SoundTube SM500i-II-WX 5.25" Extreme Weather Outdoor Surface Mount Speaker with BroadBeam, 75W RMS, Black, Single

SKU: SO500IIIWXBK MFR: SM500I-II-WX-BK
Earn VIP Reward Points

Key Features

  • Experience superior audio clarity with this SoundTube outdoor speaker.
  • Enjoy BroadBeam™ technology for consistent sound coverage in any space.
  • This extreme weather speaker is built to withstand harsh outdoor conditions.
  • Achieve optimal sound with versatile 75W RMS power for clear audio output.
  • Easily connect via Euroblock for streamlined, professional audio setup.
  • Enhance your outdoor audio experience with this durable, 5.25" speaker.
See More Product Details
Special Order?Estimated to Ship: 09/17/2025
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

1 Year

$39.99

2 Year

$69.99

3 Year

$79.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

SoundTube SM500i-II-WX Specifications

  • System Type

    5.25", coaxial, surface-mount, ported (64W transformer for 25/70.7/100V or transformer bypass)

  • Impedance

    4 Ohms (Nominal)

  • Sensitivity

    At 2.83V/1M: 86.0 dB
    At 1W/1M: 83.0 dB

  • Frequency Response

    86 Hz - 22 kHz (-3 dB)
    60 Hz - 22 kHz (-10 dB)

  • Max. Program Power

    150W

  • Max. Continuous Power RMS

    75W

  • Max. SPL

    At 1M RMS: 102 dB

  • Coverage Angle

    75 deg. horizontal / 90 deg. vertical (-6 dB at 2 kHz)
    120 deg. horizontal / 125 deg. vertical (-6 dB at 10 kHz)
    100 deg. horizontal / 100 deg. vertical (Avg. 2 to 10 kHz)

  • Aiming Angle

    360 deg. (Radial)
    0 - 90 deg. (Horizontal)

  • Directivity Factor (Q)

    4.6dB (Averaged 100 Hz - 10 kHz); 9.8dB at 2 kHz

  • Directivity Index (DI)

    5.6 dB (Averaged 100 Hz - 10 kHz); 9.9 dB at 2 kHz

  • Tap Selector

    Six-position rotary switch with transformer bypass

  • Frequency Driver

    Low-Frequency Driver: 133mm (5.25") polypropylene cone, butyl rubber surround
    High-Frequency Driver: 25mm (1.0") convex titanium tweeter with waveguide

  • Low Frequency Voice Coil

    25mm (1.0")

  • Crossover Frequency

    3 kHz

  • Network Type

    Low-Pass: 12 dB per octave, 2nd order
    High-Pass: 12 dB per octave, 2nd order

  • Enclosure Material

    Injection-molded ABS, glass fiber reinforced

  • Grille

    Aluminum with powder-coat finish

  • Inputs

    Four-pin, 5.08mm Euroblock for individual or daisy chain connection

  • Regulatory

    UL 1480 (UEAY) planned; CE Approved

  • RoHS

    Approved

  • Dimensions (HxWxD)

    Including Bracket: 289.56 x 212.26 x 266.30mm (11.40 x 8.36 x 10.48")

  • Weight

    4.3kg (9.5 lbs)

  • UPC Code

    644216203406

About SoundTube SM500i-II-WX

From the innovative minds at Soundtube, the SM500i-II-WX 5.25" Extreme Weather Outdoor Surface Mount Speaker stands as a testament to durable, high-quality audio engineering. This stylish and reliable speaker is designed to endure the most challenging outdoor environments, ensuring your soundscapes remain pristine in any weather.

Crafted with a robust mid-size enclosure, the SM500i-II-WX delivers a powerful low-end response starting at 60 Hz, while its optimal off-axis performance maintains clarity across a frequency range of 2 to 10 kHz. The integration of SoundTube's proprietary BroadBeam waveguide technology ensures a consistent, high-performance audio experience throughout the operating bandwidth.

The speaker's design is not only functional but also aesthetically pleasing, featuring a low-profile grille that blends seamlessly into any outdoor setting. The six-position tap switch with transformer bypass provides versatile power options, and the included mounting hardware, such as the innovative Stealth bracket system, offers increased aiming angles for precise sound direction.

Security is a priority with the SM500i-II-WX, which includes a security knob to deter tampering once installed. Its unlimited directional aiming capability and discreet profile make it a perfect choice for those seeking both performance and elegance in their audio setup.

Ideal for a wide range of outdoor applications, from background music to mid-level SPL needs, the SM500i-II-WX utilizes SoundTube's advanced Weather Technology. This guarantees lasting performance, even in the face of severe weather conditions. The system's detachable mounting plate is designed for pre-mounting flexibility, suitable for both wall and pole applications.

The speaker's full frequency dispersion pattern and high sensitivity make it an excellent choice for delivering music and paging in diverse settings such as retail spaces, amusement parks, restaurants, airports, hotels, schools, and casinos. For those desiring deeper bass, SoundTube's RS1001i-II-T and SM1001p subwoofers complement the SM500i-II-WX by extending the bass response down to 41 Hz (-10 dB), ensuring a rich and full audio experience.

In summary, the SM500i-II-WX is a superior choice for anyone seeking an innovative, durable, and high-quality outdoor audio solution that promises both style and reliable performance under any conditions.

SoundTube SM500i-II-WX Features

  • BroadBeam waveguide technology delivers a consistent dispersion pattern up to 10 kHz for maximum coverage area per speaker
  • One 5.25" (133mm) polypropylene woofer and one 1.0" (25mm) convex titanium tweeter with FerroFluid cooling
  • 86.0 dB average sensitivity offers high output capabilities and reduced amplification costs
  • Includes stainless steel screws and grille for severe weather, outdoor applications
  • Easy access, six-position selectable tap switch for 25-, 70.7- and 100V applications with transformer bypass position
  • Patented ZeroReflection enclosure technology for optimal sound reproduction and cabinet rigidity
  • Aluminum grille with powder-coat finish
  • Includes the new SM500i-II-WX Stealth bracket mounting system
  • Vertical and horizontal pivoting allow the SM500i-II-WX to be aimed anywhere within the installation space
  • Low profile enclosure design keeps the speaker close to the wall
  • UL 1480 (UEAY) planned
  • High-quality black paint finish

Warranty Information

This product has a limited warranty of 60 months.

Key Features

  • Experience superior audio clarity with this SoundTube outdoor speaker.
  • Enjoy BroadBeam™ technology for consistent sound coverage in any space.
  • This extreme weather speaker is built to withstand harsh outdoor conditions.
  • Achieve optimal sound with versatile 75W RMS power for clear audio output.
  • Easily connect via Euroblock for streamlined, professional audio setup.
  • Enhance your outdoor audio experience with this durable, 5.25" speaker.

What's in the box:

  • SoundTube SM500i-II-WX 5.25 " Extreme Weather Outdoor Surface Mount Speaker with BroadBeam
  • Safety Cable with Speaker Mounting Bolt
  • Euroblock Connector
  • Wall Mount Bracket
  • Terminal Weather Boot
  • SoundTube 5 Year Limited Warranty
