb/s eSATA ports are well suited to handle the increased bandwidth requirements of 6Gb/s SSDs. This card also supports older multi-drive enclosures with port multipliers, enabling you to access up to five drives per eSATA cable. The eSATA ports are also perfect for connecting media readers with eSATA interfaces, such as the RED STATION REDMAG 1.8" and 2.5" and even support booting from attached drives under OS X, Windows 8 and 7. This card supports Sonnet's exclusive eSATA data cables with locking connectors.

SuperSpeed USB 3.0 for Performance and Common Connectivity
Most drives offered today include USB 3.0 interfaces. Although they can connect to USB 2.0 ports on your computer, their performance would be reduced by as much as 85 percent! The Tempo Duo PCIe card's dual SuperSpeed USB ports offer native USB 3.0 support and are capable of transferring files at up to 350 MB/s. This Tempo card supports USB 3.0 hubs and other USB 3.0 devices and is also backward compatible with USB 2.0 devices.

Optimized for Maximum Performance Over Thunderbolt
Got a Thunderbolt connection, but no PCIe slot This card is ideal for use in one of Sonnet's Echo Express or xMac Thunderbolt 2-to-PCIe Card Expansion System. The combo enables you to add two fast eSATA ports and two more SuperSpeed USB 3.0 ports with one adapter card to iMac, Mac mini, new Mac Pro, MacBook Air, MacBook Pro and Windows computers with Thunderbolt ports.

Extras
Do you need to connect a multi-drive storage system The Tempo Duo PCIe supports storage systems with built-in hardware RAID controllers like Sonnet's Fusion QR and Fusion R400 RAID USB 3.0, enabling you to take advantage of functions like creating large protected volumes or accessing up to four drives in a single storage enclosure. Tempo Duo PCIe supports OS X, Windows 8 and Windows 7 RAID features, in addition to drive hot-swapping under OS X. AHCI (eSATA) and XHCI (USB 3.0) compliance ensures installation of the card is simple-just plug it in to the PCIe slot. The necessary drivers are installed automatically.

Enhance your Mac or PC with Thunderbolt ports with PCIe expansion capabilities - connect a Sonnet Echo Express Thunderbolt 2-to-PCIe Expansion System to your computer, install a Tempo Duo PCIe card and easily attach USB 3.0 and eSATA storage, media readers and peripherals.

eSATA Fast Connection for
• Increased bandwidth of 6Gb/s SSD
• Multi-drive enclosures with port multipliers
• Media readers with eSATA interfaces
USB 3.0 Common Connections for
• USB 3.0 based hard drives
• USB 3.0 hubs and other drives
