Sony EVI-H100V HD PTZ Camera with RC4-SHD Single Cable Solution Kit, White
See all Sony items

Sony EVI-H100V HD PTZ Camera with RC4-SHD Single Cable Solution Kit, 20x Optical Zoom, White

SKU: SOEVIH100VWP
Be the first to review this item

This item is no longer available.

Recommended Alternatives

Sony FE 300mm f/2.8: Picture 1 regular
Sony FE 300mm f/2.8 GM OSS Lens
$6,798.00
Sony 400-800mm f/6.3-8 G OSS: Picture 1 regular
Sony FE 400-800mm f/6.3-8 G OSS Lens
$3,298.00$2,698.00
Sony FE 70-200mm f/4 G OSS II: Picture 1 regular
Sony FE 70-200mm f/4 Macro G OSS II Lens
$1,998.00$1,698.00
Sony FE 70-200mm f/2.8: Picture 1 regular
Sony FE 70-200mm f/2.8 GM OSS II G Lens for Sony FE
$3,148.00$3,098.00
See More Recommendations
Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Browse our FAQ

See Terms & Conditions

Sony EVI-H100V + RC4-SHD Specifications

  • Camera: Image sensor

    1/2.8-type Exmor CMOS

  • Camera: Signal system

    HD: 1080p/29.97, 1080p/25, 1080i/59.94 (frame out 1080PsF29.97), 1080i/50 (frame out 1080PsF25), 720p/59.94, 720p/50, 720p/29.97, 720p/25

  • Camera: Lens

    f= 4.7mm (wide) to 94.0mm (tele), F1.6 to F3.5
    Optical zoom: 20x
    Digital zoom: 12x

  • Camera: Min. Object Distance

    10mm (wide) - 800mm (tele)
    Default: 290mm

  • Camera: Horizontal viewing angle

    55.4 deg. (wide) to 2.9 deg. (tele)

  • Camera: Focus system

    Auto, One-push AF, Manual, Infinity

  • Camera: Min. illumination

    High sensitivity mode: 0.5 lx (F1.6, 50 IRE)
    Normal mode: 1.7 lx (F1.6, 50 IRE)

  • Camera: Shutter speed

    1 to 1/10000 s

  • Camera: Gain

    Auto / Manual / Max. AE Gain Limit (-3 to 28dB, 2dB steps)

  • Camera: White balance

    Auto, Indoor, Outdoor, One-push, Manual

  • Camera: Wide-D

    Yes

  • Camera: Exposure control

    Auto, Manual, Priority mode (shutter priority & iris priority), Bright, EV compensation, Slow Shutter AE

  • Camera: S/N ratio

    More than 50dB

  • Camera: Pan/Tilt Angle

    Pan: +/-170 deg.
    Tilt: '+90 deg. / -20 deg.

  • Camera: Pan/Tilt Maximum speed

    Pan: 100 deg./sec
    Tilt: 90 deg./sec

  • Camera: Preset positions

    6

  • Camera: Video output

    HD: DVI-I (Digital (RGB) and Analog component)

  • Camera: Interface

    RS-232C/RS-422

  • Camera: Protocol

    VISCA

  • Camera: Power requirements

    DC 12V

  • Camera: Power consumption

    11W

  • Camera: Operating temperature

    32 to 104 deg. F / 0 to 40 deg. C

  • Camera: Storage temperature

    -4 to 140 deg. F / -20 to 60 deg. C

  • RC4-SHD Kit: Cameras Supported

    Sony EVI-HD3/DVI
    Sony EVI-HD7/DVI
    Sony EVI-H100V/DVI

  • RC4-SHD Kit: Codec Supported

    Generic HDMI & Control Device

  • Dimensions (W x H x D)

    Camera: 145 x 164 x 164mm / 5.71 x 6.46 x 6.46"
    RC4-HE: 3.75 x 1.5 x 3.62" / 9.53 x 3.81 x 9.21cm
    RC4-CE: 2.5 x 0.87 x 3.68" / 63.50 x 22.10 x 93.47mm

  • Weight

    Camera: 1550g / 54.67oz

About Sony EVI-H100V + RC4-SHD

EZ-2-Connect PTZ Camera Solution featuring EVI-H100V/W (white) PTZ Camera with RC4-SHD Kit.

EVI-H100V HD PTZ Camera
The EVI-H100V is one of the newest additions to the EVI PTZ HD camera lineup. Featuring full 1080/20 HD resolution with a 1/2.8-type Exmor CMOS sensor, this dynamic new camera is a smart-looking addition to Sony's feature-rich EVI HD camera lineup. Ceiling mountable and also available in white, this camera offers a multitide of options in remote-monitoring, videoconferencing, distance learning and house of worship applications.

• The new EVI-H100V/W is ceiling mountable, allowing for a multitiude of additional options in a variety of remote monitoring applications
• Offering full 1080/20 HD resolution with 20x optical zoom makes the EVI-H100V ideal for a variety of applications
• The EVI-H100V/W features 1/2.8-type Exmor CMOS sensor, which provides crisp, clear HD images
• A key feature of the EVI-H100V/W is the RS-232C/RS-422 interface protocol. allowing for easy connectivity to a variety of peripheral products
• Also available in a black version: EVI-H100V

RC4-SHD Single Cable Solution Kit
• Single CAT5e or CAT6
• Camera power
• Digital video
• Camera control
• Wired & Modulated IR
• Visca Control Loop

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

What's in the box:

  • Sony EVI-H100V HD PTZ Camera
  • RC4-HE Head-End Module
  • RC4-CE Camera Module
  • RCC-C004 1' DVI to HDMI Camera Cable
  • RCC-C005 1' RJ45 to Sony 8 Pin Mini-Din Camera Cable
  • RCC-C006 1' Visca 8 Pin Mini-Din to RJ11 Camera Cable
  • RCC-H001 3' HDMI Head-End Cable
  • RCC-H013 3' Control DB9F to DB9F Head-End Cable
  • RCC-H004 1' Visca Loop DB9F to 8Pin Head-End Cable
  • WPS-12 Power Supply
  • Sony 3 Year Warranty
