Sony Video Delay Distribution Board for PFV-L10 19" Rack Mount Interface Unit
See all Sony items
17% Off

Sony Video Delay Distribution Board for PFV-L10 19" Rack Mountable Compact Interface Unit

SKU: SOBKPFL723 MFR: BKPFL723
Be the first to review this itemAsk a Question
$586.50
$710.00
Save: $123.5 (17%)
OR
$98/mo suggested payments with 6‑month special financing. Learn how.
Earn VIP Reward Points

Key Features

  • Achieve low latency video distribution with this Sony video delay board!
  • Enjoy wide compatibility; this unit works seamlessly with Sony's PFV-L10.
  • Ensure a reliable connection with BNC composite video inputs/outputs (x8).
  • Fine-tune your video with adjustable system delay from 50 to 1430 ns.
  • Get high resolution video output with a signal-to-noise ratio of 70dB.
  • Easy setup: Integrate this compact interface unit into your existing rack.
See More Product Details
Temporarily On Backorder?Expected Availability: 10/2025Request assistance or get notified
Free Shipping

See Options

1
Add to ListGet Sale Alert

Protect your gear with Adorama Protect.* Learn more

2 Year

$69.99

3 Year

$94.99

4 Year

$119.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Browse our FAQ

See Terms & Conditions

Sony Video Delay Distribution Board for PFV-L10 19" Rack Mount Interface Unit Specifications

  • Compatibility

    Sony PFV-L10 19" Rack Mountable Compact Interface Unit

  • Cable length

    300m or more (when using a BELDEN 8281 or Fujikura 5C2V coaxial cable)

  • Output return loss

    40dB or more (at above 5 MHz)

  • System delay

    Approx. 50 to 1430 ns
    350 ns x 3 STEP
    75 ns x 5 STEP
    15 ns x 5 STEP
    FINE adjustment: 20 ns

  • Signal to noise ratio

    70dB or more (10 kHz to 6 MHz)

  • Frequency response

    Less than - 2.5 dB

  • DG/DP

    Less than 0.3 % / 0.3 deg.

  • K factor

    0.5 % or less

  • Tilt and Sag

    0.5 % or less

  • Inputs/Outputs

    Composite Video: BNC (x1 Input, x8 Output with Delay)

  • Power Requirements

    +5 V DC: 0.6A

  • Dimensions (W x H)

    Main Board: 267 x 77mm / 10.51 x 3.03"
    Connector Panel: 33 x 85mm / 1.29 x 3.34"

  • Weight

    Main Board: 140g / 4.93oz
    Connector Panel: 100g / 3.52oz

About Sony Video Delay Distribution Board for PFV-L10 19" Rack Mount Interface Unit

Just when you thought video distribution couldn't get any better, Sony introduces the Video Delay Distribution Board for PFV-L10 19" Rack Mountable Compact Interface Unit. This high-quality, durable board is an essential tool for any professional setting, offering an adjustable delay range from 50 ns to a whopping 1430 ns.

Designed to accept both NTSC and PAL analog video signals, this user-friendly board distributes the delayed video signal across eight outputs, ensuring your video distribution needs are met with precision and ease. With the ability to equalize up to 300 m of output video cable, this compact, rack-mountable unit is a versatile solution for a myriad of applications.

Whether you're looking to equalize the phase difference between two alternative signal routes or need a reliable system integration tool, this Video Delay Distribution Board has you covered. Plus, it's compatible with BKPF-L Series function boards, allowing you to install them into PFV-L Series Interface Units in any combination.

Experience the Sony difference with this Video Delay Distribution Board for PFV-L10 19" Rack Mountable Compact Interface Unit, a testament to Sony's commitment to delivering innovative, top-tier electronics.

Sony Video Delay Distribution Board for PFV-L10 19" Rack Mount Interface Unit Features

  • Distributes an NTSC or PAL analog signal, with a delay function
  • Adjustable delay range, 50 ns to 1430 ns
  • Eight distribution outputs
  • Passive loop-through output
  • Equalization for up to 300 m cable (Belden 8281, Fujikura 5C2V or equivalent)
  • Clamping ON/OFF selectable
  • AC or DC coupling selectable

Warranty Information

This product has a limited warranty of 3 months for parts and 3 months for labor.

Join VIP PRO

2 Day Delivery on thousands of items!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Achieve low latency video distribution with this Sony video delay board!
  • Enjoy wide compatibility; this unit works seamlessly with Sony's PFV-L10.
  • Ensure a reliable connection with BNC composite video inputs/outputs (x8).
  • Fine-tune your video with adjustable system delay from 50 to 1430 ns.
  • Get high resolution video output with a signal-to-noise ratio of 70dB.
  • Easy setup: Integrate this compact interface unit into your existing rack.

What's in the box:

  • Sony Video Delay Distribution Board for PFV-L10 19 " Interface Unit
  • Sony 90 Day Limited Warranty
