About Sonifex DHY-03T
The Sonifex DHY-03T Twin is a high quality digital telephone hybrid, which is suitable for most general telephony applications and is often used in radio and TV stations, bingo halls and dealing floors. The digital DHY-03T telephone hybrid is the replacement for the DHY-02, which for many years has set the standard as an excellent value, high quality telephone hybrid. The DHY-03T can be used for any application where a clean telephone signal is required and the line is not subject to excessive delay.
Sonifex DHY-03T Features
- Fully automatic - adapts to varying line conditions and has automatic signal limiting
- Fully adaptive echo cancellation to 127msec - default is 24msec
- 75dB typical line balance rejection offering superb performance and crystal clear audio
- Front panel input and output gain controls
- Front panel LED metering of receive and send signals
- Built-in conferencing for 2 hybrids, so that a single telco channel on a mixing desk can receive 2 calls
- Integrated ring detector - automatic call answering after a pre-determined number of rings
- Automatic call disconnection. Fitted with K-break, line polarity reversal and dial tone disconnect detection, defined by the country selection
- Automatic ducking facility allows the talent to 'shout-down' or talk over, a caller by reducing the gain of the caller's signal if it goes above a certain level
- Local and remote line hold switching - calls can be remotely switched through a mixing console
- Line hold/release button to control line hold circuit, illuminates to indicate the status of the line and flashes to show ring status
- DTMF tone recognition allowing a opto-isolated GPI output to be made on receipt of selected DTMF tones, e.g. for starting a studio automation recorder automatically to record a remote telephone interview
- International operation with built-in configurable settings for each country. Country selection allows the unit to provide line impedance and a simulation circuit to match the country
- RS232 serial port for remote control of the TBU, DTMF tone dialling and firmware upgrades to add new country settings
- Remote port distributes the remote line connect switch and tally output, a momentary/latch selector and the DTMF detect output
- Remote line connect switch can be either momentary or latching in its action
- Balanced mic/line input - 10k balanced input selectable for 0dBu clean feed line or microphone level with adjustable gain
- Divert relay
- Balanced output - 0dBu low impedance balanced output, with output gain settings
- Record output - the conferencing output can be set via a jumper to give a mix of the caller and mic/line input signals for recording both sides of the telephone conversation
- Line limiter, bandpass filter and output noise gate with preset threshold providing low distortion audio
- Built in universal power supply between 90V AC and 250V AC, 47-63Hz, IEC mains input
