Softron OnTheAir Video 3 (Download) for Mac
See all Softron items

Softron OnTheAir Video 3 (Download) for Mac

SKU: SO3A001 MFR: 3A001
Be the first to review this itemAsk a Question
$2,370.25
$2,495.00
Save: $124.75 (5%)
OR
$198/mo suggested payments with 12‑month special financing. Learn how.
Earn VIP Reward Points

Key Features

  • Enhance your broadcasts with Softron OnTheAir Video 3 for high-quality video output.
  • Enjoy seamless playout with this reliable video encoder, supporting multiple streams.
  • Streamline your workflow using this user-friendly broadcast equipment on your Mac.
  • Achieve professional results with advanced features for dynamic graphics overlay.
  • Ensure wide compatibility with various video codecs and wrappers for any project.
  • Perfect for live streaming, this software supports AJA & Blackmagic output devices.
See More Product Details
Download Version?
1
Add to ListGet Sale Alert

Need help? Ask our experts.

Overview
Compare
Specs
Q&A

Questions & Answers

Reviews about this item

Review Summary

Softron 3A001 Specifications

  • System Requirements 1

    Mac OS 10.8.5 or later
    RAM:
    4 GB for single stream
    6 GB for two streams
    12 GB for four streams
    MacPro type:
    2009 for single stream
    2010 6 Core for two streams
    2010 12 Core for four streams
    iMac type:
    2011 with Thunderbolt for single stream
    2012, 27" (68.5 cm) with two Thunderbolt ports or with PCI expansion chassis for two streams

  • System Requirements 2

    MacBook Pro type:
    2011 with Thunderbolt for single stream
    2012, 15" (38 cm) with two Thunderbolt ports or with PCI expansion chassis for up to four streams
    MacBook Air type:
    1.7 GHz, dual-core, Intel Core i5 for single stream
    Mac mini type:
    2.3 GHz, dual-core, Intel Core i5 for single stream
    2 GHz, quad-core, Intel Core i7 with PCI expansion chassis for up to four streams

  • HD / 4K Support

    HD up to four streams with the appropriate hardware and depending on the codec used
    4K for single stream with the appropriate hardware and depending on the codec used

  • Dynamic Graphics Overlay Support

    Yes, for one stream, with the appropriate hardware and depending on the codec used

  • Compatible Storage

    Any storage that can sustain the required constant write speed (depending on the number of streams, the codec and format). For network storage, enable Macro blocks and disable cache flushing.

  • Number of Licenses Required

    One complete license (with options) is required per stream
    Please download the appropriate version -- Single, Dual, Quad

  • Supported Files/Codecs 1

    Supported Video Codecs: Apple ProRes 422 Family, Apple ProRes 4444, AVC-Intra (50 & 100), AVCHD, Avid DNxHD, DV-PAL, DV/DVCPRO-NTSC, DVCPro-PAL, DVCPro HD, DVCPro 50, H.264, HDV, MPEG IMX (30/40/50), MPEG-2, MPEG-4 Video, Photo-JPEG, Uncompressed, XDCAM EX, XDCAM HD, XDCAM HD422

  • Supported Files/Codecs 2

    Supported Video Wrappers: VI, DV, M2T, M2V, M4V, MP2, MP4, MPEG, MPG, MXF, QuickTime, Transport Stream
    Supported Still Image Formats: BMP, PSD, GIF (supported only as the first image), JPEG, JPEG 2000, PNG, Targa, TIFF
    Supported Audio Formats: Linear PCM, MP3, AAC

  • Supported Output Devices 1

    For multiple outputs on one Mac, the optional Dynamic Graphics Overlay feature, if installed and the Smart Resize feature, must be disabled within the Smart Playout Engine.
    AJA (drivers 10.4.5 or later are required)
    Io Express, by ExpressCard, single stream
    Io XT, by Thunderbolt, up to four streams
    (one Io XT can output two individual streams; can be daisy chained)

  • Supported Output Devices 2

    Kona 3G, by PCI, up to four streams (one Kona 3G, with Firmware in "Standard mode," can output two individual streams; and with firmware in "4K mode," can output four individual streams)
    Kona LHe Plus, by PCI, up to four streams (one Kona LHe Plus card required per output)
    Kona LHi, by PCI, up to four streams (one Kona LHi card required per output)

  • Supported Output Devices 3

    T-Tap, by Thunderbolt, up to four streams (depends on the number of available Thunderbolt ports; one T-Tap can output one stream; cannot be daisy chained)
    Blackmagic Design (drivers 9.7.7 or later are required)
    DeckLink 4K Extreme, by PCI, up to four streams
    (one card required per output)
    DeckLink Duo, by PCI, up to two streams
    (one card has two independent outputs)
    DeckLink HD Extreme 3D, by PCI, up to four streams
    (one card required per output)

  • Supported Output Devices 4

    DeckLink Mini Monitor, by PCI, up to four streams
    (one card required per output)
    DeckLink Optical Fibre, by PCI, up to four streams
    (one card required per output)
    DeckLink Quad, by PCI, up to four streams
    (one card has four independent outputs; two cards are required for eight outputs)
    DeckLink SDI, by PCI, up to four streams
    (one card required per output)
    DeckLink Studio, by PCI, up to four streams
    (one card required per output)

  • Supported Output Devices 5

    Intensity Extreme, by Thunderbolt, up to four streams
    (one device required per output; requires one Thunderbolt port per device; cannot be daisy chained)
    Intensity Pro, by PCI, up to four streams
    (one card required per output)
    Intensity Shuttle, by Thunderbolt, up to four streams
    (1 device required per output; requires one Thunderbolt port per device; cannot be daisy chained)
    Multibridge Eclipse, by PCI breakout box, up to four streams
    (1 card required per output)

  • Supported Output Devices 6

    Multibridge Pro, by PCI breakout box, up to four streams
    (one card required per output)
    Teranex 2D Processor, by Thunderbolt, up to four streams
    (one device required per output; requires one Thunderbolt port per device; cannot be daisy chained)
    Teranex 3D Processor, by Thunderbolt, up to four streams
    (one device required per output; requires one Thunderbolt port per device; cannot be daisy chained)

  • Supported Output Devices 7

    UltraStudio 3D, by Thunderbolt, up to four streams
    (one device required per output; requires one Thunderbolt port per device; cannot be daisy chained)
    UltraStudio 4K, by Thunderbolt, up to four streams
    (one device required per output; requires one Thunderbolt port per device; cannot be daisy chained)
    UltraStudio Express, by Thunderbolt, up to four streams
    (one device required per output; requires one Thunderbolt port per device; cannot be daisy chained)

  • Supported Output Devices 8

    UltraStudio Mini Monitor, by Thunderbolt, up to four streams
    (one device required per output; requires one Thunderbolt port per device; cannot be daisy chained)
    DELTACAST
    DELTA-3G, by PCI, up to four streams
    DELTA-HD, by PCI, up to four streams
    DELTA-SDI, by PCI, up to four streams
    DELTA-Key, by PCI, up to two streams

About Softron 3A001

You can elevate your live streaming and local broadcasting experience with the high-tech Softron OnTheAir Video 3 for Mac. This innovative, automated playout software is designed to streamline your operations with its sophisticated scheduling capabilities and flexible playlist support.

As a modern solution for live operations, OnTheAir Video 3 serves as an efficient clip store, capable of direct-to-web streaming without the need for an additional video card. This is made possible when paired with Softron's MovieRecorder 3, which is sold separately. MovieRecorder 3 seamlessly receives frames from OnTheAir Video 3 and encodes them into any required format, including HTTP Live Streaming.

For added versatility, you can also opt to stream using an additional card and Softron's MovieStreamer HLS software, both sold separately. Unlike previous versions, OnTheAir Video 3 now comes with built-in HD support, a scheduler, and a static logo overlay feature.

The software's playlist capabilities are designed for efficiency and flexibility. Playlists can be scheduled to play automatically at assigned times, non-stop for days, or even looped for months until a new start date/time is set. You can also edit your playlists during playout for maximum control.

OnTheAir Video 3 supports a variety of file types, including QuickTime (.mov), Transport Stream (.ts), and MXF (.MXF), among others. Still images can be played in PNG and other formats, and audio support extends up to 5.1 channels.

At the heart of this stylish software is Softron's own Smart Playout Engine. This advanced player allows for the mixing of multiple codecs and resolutions in the same playlist without the need for additional software. It also features three resize tools that efficiently scale frame sizes. These include Automatic Resize, which scales to Fill, Pan-and-Scan, or Letterbox; Manual Resize, which lets you define parameters; and Smart Resize, which produces an advanced resize of interlaced clips, limiting artifacts to a minimum or none.

Experience the sleek, modern design and superior functionality of the Softron OnTheAir Video 3 for Mac, a reputable brand known for producing high-quality products.

Softron 3A001 Features

  • Flexible Codec/Resolution Support: OnTheAir Video 3 features Softron's Smart Playout Engine that allows mixing multiple codecs and resolutions in the same playlist without installing any additional software
  • Automatic / Manual / Smart Resize: Automatic Resize will scale different resolution clips to Fill, Pan-and-Scan, or Letterbox; Manual Resize will let you define parameters; and Smart Resize produces an advanced resize of interlaced clips, limiting artifacts to a minimum or none
  • 24/7 Unattended Playout Schedule: Playlists can be scheduled to play automatically at assigned times throughout the day, non-stop for days and they can also be looped for months, until a new start date/time hits
  • Actions for Secondary Events: A flexible "Actions" system enables OnTheAir Video 3 to control multiple external devices, such as routers (through RS-232 or Ethernet), character generators and logo inserters (using GPI triggers). Actions can be triggered at any moment of a clip within a playlist
  • Play Out Up to 4 Channels: OnTheAir Video 3 requires one license per output channel and supports up to four HD channels on one Mac, as the built-in Smart Playout Engine can take advantage of multiple cores. (Please download the matching OnTheAir Video 3 version -- Single, Dual, or Quad)
  • Video & Audio: HD support, Seamless playback, YUV and ARGB video output modes depending on the video card, External and internal keying if the video card supports keying in the desired resolution, Scrubbing (move playout at time position), 4K capable in "standard mode" (without logo, Smart Resize)
  • Video & Audio: Still image output, Still logo overlay, Smart Resize (handles interlaced formats without artifacts), Automatic Resize (auto resizes clips to fit the video output), Manual Resize (user defined per clip), Supports direct-to-web IP streaming without any additional card via MovieRecorder
  • Video & Audio: Supports IP streaming using an additional card via MovieStreamer HLS, sold separately, Audio/video buffering, One output per Mac if with Smart Resize and the optional Dynamic Graphics Overlay, Same audio destinations as video output, Linear PCM, MP3 and AAC audio formats
  • Video & Audio: Plays audio only files, Multiple audio channels output, Audio auto-mapping (using QuickTime track languages)
  • Playlist & Schedule: As-run-logs, Cue Mode, Playlist editing during playout, Show/Hide thumbnails, ASCII playlist import, Opens all vpls playlists (save only in .xpls), Scheduled playout, Event fixed start time, Schedule imports, Live events video router control for switching to studio
  • Media Management: Finder label, Clip relative path, Clip trimming, Clip splitting, Reference movie, MXF files support, Still image support, Resize clip manually, Position clip in frame (resized), Clip end behaviors (Normal, Stop at End, Hold Last Frame, Play Next Clip, Loop), Create offline clip
  • Control matrix video routers (requires OnTheAir Switch application and its supported routers), GPI input/output (requires GPI Commander Box with no extra software as support is built in), MIDI controllable, Secondary events (Actions), AppleScriptable
  • Supported Video Codecs: Apple ProRes 422 Family, Apple ProRes 4444, AVC-Intra (50 & 100), AVCHD, Avid DNxHD, DV-PAL, DV/DVCPRO-NTSC, DVCPro-PAL, DVCPro HD, DVCPro 50, H.264, HDV, MPEG IMX (30/40/50), MPEG-2, MPEG-4 Video, Photo-JPEG, Uncompressed, XDCAM EX, XDCAM HD, XDCAM HD422
  • Supported Video Wrappers: AVI, DV, M2T, M2V, M4V, MP2, MP4, MPEG, MPG, MXF, QuickTime, Transport Stream
  • Supported Still Image Formats: BMP, PSD, GIF (supported only as the first image), JPEG, JPEG 2000, PNG, Targa, TIFF
