Review Summary
Mac OS 10.8.5 or later
RAM:
4 GB for single stream
6 GB for two streams
12 GB for four streams
MacPro type:
2009 for single stream
2010 6 Core for two streams
2010 12 Core for four streams
iMac type:
2011 with Thunderbolt for single stream
2012, 27" (68.5 cm) with two Thunderbolt ports or with PCI expansion chassis for two streams
MacBook Pro type:
2011 with Thunderbolt for single stream
2012, 15" (38 cm) with two Thunderbolt ports or with PCI expansion chassis for up to four streams
MacBook Air type:
1.7 GHz, dual-core, Intel Core i5 for single stream
Mac mini type:
2.3 GHz, dual-core, Intel Core i5 for single stream
2 GHz, quad-core, Intel Core i7 with PCI expansion chassis for up to four streams
HD up to four streams with the appropriate hardware and depending on the codec used
4K for single stream with the appropriate hardware and depending on the codec used
Yes, for one stream, with the appropriate hardware and depending on the codec used
Any storage that can sustain the required constant write speed (depending on the number of streams, the codec and format). For network storage, enable Macro blocks and disable cache flushing
One complete license (with options) is required per stream (Please download the appropriate version -- Single, Dual, Quad)
Supported Video Codecs:
Apple ProRes 422 Family, Apple ProRes 4444, AVC-Intra (50 & 100), AVCHD, Avid DNxHD, DV-PAL, DV/DVCPRO-NTSC, DVCPro-PAL, DVCPro HD, DVCPro 50, H.264, HDV, MPEG IMX (30/40/50), MPEG-2, MPEG-4 Video, Photo-JPEG, Uncompressed, XDCAM EX, XDCAM HD, XDCAM HD422
Supported Video Wrappers:
AVI, DV, M2T, M2V, M4V, MP2, MP4, MPEG, MPG, MXF, QuickTime, Transport Stream
Supported Still Image Formats:
BMP, PSD, GIF (supported only as the first image), JPEG, JPEG 2000, PNG, Targa, TIFF
Supported Audio Formats:
Linear PCM, MP3, AAC
For multiple outputs on one Mac, the optional Dynamic Graphics Overlay feature, if installed, must be disabled within the Smart Playout Engine.
AJA (drivers 10.4.5 or later are required)
Io Express, by ExpressCard, single stream
Io XT, by Thunderbolt, up to four streams
(one Io XT can output two individual streams; can be daisy chained)
Kona 3G, by PCI, up to four streams
(one Kona 3G, with Firmware in "Standard mode," can output two individual streams; and with firmware in "4K mode," can output four individual streams)
Kona LHe Plus, by PCI, up to four streams
(one Kona LHe Plus card required per output)
Kona LHi, by PCI, up to four streams
(one Kona LHi card required per output)
T-Tap, by Thunderbolt, up to four streams
Blackmagic Design (drivers 9.7.7 or later are required)
DeckLink 4K Extreme, by PCI, up to four streams
(one card required per output)
DeckLink Duo, by PCI, up to two streams
(one card has two independent outputs)
DeckLink HD Extreme 3D, by PCI, up to four streams
(one card required per output)
DeckLink Mini Monitor, by PCI, up to four streams
(one card required per output)
DeckLink Optical Fibre, by PCI, up to four streams
(1 card required per output)
DeckLink Quad, by PCI, up to four streams
(one card has four independent outputs; two cards are required for eight outputs)
DeckLink SDI, by PCI, up to four streams
(one card required per output)
DeckLink Studio, by PCI, up to four streams
(one card required per output)
Intensity Extreme, by Thunderbolt, up to four streams
(one device required per output; requires one Thunderbolt port per device; cannot be daisy chained)
Intensity Pro, by PCI, up to four streams
(one card required per output)
Intensity Shuttle, by Thunderbolt, up to four streams
(one device required per output; requires one Thunderbolt port per device; cannot be daisy chained)
Multibridge Eclipse, by PCI breakout box, up to four streams
(one card required per output)
Multibridge Pro, by PCI breakout box, up to four streams
(one card required per output)
Teranex 2D Processor, by Thunderbolt, up to four streams
(one device required per output; requires one Thunderbolt port per device; cannot be daisy chained)
Teranex 3D Processor, by Thunderbolt, up to four streams
(one device required per output; requires one Thunderbolt port per device; cannot be daisy chained)
UltraStudio 3D, by Thunderbolt, up to four streams
(one device required per output; requires one Thunderbolt port per device; cannot be daisy chained)
UltraStudio 4K, by Thunderbolt, up to four streams
(one device required per output; requires one Thunderbolt port per device; cannot be daisy chained)
UltraStudio Express, by Thunderbolt, up to four streams
(one device required per output; requires one Thunderbolt port per device; cannot be daisy chained)
UltraStudio Mini Monitor, by Thunderbolt, up to four streams
(one device required per output; requires one Thunderbolt port per device; cannot be daisy chained)
DELTACAST
(Please make sure to choose the right model depending on your I/O needs / May be "Low Profile")
DELTA-3G, by PCI, up to four streams
DELTA-HD, by PCI, up to four streams
DELTA-SDI, by PCI, up to four streams
DELTA-Key, by PCI, up to two streams
The Softron OnTheAir Video Express 3 (Electronic Download) is a Mac-based, 64-bit playout software with flexible playlist support. In OnTheAir Video Express 3, Softron uses its own playout engine called Smart Playout Engine. This player allows mixing multiple codecs and resolutions in the same playlist without installing any additional software and it features an Automatic Resize tool that will efficiently scale frame sizes to Fill, Pan-and-Scan, or Letterbox. The standard playout file type is QuickTime (.mov), but you can also select Transport Stream (.ts), MXF (.MXF) and others. Still images play in PNG and other formats and audio support ranges up to 5.1 channels.
